- Page 1 CHILDREN PLAYGROUND ASSEMBLY INSTRUCTION Jūrmalas Mežaparki, Ltd. 1 Garkalnes street Jurmala, LV 2011, Latvia...
- Page 2 Overview SK12 SK12 SK12 SK12 WARNINGS: A safety zone must be maintained 500 mm around any playground equipment. This area must be clear from any objects (trees, buildings, fences, rocks, curbs, pools etc.). MAX RECOMMEMDED RECOMMENDED AGE MAX HEIGHT OF HALL CAPACITY 2 - 14 years 0.240 m...
- Page 3 Specification Dimensions Part Quantity SK1-SK8 Beam with planks Plank Plank 2830 BARRIERS Circle SK12 Barrier 1417 SK13 Barrier 1417 ADDITIONAL ELEMENTS Geotextile Jūrmalas Mežaparki Ltd. Version Nr. CHILDREN PLAYGROUND 1 Garkalnes street, ELEMENTS Jurmala Date: 22.07.2015. Name, Surname Signature Page Pages Element drawings Scale Developed by...
- Page 4 Required safety area for the sandbox 4 000 WARNINGS: A safety zone must be maintained 500 mm around any playground equipment. This area must be clear from any objects (trees, buildings, fences, rocks, curbs, pools etc.). Jūrmalas Mežaparki Ltd. Version Nr. CHILDREN PLAYGROUND 1 Garkalnes street, ELEMENTS...
- Page 5 Detail specification SK1-SK8 Quantity- 2 pcs. Quantity- 2 pcs. Plank 2 830 Quantity - 4 pcs. Jūrmalas Mežaparki Ltd. Version Nr. CHILDREN PLAYGROUND 1 Garkalnes street, ELEMENTS Jurmala Date: 22.07.2015. Name, Surname Signature Page Pages Element drawings Scale Developed by Liene Pavlova Detail specification Approved by...
- Page 6 Detail specification Barrier circle Quantity - 4 pcs. Jūrmalas Mežaparki Ltd. Version Nr. CHILDREN PLAYGROUND 1 Garkalnes street, ELEMENTS Jurmala Date: 22.07.2015. Name, Surname Signature Page Pages Element drawings Scale Developed by Liene Pavlova Detail specification Approved by Andris Čuda...
- Page 7 Additional elements specification Geotextile Anchor Quantity - 1 pcs. Quantity - 1 pcs. Quantity - 2 pcs. Jūrmalas Mežaparki Ltd. Version Nr. CHILDREN PLAYGROUND 1 Garkalnes street, ELEMENTS Jurmala Date: 22.07.2015. Name, Surname Signature Page Pages Element drawings Scale Developed by Liene Pavlova Additional elements specification Approved by...
- Page 8 Additional elements specification s28tx 6.0 x 140 DIN1629 5 x 50 DIN1629 5 x 40 Quantity - 8 pcs. Quantity - 28 pcs. Quantity - 20 pcs. DIN1692 5 x 45 DIN1629 5 x 70 Quantity - 4 pcs. Quantity - 4 pcs. Jūrmalas Mežaparki Ltd.
- Page 9 STEP Jūrmalas Mežaparki Ltd. Version Nr. CHILDREN PLAYGROUND 1 Garkalnes street, ELEMENTS Jurmala Date: 22.07.2015. Name, Surname Signature Page Pages Element drawings Scale Developed by Liene Pavlova Assembly step 1 Approved by Andris Čuda...
- Page 10 STEP Comment: The screws must be screwed in the average line of drillhole, in the step C Jūrmalas Mežaparki Ltd. Version Nr. CHILDREN PLAYGROUND 1 Garkalnes street, ELEMENTS Jurmala Date: 22.07.2015. Name, Surname Signature Page Pages Element drawings Scale Developed by Liene Pavlova Assembly step 2 Approved by...
- Page 11 STEP Comment: Geotextile has to be under sandbox at the customer's discretion; Jūrmalas Mežaparki Ltd. Version Nr. CHILDREN PLAYGROUND 1 Garkalnes street, ELEMENTS Jurmala Date: 22.07.2015. Name, Surname Signature Page Pages Element drawings Scale Developed by Liene Pavlova Assembly step 3 Approved by Andris Čuda...
- Page 12 STEP SK12 SK13 SK13 SK12 SK13 SK12 SK12 SK12 SK13 Do not screw in the first drill in the step E Jūrmalas Mežaparki Ltd. Version Nr. CHILDREN PLAYGROUND 1 Garkalnes street, ELEMENTS Jurmala Date: 22.07.2015. Name, Surname Signature Page Pages Element drawings Scale Developed by...
- Page 13 STEP SK12 SK13 SK13 SK12 SK13 SK12 SK12 SK12 SK13 Do not screw in the step E Do not screw in the step E Do not screw in the step E Do not screw in the step E Do not screw in the step E Do not screw in the step E...
- Page 14 STEP Must be leveled ! Jūrmalas Mežaparki Ltd. Version Nr. CHILDREN PLAYGROUND 1 Garkalnes street, ELEMENTS Jurmala Date: 22.07.2015. Name, Surname Signature Page Pages Element drawings Scale Developed by Liene Pavlova Assembly step 5 Approved by Andris Čuda...
