- Page 1 OPERATION AND MAINTENANCE MANUAL SG10 COD.: MUM0127 REV. 06 SICOR S.p.A. Head Office and Production Centre Viale Caproni 32 (Industrial Area) 38068 Rovereto (TN) Italy Copy of the original file MUM0127_REV06 Italian...
-
Page 3: Table Of Contents
SG10 INDEX LETTER TO THE CUSTOMER ....................2 DESCRIPTION OF THE GEARLESS MACHINE ..............2 2.1. DIMENSIONS/TECHNICAL SPECIFICATIONS SG10 ............3 MACHINE IDENTIFICATION ....................4 WARRANTY ........................5 GENERAL DELIVERY NOTES ....................6 SAFETY PRECAUTIONS .......................7 SAFETY REQUIREMENTS ....................8 MOVING THE WINCH ......................10 NOTES FOR INSTALLATION ....................12 9.1. -
Page 4: Letter To The Customer
SG10 LETTER TO THE CUSTOMER Dear Customer, SICOR gearless machines are designed and manufactured in accordance with the Machinery machine was delivered; that this manual has been delivered with the machine and that the DESCRIPTION OF THE GEARLESS MACHINE for handling cable elevator systems. -
Page 5: Dimensions/Technical Specifications Sg10
SG10 2.1. DIMENSIONS/TECHNICAL SPECIFICATIONS SG10 Ø D1 Max Weight System S3 40% Load Power** [mm] [mm] [mm] [kg] [kgm²] [Nm] [kW] 0,09 0,13 0,21 0,24 0,36 0,47 0,54 Standard Encoder Data 2x180 [Nm] Heidenhain [V DC] Model ECN 1313 [V DC]... -
Page 6: Machine Identification
SG10 MACHINE IDENTIFICATION... -
Page 7: Warranty
SG10 WARRANTY • Labour, travel and board and lodging costs must be met by the Customer. • • gaskets, revolving bearings. • • Customer under warranty or will send its own technicians. -
Page 8: General Delivery Notes
SG10 GENERAL DELIVERY NOTES there is no visible damage to the gearless machine or its accessories in detail. Machine data sheet Work Order... -
Page 9: Safety Precautions
SG10 SAFETY PRECAUTIONS or similar). WHEN THESE WARNINGS APPEAR, PROCEED WITH THE UTMOST CAUTION. -
Page 10: Safety Requirements
SG10 SAFETY REQUIREMENTS LIFTING EXCLUSION OF POWER SOURCES WARNING Do not lean and/or sit on the gearless machine, either when it is in or out of service. - Page 11 SG10 MALFUNCTIONS.
-
Page 12: Moving The Winch
SG10 MOVING THE WINCH WARNING RISK OF CRUSHING, IMPACT AND ABRASION WARNING WARNING • lay the crate on the ground slowly • •... - Page 13 SG10 CAUTION machine.
-
Page 14: Notes For Installation
MECHANICAL INSTALLATION WARNING For other values, consult SICOR. The customer must make sure that the electrical system has suitably gauged cables, is correctly Allow a minimum of 80 mm between the encoder and the wall so that it is always accessible... -
Page 15: Cable Installation
SG10 9.1.1. CABLE INSTALLATION in any way. 9.1.2. SECURING THE GEARLESS MACHINE SG10 Screws M16 8.8) [Nm]... -
Page 16: Cable Guard
SG10 9.1.3. CABLE GUARD... -
Page 17: Electrical Installation
SG10 9.2. ELECTRICAL INSTALLATION 9.2.1. ELECTRIC MOTOR DO NOT CONNECT THE MACHINE DIRECTLY TO THE POWER GRID. THE POWER MUST BE SUPPLIED BY A SUITABLE ELECTRONIC CONVERTER. IMPORTANT NOTE Thermistors The thermistors MUST ONLY BE CONNECTED TO A SPECIFIC DEVICE. -
Page 18: Terminal Board Wiring Diagram
SG10 9.2.2. TERMINAL BOARD WIRING DIAGRAM Thermistors L1 L2 L3 terminals of the thermistor... -
Page 19: Encoder
SG10 9.3. ENCODER • Absolute rotary encoder with EnDat interface; • Rotary encoder with Sin/Cos interface;... - Page 20 SG10 9.3.1. connected or disconnected. 6/10/15/20/25 m inverter side connector. • 6/10/15/20/25 m C1 MINITEK 12 PIN WIRE COLOUR SIGNAL Brown Green CLOCK Violet White Red/Blue Grey DATE Pink Grey/Pink Blue Sensor 0 V Black Yellow Sensor 5 V...
