MDN BTR006L User Manual

Bluetooth audio receiver
User's manual
Welcome to use this Bluetooth stereo receiver BTR006L. Please read this
user's manual carefully before use.

Before use

1. About BTR006L

BTR006L is a stereo Bluetooth receiver. You can use a common audio
device with 3.5mm audio in jack for playing any stereo Bluetooth-enabled
device's music after plugging in BTR006L.
The product comes with a built-in rechargeable battery, it can be used for
about 14 hours after being charged fully.

2. System requirements

Audio device with 3.5mm audio input jack, such as speakers, radios etc .
Bluetooth transmitting device supporting A2DP profile, such as
Bluetooth mobile phones, Bluetooth MP3 etc.

3. Overview of BTR006L

1 MFB button — Power on/off, pair, music pause/play
2
Charging jack — DC 5V
3
LED indicator — Indicate current status
4
3.5mm audio input jack — Connect to audio device
BTR006L
1
Before use...............................................................1
1. About BTR006L.......................................................1
2. System requirements...................................................1
3. Overview of BTR006L................................................1
Getting started..........................................................2

1. Charging the receiver...................................................2

2. Turning on/off the receiver............................................2

3. Pairing with Bluetooth devices.......................................3
4. Music playback.........................................................5

5. LED indicator...........................................................5

Care and maintenance.................................................6
FAQs.....................................................................6
Specifications............................................................7
FCC Statement..........................................................8
Getting started
1. Charging the receiver
First time charging:
Please charge the battery fully before first use the receiver.
Low battery：
When you see the red LED flashed once every 20 seconds and hear three
Tones during use, the battery is low battery and needs to be charged.
1. Plug charger or charging cable into the standard AC power socket
2. Plug other end of charger or charging cable into charging port of receiver
RED light on→Charging
RED light off→Finished charging
3. It will take about 3 hours to finish charging
4. If the receiver can't be turned off, you can charge it to turn it off.
Remarks:
Please don't attempt to take out the battery from the speaker, as this might
damage it.
Warning:
1) The battery is recyclable.
2) Batteries (battery pack or batteries installed) shall not be exposed to
excessive heat place, such as sunshine, fire or the like.
2. Turning on/off the receiver
Function Operation
Press and hold MFB button for
Turning on
3～5 seconds
Press and hold MFB button for
Turning off
3～5 seconds
Content
LED indicator
Blue LED is on
for 1 second
Red LED is on for
1 second
2
