Summary of Contents for Schertler arthur
- Page 1 ACOUSTIC FIDELITY USER MANUAL Assembling instruction on ART48-L/Rmast manual...
- Page 2 WARNINGS PRECAUTIONS WARNINGS Read carefully this manual and follow these precautions before operating the device Keep this manual for possible future needs Pay attention not to pour liquids onto the device and do not operate in conditions of excessive humidity Do not install the device close to sources of excessive heat, do not expose it to direct solar radiation and do not position it without protection in a dusty environment Be sure that the main voltage does not exceed the value indicated on the back panel...
- Page 3 ART48 - AUXMAST The Arthur AUX master unit is a very fine, high-end, CLASS-A output amp. It has been designed to function as an additional output unit for the L/R master unit, completing your mixer and providing all routings as well as additional output functions. In this respect, the mixer’s entire master section consists of the L/R master unit, the AUX master unit and a...
- Page 4 ART48 - AUXMAST Let’s take a look at the additional functions the AUX master unit adds Arthur to your Arthur mixer. format AUX master It makes sense to install the AUX master unit to the right of the L/R master unit. This way the AUX faders will go from left to right in...
- Page 5 ART48 - AUXMAST knob (9.). Don’t forget to deactivate the TB ON button when you have finished speaking over the talkback!! Using the headphones section is very simple: Connect your headphones to the HP OUT (14.) and adjust the VOLUME knob (13.) to a comfortable sound level. You will hear the music signal from the L/R master independently from the signal level that is determined by the position of the master faders.
-
Page 6: Technical Specs
TECHNICAL SPECS Control Room L/R balanced ¼” jack outputs Output impedance 200 ohm Maximum output level +25dBu (@1kHz ; THD <0.5%) Frequency response (-3dB) 20Hz – 60 kHz Distortion (THD+N; @1kHz) 0.12% -30dBu input level 0dBu output level AUX 2, AUX 3 balanced ¼” jack outputs Output impedance 180 ohm Maximum output level... -
Page 7: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE PRESENCE OF UNINSULATED “DANGEROUS VOLTAGE” WITHIN THE PRODUCT ENCLOSURE THAT MAY BE OF A SUFFICIENT MAGNITUDE TO CONSITUTE A RISK OF ELECTRIC SHOCK TO PERSONS. - Page 8 “COMMON SENSE” AND THUS, MISUSE OF OUR PRODUCTS ARE NOT COVERED UNDER RIGHTS OBTAINED THROUGH OUR WARRANTY POLICY OR THAT OF INTERNATIONALLY RECOGNIZED TERMS AND CONDITIONS. SCHERTLER SA IS CONSTANTLY AIMING TO IMPROVE ITS RANGE OF PRODUCTS THEREFORE, SCHERTLER SA RESERVES THE RIGHT TO AMEND PRODUCT SPECIFICATIONS WITHOUT NOTICE.
