Automotive Data Solutions BLADE-AL-TL5-EN Install Manual

Toyota scion, blade series
Hide thumbs

Advertisement

Quick Links

Download this manual
Automotive Data Solutions Inc.
INSTALL GUIDE
BLADE-AL(DL)-TL5-EN
AvAiLABLE for : ADS-BLADE AL
Rev. Date: December 05, 2012
Doc. No.: ##10213##
20121130
VErSIoN FrANçAISE DISpoNIbLE EN LIGNE AU www.BLADEUPTADE.com
pLEASE VISIT www.BLADEUPDATE.com For compLETE proDUcT DETAILS
The brand names and logos found in this guide are property of their respective owners. Automotive Data Solutions Inc. © 2012
!
NOTICE: The manufacturer will accept no responsibility for any electrical damage resulting from
improper installation of this product, be that either damage to the vehicle itself or to the installed
device. This device must be installed by a certified technician. This guide has been written for
properly trained technicians; a certain level of skill & knowledge is therefore assumed. Please
review the Installation Guide carefully before beginning any work.
TL5

Advertisement

loading
Need help?

Need help?

Do you have a question about the BLADE-AL-TL5-EN and is the answer not in the manual?

Questions and answers

Related Manuals for Automotive Data Solutions BLADE-AL-TL5-EN

Summary of Contents for Automotive Data Solutions BLADE-AL-TL5-EN

  • Page 1 VISIT www.BLADEUPDATE.com For compLETE proDUcT DETAILS The brand names and logos found in this guide are property of their respective owners. Automotive Data Solutions Inc. © 2012 NOTICE: The manufacturer will accept no responsibility for any electrical damage resulting from improper installation of this product, be that either damage to the vehicle itself or to the installed device.
  • Page 2 • • • • Yaris Sedan Regular key (80 bit) 11-12 9 • • • • • • • • • • • *Available only if vehicle is equipped with factory hood switch. www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...

