INSTALLATION INSTRUCTIONS FOR PART AX-ADGM03
GM Class 2 vehicles 2000-up
The AX-ADGM03 is designed to and MUST be used with the AX-ADBOX1 or AX-ADBOX2 (sold seperately).
Please refer to AX-ADBOX1 or AX-ADBOX2 for 16-pin connector instructions.
BUICK
Allure
2005-2009
Century
2004-2005
LaCrosse
2005-2009
Rainier
2004-2007
Regal
2004
Rendezvous
2002-2007
Terraza
2005-2008
CADILLAC
Escalade
2003-2006*
Escalade EXT
2003-2006*
CHEVROLET
Avalanche
2003-2006*
Cavalier
2000-2005
Colorado
2004-2012
Corvette
2005-2013
Express
2003-2007
Impala
2000-2005
Kodiak
C4500-C8500
2003-2009
Malibu
2001-2003
If only the finest quality will do, then look no further than Axxess products.
AX-ADGM03
APPLICATIONS
CHEVROLET
(continued)
Malibu Classic
2004-2005
Monte Carlo
2000-2005
Silverado
2003-2006*
Silverado Classic
2007*
SSR
2003-2006
Suburban
2003-2006*
Tahoe
2003-2006*
Trailblazer
2002-2009
Uplander
2005-2008
GMC
Envoy
2002-2009
Canyon
2004-2012
Savanna
2003-2007
Sierra
2003-2006*
Sierra Classic
2007*
TopKick
C4500-C8500
2003-2009
Yukon/XL/Denali
2003-2006*
HUMMER
H2
2003-2007
HUMMER
(continued)
H3/H3t
2006-2010
ISUzU
Ascender
2003-2008
H-Series
2003-2008
I-Series
2006-2008
OLDSMOBILE
Alero
2001-2004
Bravada
2002-2004
Intrigue
2002
PONTIAC
Aztec
2001-2005
Grand Am
2001-2005
Grand Prix
2004-2008
Montana SV6
2005-2006
Sunfire
2000-2005
SAAB
9-7x
2005-2009
SATURN
Relay
2005-2007
Accept no compromises, choose only quality OE integration interfaces.
INTERFACE COMPONENTS
• 22-pin to 24-pin and 12-pin GM harness
• 4-pin to 4-pin resistor pad harness
TOOLS REQUIRED
• Cutting tool • Tape • Crimping tool
• Connectors (i.e. butt-connectors, bell caps, etc.)
* These vehicles have a digital amp option. Please refer
to the RPO list located in the glove box and if code Y91
appears you have a digital amplifier.
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
