lapara LA-SP7 Quick Manual

Hide thumbs
1
2

Advertisement

Table of Contents

Quick Guide
Surge Protector
___________________________________________________
LA-SP7 (V.1.1 2011)
LA-SP7

1. Introduction

Thank you for purchasing Lapara product. This item is designed to provide surge protection
and power extender for connected devices. With its master-controlled design, the unit
provides energy saving by shutting down unused peripherals. The master outlet is designed to
sense current drawn by connected equipment, usually a computer. When the computer is
shut down, it will shut off power to slave outlets which connect all PC peripherals.

2. Product Overview

Wall Mount the Unit
The unit can be mounted to a wall surface. Please follow below steps:
1. Use tape to hold this page in place against the wall.
2. Use a sharp nail to puncture the center of the two holes to mark the wall. (see below chart 1)
3. Mount the unit by positioning the key-hole slots over the mounting nails. (see chart 2)
__________________________________________________
Master output receptacle (for connecting a
computer)
Uncontrolled output receptacles (for
connecting peripherals)
Slave output receptacles (for connecting
peripherals)
Modem/phone line surge protection
Function switch
Circuit breaker
AC input
Power LED
Master/Slave Function LED
LA-SP7 (V.1.1 2011)