  • Page 3: Component Locator

    All in one INSTALL GUIDE Scion/ToyoTa Guides Français disponibles au www.bLADEUpDATE.com BLADE-AL(DL)-TL5-EN Page 3 of 27 20121130 Doc. No.: ##10213## COmPOnent LOCatOr COmPOnent LOCatOr www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 4 This key is NOT compatible with This key is compatible with this this fi rmware. fi rmware. Use a compatible fi rmware Proceed with installation. solution. www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 5 Ignition connector Accessory White 08 pin 03 Gray Ignition connector Starter 1 White 08 pin 01 White Ignition connector Starter 2* White 08 pin 08 Black Ignition connector * With 2.4L engine only. www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 6 Ignition connector Accessory White 08 pin 03 Red Ignition connector Starter 1 White 08 pin 01 White Ignition connector Starter 2 White 08 pin 08 Yellow Ignition connector * With 2.4L engine only. www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 7 BLUE/RED (NC) GREEN/RED YELLOW BLUE/YELLOW (NC) GRAY/RED GRAY/YELLOW GREEN/RED (NC) GRAY/RED GRAY/RED - GROUND (-) INPUT - GROUND (-) INPUT GRAY/YELLOW (NC) GRAY/YELLOW (NC) BLACK (NC) BLACK (NC) WITHOUT OEM HOOD STATUS ONLY www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 8 White 08 pin 06 Black Ignition connector Accessory White 08 pin 02 White Ignition connector Starter 1 White 08 pin 03 LtGreen Ignition connector Starter 2 White 08 pin 07 Blue Ignition connector www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 9 STATUS ONLY 19 20 21 22 23 24 25 26 27 28 29 30 7 8 9 10 11 12 13 14 15 16 17 18 1 2 3 4 5 6 WHITE CONNECTOR www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 10 Ignition connector Ignition 2 D109 White 08 pin 06 Pink Ignition connector Starter 1 D109 White 08 pin 07 Green Ignition connector Starter 2 Accessory D109 White 08 pin 02 Blue Ignition connector www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 11 STATUS ONLY 19 20 21 22 23 24 25 26 27 28 29 30 7 8 9 10 11 12 13 14 15 16 17 18 1 2 3 4 5 6 WHITE CONNECTOR www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 12 White 08 pin 04 Green Ignition connector Starter 1 White 08 pin 01 Green Ignition connector Starter 2 White 08 pin 08 Red Ignition connector Accessory White 08 pin 03 Green Ignition connector www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 13 1 2 3 4 5 6 7 8 9 OEM HOOD STATUS ONLY MAIN BODY ECU BACK SIDE 18 19 20 21 22 23 24 25 26 7 8 9 10 11 12 13 14 15 16 17 D50 - WHITE www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 14 01 Black Ignition connector Starter 1 White 08 pin 07 Yellow Ignition connector Starter 2 Accessory White 08 pin 02 Gray Ignition connector Power liftgate Black 05 pin 04 Red At power liftgate switch www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 15 BLUE/RED BLUE/YELLOW BLUE/YELLOW (NC) GREEN/RED YELLOW GREEN/RED (NC) GRAY/RED GRAY/YELLOW GRAY/RED GRAY/RED - GROUND (-) INPUT - GROUND (-) INPUT GRAY/YELLOW (NC) GRAY/YELLOW (NC) BLACK (NC) BLACK (NC) WITHOUT OEM HOOD STATUS ONLY www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 16 08 pin 06 Black Ignition connector Ignition 2 White 08 pin 04 Yellow Ignition connector Starter 1 White 08 pin 08 Red Ignition connector Starter 2 Accessory White 08 pin 03 Blue Ignition connector www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 17 STATUS ONLY 19 20 21 22 23 24 25 26 27 28 29 30 7 8 9 10 11 12 13 14 15 16 17 18 1 2 3 4 5 6 WHITE CONNECTOR www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 18 White 08 pin 06 Black Ignition connector Ignition 2 White 08 pin 01 LtGreen Ignition connector Accessory White 08 pin 02 Gray Ignition connector Starter 1 White 08 pin 07 Green Ignition connector www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 19 BLUE/RED (NC) GREEN/RED YELLOW BLUE/YELLOW (NC) GRAY/RED GRAY/YELLOW GREEN/RED (NC) GRAY/RED GRAY/RED - GROUND (-) INPUT - GROUND (-) INPUT GRAY/YELLOW (NC) GRAY/YELLOW (NC) BLACK (NC) BLACK (NC) WITHOUT OEM HOOD STATUS ONLY www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 20 White 08 pin 06 Black Ignition connector Accessory White 08 pin 02 Gray Ignition connector Starter 1 White 08 pin 07 Green Ignition connector Liftgate White 08 pin 06 Red At liftgate switch www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 21 BLUE/RED (NC) BLUE/YELLOW (NC) GREEN/RED YELLOW GREEN/RED (NC) GRAY/RED GRAY/YELLOW GRAY/RED GRAY/RED - GROUND (-) INPUT - GROUND (-) INPUT GRAY/YELLOW (NC) GRAY/YELLOW (NC) BLACK (NC) BLACK (NC) WITHOUT OEM HOOD STATUS ONLY www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 22 White 08 pin 01 Green Ignition connector Ignition 2 White 08 pin 06 Pink Ignition connector Accessory White 08 pin 02 White Ignition connector Starter 1 White 08 pin 07 Black Ignition connector www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 23 YELLOW BLEU/JAUNE (NC) BLUE/YELLOW (NC) VERT/ROUGE (NC) GREEN/RED (NC) GRIS/ROUGE GRAY/RED GRIS/JAUNE GRAY/YELLOW GRIS/ROUGE (NC) GRAY/RED (NC) GRIS/JAUNE (NC) GRIS/JAUNE (NC) GRAY/YELLOW (NC) GRAY/YELLOW (NC) NOIR (NC) NOIR (NC) BLACK (NC) BLACK (NC) www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 24 08 pin 01 LtBlue Ignition connector Ignition 2 White 08 pin 06 Pink Ignition connector Accessory White 08 pin 02 Blue Ignition connector Starter 1 White 08 pin 07 Green Ignition connector Starter 2 www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
  • Page 25 STATUS ONLY 19 20 21 22 23 24 25 26 27 28 29 30 7 8 9 10 11 12 13 14 15 16 17 18 1 2 3 4 5 6 WHITE CONNECTOR www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...

  • Page 26: Cartridge Installation

    2 seconds. for 2 seconds. Turn key to OFF position. Turn key to OFF position. Turn key to ON position. Turn key to ON position. Module Programming Module Programming Procedure completed. Procedure completed. www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...

  • Page 27: Module Diagnostics

    7,010,402; 7,031,826; 7,046,126; 7,061,137; 7,068,153; 7,015,830; 7,205,679; 7,224,083; 7,369,936; 7,378,945; 7,489,233; 7,501,937; Canadian Patent nO. 2,320,248; 2,415,023; 2,426,670; 2,414,991; 2,415,011; 2,415,027; 2,415,038; 2,415,041; 2,502,893; 2,451,490; 2,452,296; 2,451,487; eUrOPean Patent nO. 1,053,128; de 69807-941T2; U.S. 20020145535; 20060129282; 20060129284; 20040017284; 20080030316; 20090079552; eP1500565; 1538038; 1538037; www.bLADEUpDATE.com Automotive Data Solutions Inc. © 2012...
