300 Mbps PTP600 SERIES
4.9-5.8GHz MIMO Bridge Point to Point Kit
Two Netkrom AIRNET Outdoor Bridge Units
Two Mounting brackets (include: 2 Wall/ Pole
mounting system and 4 screw nuts)
Two PoE Injectors
Package Contents:
Two Power Cables
Two RJ45 Waterproof Connector System
Quick Installation Guide
CD-ROM
Two 75' Outdoor Rated Cat5e shielded cables
Advertisement
Table of Contents
Related Manuals for airnet PTP600 series
Summary of Contents for airnet PTP600 series
- Page 1 300 Mbps PTP600 SERIES 4.9-5.8GHz MIMO Bridge Point to Point Kit Two Netkrom AIRNET Outdoor Bridge Units Two Mounting brackets (include: 2 Wall/ Pole mounting system and 4 screw nuts) Two PoE Injectors Package Contents: Two Power Cables Two RJ45 Waterproof Connector System...
-
Page 2: Installation
Following installation, access to the unit should be password protected by the network administrator to maintain regulatory compliance. The AIRNET Outdoor Bridge Point to Point kit and PoE injector can be damaged by incorrect power application. Read and carefully follow the installation instructions before connecting the system to its power source. -
Page 3: Package Contents
Guide Installation 300 Mbps PTP600 SERIES Package contents Take a moment to ensure that you have all of the following parts in your Outdoor Waterproof Unit installation kit before you begin installing the product. If any parts are missing, please contact your local vendor or contact us, please see the contact information in Section 6. -
Page 4: Setup Requirements
Hardware Guide Installation 300 Mbps PTP600 SERIES Setup Requirements Before starting, please verify that the following is available: CAT5/5e or FTP Outdoor Ethernet cable (from the PTP to PoE Injector). At least one computer is installed with a Web browser and a wired or wireless network interface adapter. - Page 5 Quick Installation Hardware Guide Installation 300 Mbps PTP600 SERIES AIRNET Outdoor Bridge Point to Point Installation Step 1: Connect one end of your UTP or FTP Outdoor cat.5 Ethernet cable with waterproof connector to the RJ-45 connector located in the PTP unit. Then connect the other end of the cable to the PoE injector.
- Page 6 Now, turn on your power supply. Notice that the POWER LED has lighted up. This indicates that the PTP unit is receiving power through the Netkrom PoE Injector and that connection between your AIRNET PTP unit and your network has been established.
- Page 7 Do not tighten the screws all the way because you will need to adjust the AIRNET PTP direction in a later step. Mount the AIRNET PTP to the top of the pipe or other support and point the AIRNET PTP in the approximate direction of the base station antenna, then hand-tighten the nuts on the mounting system.
- Page 8 PTP600 SERIES uConfig is a feature that provides the ability to directly access the AIRNET PTP without the need to know absolutely its IP address. It may be run directly from the product CD or installed on the user’s PC for later access.
- Page 9 Quick Installation uConfig Guide Utility 300 Mbps PTP600 SERIES Click the OK button to continue At the login prompt, enter the User name and Password. The default are: User name: admin Password: password Click on OK and start configuring the radio.
- Page 10 PC and the AIRNET PTP, by default the AIRNET PTP has the IP address 192.168.168.1. Therefore, your PC must be in the same network segment as the AIRNET PTP in order to get Ethernet connectivity. The steps shown below are for Windows XP.
-
Page 11: Getting Started
Guide Configurations 300 Mbps PTP600 SERIES Find below typical and basic configurations using the AIRNET PTP. For advanced features please refer to the user manual. Getting Started You can start configuring your AIRNET PTP using either your Web Browser or the uConfig utility. - Page 12 300 Mbps PTP600 SERIES Wireless Point to Point Setup The AIRNET Outdoor Bridge Point to Point Kit is commonly used in Point-to-Point Applications. You can implement a Point-to-Point connection by simply setting one access point in Access Point mode and setting the other access point in Station Mode (client).
- Page 13 Installation Common Guide Configurations 300 Mbps PTP600 SERIES Follow these steps to setup Sation Mode. Click on the Basic Wireless Tab. In wireless mode choose Station. Enter the name of the Remote AP-ESSID. Note: this option must match with the ESSID configured in the Access point.
- Page 14 Quick Installation Advanced Guide Configuration 300 Mbps PTP600 SERIES Wireless with Router Mode: Advanced Settings: Please go to page 69 of User Manual. Please go to page 74 of User Manual. Advanced Wireless Configuration: Wireless Security Setup: Please go to page 44 of User Manual.
- Page 15 Quick Installation Guide 300 Mbps PTP600 SERIES Congratulations With these basics steps you can enjoy your wireless link without problems, please for more information about the capabilities and advance configuration of our product please see the user manual. High Capacity Wireless Networks...
-
Page 16: Contact Information
Quick Installation Guide 300 Mbps PTP600 SERIES Contact Information Address: 2134 NW 99th Avenue, Miami Florida 33172 Phones: (+1) 305-418-2232 Fax: (+1) 305-418-9266 Sales and ordering: American Customers: salesusa@netkrom.com Worldwide Customers: sales@netkrom.com Latin American and Spanish Customers: ventas@netkrom.com Technical Support: Worldwide and English Customers: support@netkrom.com... - Page 17 300 Mbps CPE600 SERIES...
