T R A C K V O I D M O N I T O R
Sensor
Plug
Sensor
Clamp
Gaiter
Foot
Shoulder
End Clamp
Base Plate
1. VoidMate Glossary.
3. Ensure the VoidMate base is flush under the rail.
The bracket should sit on the foot of the rail as shown.
5. Tighten the bolts on the clamp repetitively and alternatively
using the M10 Allen key until secure.
24/7 Helpline:
0845 600 2511
Solar Panel
On / O Switch
2. Create a small void in the ballast between sleepers and slide
the VoidMate under the rail.
4. Slide clamp over the foot of the rail.
6. Fit sensor loosely to side of VoidMate.
