INSAFE Origin Instruction Manual

1. RECOMMENDED PLACES TO MOUNT THE DETECTOR
Depending on the layout and the surface area of the dwelling, several smoke detectors may be required to ensure minimum
Smoke detector protection and guarantee efficient detection, the range of the alarm and quick evacuation of the dwelling.
INSTRUCTION MANUAL
 Recommended installation
Please read this instruction manual carefully before use!
The documentation supplied with this product must be retained throughout its service life..
INSAFE+
Control
Product model: I740SX
INSAFE
Origin
Product model: I730FW
Standard installation
INSAFE Origin and INSAFE+ Control are Smoke Detection and Alarm Devices for household use. - on each floor
- in hallways and/or stairwells
A smoke detection and alarm device is a product designed to give off an audible signal to warn that a fire has started.
- between rest areas (bedrooms), the possible ignition sources
The detector will only trigger the alarm in due time if it is properly located, installed and maintained in accordance with the
(garage, area with a high electrical system, etc.) and exits
instructions in this manual.
leading outside of your home (door, window)
INSAFE Origin and INSAFE+ Control are designed and manufactured by NEXELEC, 67 COURS MIRABEAU
13100 AIX-EN-PROVENCE FRANCE
It is recommended to install smoke detectors:
- less than 7 m from possible ignition sources
16 - less than 7 m from rest areas (3 m if the doors are closed)
EN14604:2005/AC:2008 - less than 7 m from exits
1922-CPR-0582 D232E_EN
Notice D232E_EN.indd 1
Locate the detector in line with the current building standards.
Ceiling mounting:
CEILING
Install the detector to the ceiling in the centre of the room,
minimum 30 cm from corners, walls, beams or any other obstacles.
 Standard installation
Wall mounting:
Install the detector to the wall at a distance ranging between Compliant
location
30 cm and 60 cm from the ceiling.
Mounting on a sloped ceiling:
Bathroom
Kitchen
Install the detector at a distance ranging between 30 cm
Bedroom
Living room
and 60 cm vertically from the highest point of the ceiling.
Dining room
Bedroom
Bedroom
Recommended installation
Place a detector:
- on each floor, every 7 m
- in each stairwell per level
2. PLACES TO BE AVOIDED
- in each room (1 for 50 m²), except in the kitchen
and the bathroom (refer to paragraph 2: Places to Do not install the smoke detector:
be avoided)
 Outside  In a place where the alarm will be difficult to hear (room with closed door)  In a place where the detector
will be difficult to reach, in particular to perform tests  In a place where the temperature is lower than 4°C or higher than
45°C  In a place where humidity is less than 10% or exceeds 95% (bathroom, kitchen, laundry room, etc.)  In a place
subject to high and/or rapid temperature, pressure or humidity variations  In a place where the sunlight hits directly on the
detector  In a dusty or dirty area (garage, workshop, etc.)  In a place where there are a lot of insects  In a place where
spurious smoke may disturb the smoke detector: kitchen, chimney, garage (exhaust gas), furnaces, boiler rooms, combustion
radiators, etc.  Close to heating appliances, windows, ventilation ducts, air conditioners, fans or any other item of equipment
that may produce air flows  Close to an area that is hotter or cooler than the rest of the room (non-insulated walls, hatches,
30 cm
etc.)  Less than 1.5 m from obstacles preventing the smoke from accessing the detector (decorative objects, walls, doors,
min.
plants, chandeliers, curtains, etc.)  Less than 1.5 m from lighting appliances (ceiling light, incandescent lamps, halogen or
fluorescent lamps, etc.)  Less than 1.5 m from electrical appliances or their wiring.
NEVER
30 cm
HERE
min.
3. INSTALLATION
60 cm
max. Commissioning the smoke detector
Comply with the following commissioning procedure:
 Activate the single-use switch (1)
WALL
(1)
 Wait a few seconds then press the button of the detector for 3 seconds until
the alarm sounds, then release it for the alarm to stop (2)
The detector initialises for 10 minutes. At the end of the 10 minutes,
30 cm
the detector is operational. The red diode will then flash every 5 and
NEVER min.
