Edwards Signaling AdaptaBeacon 104 Series Installation Instructions Manual

Cheshire, CT 06410 203-699-3300 (Ph)
203-699-3365 (Cust. Serv. Fax)
203-699-3078 (Tech. Serv. Fax)
Description
The 104 Series AdaptaBeacon is a UL and cUL listed signaling
appliance in a NEMA 4X and IP65 rated enclosure. CE Marked.
The modules can be panel mounted or conduit mounted.
AdaptaBeacon modules are available in Flashing LED
(104FLED), Steady-On LED (104SLED), Flashing Halogen
(104FINH), Steady-On Halogen (104SINH) or Flashing Strobe
(104ST). The maximum capacitor operating temperature (Tc) is
185°F (85°C).
The modules are available in a variety of colors as listed in
Table 1.
Catalog
Number Voltage
104FLED(*)-G1 24V DC
104FLED(*)-N5 120V 50/60 Hz
104SLED(*)-G1 24V DC
104SLED(*)-N5 120V 50/60 Hz
104FINH(*)-G1 24V DC
104FINH(*)-G5 24V 50/60 Hz
104FINH(*)-N5 120V 50/60 Hz
104SINH(*)-G1 24V DC
104SINH(*)-G5 24V 50/60 Hz
104SINH(*)-N5 120V 50/60 Hz
104ST(*)-N5 120V 50/60 Hz
*Letter in this position signifies color of the lens. For available colors, see
Table 1.

Specifications

WARNING
To prevent electrical shock, ensure that power is
turned off before installing the signal.
Installation
Conduit Mounting (Figure 1)
1. Thread the 18" (45.7 cm) signal wire leads through either
1/2" (13mm) or 3/4" (19 mm) conduit into an approved
conduit outlet box. (Product is supplied with a double
threaded - 1/2" (13mm) internal and 3/4" (19mm) external -
conduit hub.)
2. Wire the beacon as follows:
a. For AC models, use wire nuts (not supplied) and connect
the signal's black and white wire leads to the power source
wires as shown in Figure 1. Polarity is not relevant.
b. For DC models, connect the signal's red wire to the
positive power source wire and connect the signal's black
wire to the negative power source wire using wire nuts
(not supplied). Polarity must be observed. Refer to
Figure 1.
Installation Instructions for 104 Series AdaptaBeacon
Modules in NEMA 4X Enclosures
Illumination
Current Source
0.062 A 28 LED Cluster
0.022 A 28 LED Cluster
0.062 A 28 LED Cluster
0.022 A 28 LED Cluster
0.77 A 9W Halogen Bulb
0.77 A 9W Halogen Bulb
0.25 A 12W Halogen Bulb
0.77 A 9W Halogen Bulb
0.77 A 9W Halogen Bulb
0.25 A 12W Halogen Bulb
0.12 A Xenon Strobe Tube
WARNINGS
To avoid risk of injury, install lens before energizing
the unit.
To avoid the risk of injury, do not remove or insert
lamp when unit is energized.
3. Thread the conduit onto the base of the signal.
4. Turn on power and verify that the signal operates properly.
Panel Mounting (Figure 2)
Note: The integrity of the outdoor, NEMA 4X, and IP65 rating
on the panel assembly at the interface with the 104 Series
AdaptaBeacon relies on the construction and configuration de-
tails of the mounting surface. Installer should evaluate.
1. Place the mounting gasket (supplied) over the hole in the
panel and route the signal wires through the gasket and the
hole in the panel.
2. Insert the base through the hole in the panel and screw the
locking nut (supplied), with the raised locking edge facing
the mounting surface, onto the base to secure the beacon.
3. Wire the beacon as follows:
a. For AC models, use wire nuts (not supplied) and connect
the signal's black and white wire leads to the power source
wires as shown in Figure 2. Polarity is not relevant.
b. For DC models, connect the signal's red wire to the
positive power source wire and connect the signal's black
wire to the negative power source wire using wire nuts
(not supplied). Polarity must be observed. Refer to
Figure 2.
4. Turn on power and verify that the signal operates properly.
®
P-047550-1848 ISSUE 6 © 2003
