Dimensional Tolerances
Dimension
> 0.5 to 3 > 3 to 6 > 6 to 30 > 30 to
> 120
>400
in mm
120
to 400
to
1000
Tolerance ± 0.1
± 0.1
± 0.2
± 0.3
± 0.5
± 0.8 ± 1.2
Angular Tolerance
Angle
... 10
> 10 to
>50 to
> 120
50
120
to 400
Tolerance ± 1 °
± 30'
± 20'
± 10'
> 1000
> 2000
> 4000
> 8000
to 2000
to 4000
to 8000
to
12000
± 2
± 3
± 4