HERE
a half minutes indicating that the detector is working properly.
60 cm
Mounting the smoke detector
max.
The screws and wall plugs supplied with the detector should preferably be used
(2)
to mount your smoke detector.
WALL
Comply with the following procedure:
 Select an appropriate location on the ceiling or the wall to mount the detector
 Remove the mounting base (3)
 Use a pencil to mark the screw holes in the intended place on the ceiling or the wall
 Drill two holes to match the screws with equipment suited to the type of ceiling
 Insert the nylon wall plugs supplied
 Clean the area with a dry cloth to remove any dust
(3)
 Screw the mounting base into the ceiling(4)
The drawing inside the mounting base shows how to position
6. PRECAUTIONS AND LIMITS OF USE
the detector across from its mounting base and the final position
For your safety, please comply with the following measures:
of the detector once it is clipped in
 You must follow all instructions in this manual. Please bear in mind that it may be dangerous to mute or switch off the
 Place your detector on the mounting base by aligning the single-use switch with
detector or to refuse to replace your detector when specified by the manual.  Do not install the detector in one of the
the circular hole of the mounting base (5)
situations described in paragraph 2 "Places to be avoided". Do not paint or cover the detector. Do not block the detector
 Turn it slightly towards the right. The detector must fit into the mounting base
openings.  Do not disassemble, modify or damage the detector.  Do not place bare ignition sources such as lighted candles
(4)
 Turn the detector by a quarter turn towards the right to clip it in: you must hear
underneath the detector.  The detector must remain in place at all times.  The detector is not a transportable product.  To
a click indicating that your detector has been properly secured into
avoid accidents, the detector must be safely secured to the ceiling or wall in accordance with the installation instructions. 
its mounting base (6)
The detector is unable to detect fires outside of the dwellings.  The detector will not be able to detect a fire if an insufficient
 Make sure that your detector is completely secured to the ceiling
quantity of smoke reaches the detector sensor (smouldering fire, fire too far away, etc.). It is recommended to install several
detectors for optimum safety.  The detector cannot be used for people who are hearing impaired.  The manufacturer recom-
mends a monthly maintenance of the detectors.  It is dangerous to suspect a false alarm as the smoke preceding the onset
4. BATTERY
of the flames are toxic and may cause you to lose consciousness: despite the absence of flames, a fire may blaze up in a few
(5) minutes.  If false alarms are frequent, you may need to change the location of your detector and move it further away from
The smoke detector has a maximum service life of 10 years. Beyond this limit,
it will no longer operate at peak efficiency. Your detector and its remote control the sources of false alarms.  The maximum date of commissioning must not exceed 5 years after the date of manufacture
"clic"
affixed to the detector.  The detector must not be used after the maximum specified use-by date: the maximum use-by date
are fitted with a high-performance battery that has a duration of 10 years*. This
battery cannot be replaced. The detector and the remote control are sealed and is equal to the date of manufacture affixed to the detector + 10 years.  The detector must no longer be used and must be
replaced subsequent to a fire or after a significant amount of smoke or under abnormal conditions.
will operate throughout their entire service life The end of the battery life means
that you must change your detector and/or remote control.
The detector is designed to have a service life of 10 years* enabling it:
 To detect fires for 10 years  To power the alarm signal for 4 minutes at 85 dB.  To perform weekly tests for 10 seconds.
5. MAINTENANCE (6)
 To indicate that the battery is low via an audible signal for 30 days.
Clean the detector every month:
The detector is designed to operate in a normal household environment:
 Remove dust from the detector with an antistatic cloth or with the brush end-fitting of your vacuum cleaner
 Temperature: 15°C to 35°C.  Humidity: 25% to 75%.  Atmospheric pressure: 86 to 106 kPa.
 Clean the upper edges of the detector with an antistatic cloth
 Immediately remove any insect, spider web or dust accumulated around your detect
The detector may be used in an exceptional household environment:
CAUTION: Do not use a compressed air spray or equivalent  Temperature ranging between 4°C and 45°C.  Humidity ranging between 10% and 95%.  Recurrent and/or prolonged
use in this exceptional environment may reduce the battery life and consequently the service life of the detector..
