Summary of Contents for Sensor Therm Polaris PS09
- Page 1 Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 User Manual...
-
Page 2: Table Of Contents
Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 Content Content General ............................... 3 Information to this Manual ......................3 CE Conformity and Standards ....................3 Limitation of Liability ........................3 Terms of Warranty ........................3 Copyright ........................... 3 Explanation of Symbols ...................... -
Page 3: General
Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 General General Information to this Manual This manual enables the safe and efficient use with the device. The manual is part of the instrument and has to be kept in a location where users always have access to. -
Page 4: Explanation Of Symbols
Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 General Explanation of Symbols The following symbols are used in this manual for restrictions, preventive measures and security notes. Please pay attention to this symbols for safety reasons. CAUTION: This combination of symbol and signal word indicates a potentially dangerous situation that can result in minor or moderate injury if not avoided. -
Page 5: Safety
Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 Safety Safety General Any person who is tasked to carry out work with the device must have read and understood the operat- ing instructions before beginning. Operation and maintenance of the system may only be performed by trained personnel. -
Page 6: Electrical Connection
Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 Electrical Connection Electrical Connection Cable Colors and Pin Assignment AK32: Power supply / switching outputs The electrical connection of the Polaris (supply voltage and switch- ing signals) will be done via the connectors on the rear panel. For this purpose, connection cables are available as accessory (see Accessories). -
Page 7: Switching Outputs
Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 Electrical Connection 3.1.2 Switching Outputs +24 V Brown The switching outputs are used to detect if a certain temperature threshold is exceeded or falling below. Max. 30 mA Output White... -
Page 8: Interface Converter (Accessory)
Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 Mechanical Installation 3.1.3.1 Interface Converter (Accessory) Using an interface converter DK3000 or DK4000 (RS232USB or RS485USB) is a quick and easy way to connect the infrared switch to a PC (see Accessories). -
Page 9: Alignment With The Laser Targeting Light
Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 Mechanical Installation 4.3.1 Alignment with the Laser Targeting Light The laser targeting light is a conical red laser beam with the largest diameter directly at the lens and the smallest Focus point and sharpest in the focused distance, i.e. -
Page 10: Spot Size Tables
Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 Mechanical Installation Spot Size Tables The following tables show the optical data of the different device types. The values in the tables are ex- emplary, intermediate measurement distances must be determined by interpolation. If the measuring... -
Page 11: Parameters / Settings
Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 Mechanical Installation Parameters / Settings 4.6.1 Emissivity ε The emissivity indicates the radiation Emissivity [%] Measuring object capacity of an object to be measured PS09 PI16 relative to a calibration source with the Calibration source same temperature. -
Page 12: Response Time T
Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 Mechanical Installation 4.6.2 Response Time t The response time specifies the time that an infrared measuring device requires to track 90% of a sudden temperature change on the signal output. -
Page 13: Configuring Via Sensortools Software
Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 Configuring via SensorTools Software Configuring via SensorTools Software Program Start Starting the software opens the main window of the pro- Select PC Connect with or search gram. The Polaris is not con-... - Page 14 Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 Configuring via SensorTools Software Port test: Enables testing of the outputs by simulating a switching temperature. Specify simulation temperature Start simulation Check output state The simulation automatically stops after 3 seconds.
-
Page 15: Technical Data
Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 Technical Data Technical Data Model PS09 PI16 Temperature ranges 550–1400°C 250–1000°C 650–1800°C 300–1300°C 350–1800°C Spectral range 0.7–1.1 µm 1.45–1.8 µm Switch temperatures Can be set within the limits of the temperature range... -
Page 16: Composition Of The Type Number
Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 Technical Data Composition of the Type Number The equipment version of the Polaris is encoded in the 18-digit model number as follows (Example type number PS09 with 550–1400°C; laser targeting light, 2 switch outputs):... -
Page 17: Maintenance
Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 Maintenance Maintenance CAUTION, switch off supply voltage. Before beginning any maintenance, switch off power supply or pull connector on the Pola- ris to prevent injury by accidentally activated laser targeting light! Cleaning Clean the lens with a soft cloth and a little alcohol or acetone. - Page 18 Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 Communication via Serial Interface / Interface Commands Command Parameter Description / Settings Read reference number (18-digit ASCII sequence) Meaning: see Type number Baud rate (1-digit dec.) X = 0-4, 6...
-
Page 19: Index
Infrared Temperature Switch (Hot Metal Detector) Polaris PS09 / PI16 Index Index Accessories ............16 Laser targeting light .......... 9, 13 Address ..............12 Alignment onto the measuring object ....8 Alignment with the laser targeting light ....9 Maintenance ............17 Ambient temperature .......... - Page 20 Sensortherm GmbH Hauptstraße 123 65843 Sulzbach Tel: +49 (0)6196 64065-80 Fax: +49 (0)6196 64065-89 E-Mail: info@sensortherm.com Internet: www.sensortherm.com © Sensortherm GmbH Polaris_PS09_PI16 (May 11, 2017)