- Page 21 SG10 EXTENSION CABLE LENGTH MORE THAN 25 METRES connected or disconnected. extensions over 25 m 0.3m • EXTENSION CABLE LENGTH OF MORE THAN 25 METRES C2 17 PIN WIRE COLOUR SIGNAL Blue White Brown/Green Violet CLOCK Yellow White/Green Blue/Black Red/Black...
-
Page 22: Rotary Encoder Sin/Cos Interface Configuration
SG10 9.3.2. ROTARY ENCODER SIN/COS INTERFACE CONFIGURATION extension cables is necessary in order to connect this encoder to the inverter. Please refer to the table below to connect the encoder to the inverter. connected or disconnected. 6/10/15/20/25 m inverter side connector. -
Page 23: Instructions For Installing The Extension Cable On The Heidenhain
SG10 9.3.3. INSTRUCTIONS FOR INSTALLING THE EXTENSION CABLE ON THE HEIDENHAIN ENDAT ECN 1313 ENCODER of the encoder • • •... - Page 24 SG10 • Bushing Bushing • The removal of the extension cable is not recommended, if this is unavoidable carry out the...
-
Page 25: Electromagnetic Brake
SG10 9.4. ELECTROMAGNETIC BRAKE be controlled. The two brake circuits MUST be monitored manual. descent of the elevator. -
Page 26: Emc Directive
SG10 IMPORTANT NOTES values. between 10mA min. and 50 mA max. at 24V DC. DO NOT use detergents containing solvents and/or oily 9.4.1. EMC DIRECTIVE... -
Page 27: Manual Brake Release Lever Remote Control Kit
SG10 9.4.2. MANUAL BRAKE RELEASE LEVER REMOTE CONTROL KIT device of 2.5 m or 5 m in length. • Block the cabin booth and the counterweight. • • Insert the Bowden cable into the brake release lever; minimum curvature radius of 200 mm. - Page 28 SG10 Manual emergency manoeuvre is a dangerous task. It can be used to move the cab of the risks involved.
-
Page 29: Manual Brake Release Lever Extension Kit
SG10 9.4.3. MANUAL BRAKE RELEASE LEVER EXTENSION KIT device • Manual emergency manoeuvre is a dangerous task. It can be aware of the risks involved. -
Page 30: Power Supply Unit
SG10 9.5. POWER SUPPLY UNIT [VAC] [VDC] bridge FF315A Terminals... -
Page 31: Power Supply Unit Electrical Connection Drawings
SG10 9.5.1. POWER SUPPLY UNIT ELECTRICAL CONNECTION DRAWINGS max. 250V~ 2,5A - 1/025.000.6 [U- =0,9xU~] Full-wave rectifier Bridge max. 250V~ 2,5A - 1/025.000.6 [U- =0,9xU~] Full-wave rectifier Bridge... - Page 32 SG10 max. 250V~ 2,5A - 1/025.000.6 [U- =0,9xU~] Full-wave rectifier...
-
Page 33: Starting The Gearless Machine For The First Time
SG10 STARTING THE GEARLESS MACHINE FOR THE FIRST TIME data. CAUTION WARNING etc...). the EN 81.1 standard. The system can now be handled. -
Page 34: Maintenance
SG10 MAINTENANCE of this manual. CAUTION gloves, safety shoes). materials WARNING The gearless machine MUST NEVER BE OPENED. -
Page 35: Encoder Replacement
SG10 11.1. ENCODER REPLACEMENT Loosen the screw on the outer ring with an Allen key Remove the cover on the rear Remove the M10 screw; Remove the encoder Figure 1... - Page 36 SG10 Remove the cover on the rear of the encoder Place the encoder inside the housing, taking care to centre the cone of 1.25 Nm THE HEIDENHAIN ENDAT ECN 1313 ENCODER) and close the cover with the Allen wrench SW3/ PROCEDURE).
-
Page 37: Pulley Dismantling
SG10 11.2. PULLEY DISMANTLING Unscrew the retaining screws Tighten the nuts on the screws Figure 4 Figure 3... -
Page 38: Pulley Assembly
SG10 11.3. PULLEY ASSEMBLY Tighten the bolts of 90 Nm. Figure 5 EMERGENCY OPERATION gearless machine. IN THIS CONDITION THE CABIN WILL MOVE DOWNWARD OR UPWARD DEPENDING ON THE LOAD AND/OR BALANCE CONDITIONS OF THE SYSTEM. WARNING WHEN THE MOTOR IS NOT POWERED, IT IS UNABLE TO GENERATE TORQUE. IN THIS SITUATION,... -
Page 39: Disposal/Recycling
SG10 DISPOSAL/RECYCLING... - Page 40 SICOR S.p.A. Head Office and Production Centre Viale Caproni 32 (Industrial Area) 38068 Rovereto (TN) Italy...
