INSTRUCTION MANUAL
VF-9000
SERIAL DIGITAL FIBER OPTIC TRANSPORT and DISTRIBUTION
SYSTEM FOR SMPTE 259, 292, 424, DVB-ASI,
with gigabit ethernet with SNMP & Web page monitoring and other protocols
MultiDyne
Harnessing The Power of Light
10 NEWTON PLACE
HAUPPAUGE, NY 11788 USA
(877) 685-8439 / (516) 671-7278 / FAX (516) 671-3362
sales@multidyne.com
www.multidyne.com
Advertisement
Table of Contents
Summary of Contents for MultiDyne VF-9000
- Page 1 INSTRUCTION MANUAL VF-9000 SERIAL DIGITAL FIBER OPTIC TRANSPORT and DISTRIBUTION SYSTEM FOR SMPTE 259, 292, 424, DVB-ASI, with gigabit ethernet with SNMP & Web page monitoring and other protocols MultiDyne Harnessing The Power of Light 10 NEWTON PLACE HAUPPAUGE, NY 11788 USA (877) 685-8439 / (516) 671-7278 / FAX (516) 671-3362 sales@multidyne.com...
- Page 2 MULTIDYNE, the Multidyne logo, are registered trademarks of MULTIDYNE Electronics, Inc. Copyright 2018 MULTIDYNE Electronics, Inc., Hauppauge, New York. Printed in the United States of America. All Rights Reserved. Contents of this publication may not be reproduced in any form without the written permission of MULTIDYNE Electronics, Inc.
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION..…………..………...…..…..………...…………………………………….……..…....……1 FEATURES AND OPERATION…..…………………………………………..……........………...1 FRONT PANEL.....…...……………………………………..........………………..…..1 REAR PANEL......…..…..……………………………………………………….........……..1 - 2 VIDEO CARD......…..……………………………………………..........………………2 • QUAD VIDEO...…..……………………………………………..........………………2 • DUAL BNC....…..……………………………………………..........………………2 • ADD OR REMOVE A CARD..……………………………………….....……......………...2 NETWORK SETTINGS AND STATUS MONITORING………………………........……..…….……..2 NETWORK SETTINGS..………………..………………………..........……...……3 - 4 WEB PAGE STATUS MONITORING..…………………………..........……………4 - 5 ELECTRICAL CHARACTERISTICS OF THE CARDS...….……………….....…......………………..…5 SNMP MONITORING..…..……………………………………….…..........……………5 - 6 •... -
Page 4: Introduction
The lock LED is a bi-color LED. It is Red when there is no Each card in the VF-9000 has two or four BNCs on the back signal or when the signal does not lock to any data rate like and one or two SFP cages in the front. -
Page 5: Video Card
In receive configuration, they are received over fiber and re-clocked and transmitted over You can monitor the status of all the cards in your VF-9000 copper. The video cards have High-density BNC on the rear frame via a Web page dashboard that is embedded within and hot-swappable SFP ports in the front. -
Page 6: Network Settings
Network Settings To use one of the fixed preset IP addresses: The method for setting the IP address of the VF-9000 frame 1. Set the DIP Switch to specify the desired preset IP address is determined using the 4-position DIP switch on the rear as outlined in the IP address DIP switch table. -
Page 7: Web Page Status Monitoring
VF-9000 is to be employed in. The computer used for monitoring the VF- You can monitor the status of all the cards in your VF-9000 9000 frame must be on the same subnet. Contact your IT frame via a Web page dashboard that is served from the Department if necessary. -
Page 8: Electrical Characteristics Of The Cards
The Network Controller Card can provide optional support information about the SFP modules that are plugged into the for remote monitoring of your VF-9000 frame using the SFP Cages on the card. Displayed are the SFP Module type Simple Network Management Protocol (SNMP). This protocol... -
Page 9: Snmp Configuration
• SDI Card Ch 2 SDI signal optical power status 2. Open the VF-9000 Web page Dashboard in a web browser. • SDI Card Ch 3 SDI signal optical power status 3. In the SNMP Settings Box, check the Trap Enable check •... -
Page 10: Basic Testing
With Net-SNMP installed on a PC or Linux computer, copy To get the temperature of SFP #1 on card #2 in the frame: all the VF-9000 system MIB files listed above to the default (for other cards, replace the last # with the slot #) MIB directory used by Net-SNMP which is typically either snmpget -m ALL -Os -c public -v1 192.168.1.249... -
Page 11: Technical Specifications
>15 dB at 5 MHz - 1.485 GHz >10 dB up to 3 GHz Mechanical, Environmental Overall Dimensions (LxWxH) 19”L x 7.5”W x 1.75”H (Standard Frame) Module Capacity 9 SFP modules (VF-9000-18-BNC or 18 SFP modulars “VF-900-36-MBNC” Temperature Range -25 to 50°C FAN Power Power Supply Configuration... - Page 12 10 Newton Place Hauppauge, NY 11788 (800)-488-8378 / (516)-671-7278 sales@multidyne.com www.multidyne.com...
