Summary of Contents for Sintrones VDM-804
- Page 1 USER’S MANUAL 8.4-INCHES TFT TOUCHSCREEN USER’S MANUAL V.LH01...
-
Page 2: Table Of Contents
INDEX CONTENT PAGE Features Specification Installation Notice Video Control Keys Video Remote Controller Function Content of OSD Function 13~15 Content of VGA Function 16~18 Language Table of OSD Menu VGA Mode Support List Replacing Batteries Of Remote Controller Standard Package... -
Page 3: Features
1. Features: . Touch Screen, No need mouse for use . Multi Language OSD in English, Spanish, French, German, Italian. . High Contrast 600:1 . Three Video Inputs . One VGA Input . Two Audio Inputs(Stereo) . USB Interface . LED backlight with low power consumption . -
Page 4: Specification
2.Specification: 8.4-INCH TFT LCD COLOR VIDEO MONITOR Resolution 800 (V) x R.G.B. x 600 (H) Display Size 8.4-Inch TFT Active Area(mm) 170.4(H) x 127.8(V) Brightness (cd/m2) Contrast Ratio 600:1 Drive System Active Matrix Back Light Video Input Composite Video Signal 1 Vpp 75Ω Video Input System NTSC/PAL/SECAM Auto Switching Dot Pitch... -
Page 5: Installation 5~9
3. Installation Step 1: Wire Connection 1. Yellow RCA Jack: Video 1 2. Black RCA Jack: Video 2 3. Blue RCA Jack: Video 3(For Reversing Camera, when you shift the reverse gear, the camera image will be shown on the screen automatically) 4. - Page 6 Step 2: a) Install the CD Disk of the software into your PC first b) Select the “TouchKit” function from your PC c) Select the Interface to be USB mode d) Select the Language what you want: English, Traditional Chinese, Simplified Chinese, Japanese, Spanish, French, German, Korean e) Select the “4 PTS CAL”...
- Page 7 g) Draw test: when you finish the 4 Pts Cal correction, you can select the draw test and drawing on the screen for testing that if your screen can feel you touch. h) Advance: if you feel the 4 Pts Cal is not good enough for you, you can select the advance function for 25 Pts Cal correction.
- Page 8 Step 3: VESA Stand Assembly Instruction Rear Enclosure Steps: 1) Screw 4 screws with the VESA hole of rear enclosure together. Adjust the screen angle 2) Screw this part into the plate.(for adjust the screen angle) 3) 3M adhesive sticker for fix on the dashboard or suitable place.
- Page 9 Finished...
-
Page 10: Notice
***** NOTICE ***** 1) Please calibrate the Touchscreen with the Touchkit-utility after the Touchscreen drivers have been installed. If you do not calibrate the Touchscreen, it might not work properly and can be inaccurate. (Please Refer To The Step 2 Of the User Manual) ***** Hinweis ***** 1) Bitte kalibrieren Sie den Touchscreen im... -
Page 11: Video Control Keys
4. Video Control Keys: 1. IR receiver 2. POWER: power ON/OFF & Video 1,2, VGA Mode selection. 3. Dimmer: Adjust the Dimmer range(3 levels, by manual) 4. MENU: Show menu list of function and make selection. : Increase +) the rating of the function that you selected. : Decrease -) the rating of the function that you selected. -
Page 12: Video Remote Controller Function
5. VIDEO Remote Controller Function: POWER: Power On/Off Function. : MUTE MENU: Show Function Menu List and make Selection. － : Decrease the rating of the function you selected. ＋ : Increase the rating of the function you selected. S: Adjust the screen aspect ratio at 16:9 or 4:3 mode AV: Video Selection. -
Page 13: Content Of Osd Function
6. Content of OSD Function OSD MENU LIST BRIGHTNESS: Adjust the brightness of screen. Adjust area: 0~100 CONTRAST: Adjust the contrast of screen. Adjust area: 0~100 COLOR: Adjust the color of screen. Adjust area: 0~100... - Page 14 HUE: Adjust HUE function. Adjustment area: 0~100 H-POSITION Adjust Horizontal Position Adjust area:0~100 V-POSITION: Adjust Vertical Position Adjust area: 1~100 ZOOM: Adjust Ratio Position Adjust Type: 16:9 /4:3 RESET: Return to origin default value EXIT: Save the value you set & Exit Function OPTION: For setting more functions (Please see next page)
- Page 15 VIDEO OPTION Functions: Volume: Adjust volume from 0-100 Mute: Select Audio On/Off Dimmer: Select Auto Dimmer/Bright/Dark/Normal CCD Mirror: Select CCD Mirror On/Off Language: 5 languages of OSD in English, Spanish, French, German, Italian. Exit: Save the value you set and Exit to last menu mode.
-
Page 16: Content Of Vga Function
7. Content of VGA Function VGA MENU LIST AUTO ADJUST Adjust the screen vertical & horizontal position BRIGHTNESS: Adjust the brightness of screen. Adjust area: 0~100 CONTRAST: Adjust the contrast of screen. Adjust area: 0~100... - Page 17 PHASE: Adjust the Phase control. Phase adjustment may be required to optimize the display quality. CLOCK: Adjust the full screen by manual (H & V screen size) H-POSITION: Adjust Horizontal Position Adjust area:0~100 V-POSITION: Adjust Vertical Position Adjust area: 1~100 ZOOM: Adjust Ratio Position Adjust Type: 16:9 /4:3...
- Page 18 OPTION: Setting more functions in VGA mode Option Menu List of VGA mode Volume: Adjust volume from 0-100 Mute: Select Audio On/Off Dimmer: Select Auto Dimmer/Bright/Dark/Normal R_TEMP: Adjust RED Color Range from 0-100 G_TEMP: Adjust Green Color Range from 0-100 B_TEMP: Adjust Blue Color Range from 0-100 CCD Mirror: Select CCD Mirror On/Off LANGUAGE: English, Spanish, French, German, Italian.
-
Page 19: Language Table Of Osd Menu
Language Table of OSD Menu... -
Page 20: Vga Mode Support List
VGA Mode Support... -
Page 21: Replacing Batteries Of Remote Controller
8. Replacing Batteries of Remote Controller (1) Always use new batteries when replacing the old set. (2) Do not attempt to charge, short-circuit, disassemble, hurt or burn used batteries. (3) Battery replacement is necessary when remote controller acts sporadically or stops on the remote controller (4) Do not drop, apply shock or stop on the remote controller (5) Do not spill water on the remote controller (6) Do not place objects between the remote controller and... -
Page 22: Standard Package
9. STANDARD PACKAGE: . Metal or VESA Stand x 1 . All-In-One Cable (Power x 1, Video x 3, Audio x 2, 15Pin D-Sub USB Cable) x 1 . TouchKit Driver x 1 . Remote Controller With Battery x 1 .
