Eibach Multi-Pro R1 Installation Instructions Manual

Installation Instructions
Eibach Springs, Inc. • 264 Mariah Circle • Corona, California 92879-1751 • USA • Tech Support 800-222-8811 Ext 114
Eibach Multi-Pro R1 Coilovers - #8598.712
2006-2011 Volkswagen, GTi, 2.0L Turbo
2005-2010 Volkswagen, Jetta V, 2.0L Turbo, 2.5L 5cyl.
2006-2009 Volkswagen, Golf V/Rabbit, 2.5L 5cyl.
Kit Contents Description
Front Coil Over Assembly
Rear Damper
Rear Main Spring
Perch, Rear
Perch, Rear Threaded
Height adjustment tool
Rebound adjustment tool
NOTES: Read All Instructions Before Beginning Installation
•
Installation of a Eibach Multi-Pro Coil-Over set should only be performed by a qualified mechanic
experienced in the installation and removal of suspension componentry.
•
Use of a hoist is highly recommended and will substantially reduce installation time.
•
Never work on or under a vehicle unless it is properly supported by safety stands and wheels are blocked.
•
Never use impact wrenches or guns to install or remove shock absorber piston components, shafts and
piston rod nuts.
•
After installation, it is always important to inspect and adjust the following if necessary:
- Wheel alignment such as camber, caster & toe.
- Tire and/or wheel fender clearance.
- Brake line clearance and attachments.
- Brake anti-locking and anti-skid system sensors.
•
Alignment: After installation, you will need a full vehicle alignment to ensure proper tire wear and
performance.
•
Height Adjustment – Should be performed with the wheels completely off the ground and with the springs
fully unloaded.
Tightening torque for piston rod nut
Thread Size Nm
M8
M10 x 1.0
M10 x 1.25
D2747Rev2
ft-lb Thread Size
25 18 M12 x 1.25
20 15 M12 x 1.50
20 15
www.eibach.com
Part Number Qty
8598.8500 2
8598.8600 2
0800.250.0300 2
8000155 2
8000084 2
PDK.TOOL 1
PDR.TOOL 1
Nm ft-lb Thread Size
35 26 M14 x 1.50
40 29 M16 x 1.50
Nm ft-lb
50 37
50 37
Page 1
