DRAG SPECIALTIES 2130-0006 Installation Instructions

INSTALLATION INSTRUCTIONS
ATTENTION INSTALLER (if other than owner):
Please forward this instruction sheet to the purchaser
of this product. These instructions contain valuable
information necessary to the end user.
INTRODUCTION: These instructions describe the
procedure for properly installing this CB antenna
on the GL1800.
Review instructions carefully before beginning, as
they contain important information. Please retain for
future reference.
Particularly important information is distinguished
in these instructions by the following notations:
NOTE: A NOTE provides key information to make
procedures easier or clearer.
CAUTION: A CAUTION indicates special procedures that
must be followed to avoid damage to the motorcycle and/
or accessories.
WARNING!: A WARNING indicates special procedures
that must be followed to avoid injury to a motorcycle
operator or person inspecting or repairing the motorcycle.
TOOLS REQUIRED:
1 / " pilot drill bit, 3 / " drill bit, drill motor
8 8
10mm socket and ratchet
14mm open end wrench
#2 Phillips screwdriver
Torque wrench
2mm & 4mm hex key wrenches (included)
PROCEDURE:
1. Place motorcycle on the center stand on a firm, level surface.
2. Remove seat by removing the two bolts that hold each of
the passenger grips to the seat. Grasp seat and pull up
and to the rear to remove.
3. Open trunk lid and remove the four screws that retain
the left trunk side pocket. Set aside.
4. Once the side pocket is removed, locate the two "+" marks
on the left inside of the trunk. They should be approximately
directly across from where the right antenna is mounted.
5. Carefully drill a pilot hole in the center of both "+" marks.
These two holes should be approximately 2
6. Measure the halfway point between the two pilot holes,
1
or about 1 / " down from the top hole.
8
7. Drill a pilot hole in this location also.
8. Carefully enlarge all three pilot holes to
9. Remove the front left bolt holding the trunk to the bike.
Retain this bolt for re-installation later.
NEW 6/2008
10. Run the antenna wire through the center
11. Re-insert the front left trunk bolt through the antenna stay,
12. Carefully torque the two antenna base bolts to 10 foot-lbs.
13. Install the left side pocket, routing the antenna wire through
1 / " apart. CAUTION: Route the antenna wire under the frame members
4
and take care to not pinch the wire between the frame and seat.
Secure the wire so it cannot move.
14. Install the four screws that hold the side pocket to the trunk.
15. Insert the top half of the antenna mast into the lower half
3
/ ".
8
16. Screw the antenna mast onto the antenna
DRAG SPECIALTIES
3501 Kennedy Rd, PO Box 5222, Janesville, WI 53547-5222
P/N 2130-0006
DRAG SPECIALTIES
CB ANTENNA
P/N 2130-0006
mount the antenna to the trunk by inserting the two
shouldered bolts through the antenna stay, through the
trunk and into the antenna base. Hand tighten only for now.
and trunk. Tighten to 20 foot-lbs.
the hole in the side pocket down under the seat and
connect to the CB.
and secure with the two setscrews.
base as far as possible.
3 / " hole and
8
Page 1 of 2
