Steelcase ēno
play
®
Installation and Operation Guide
Part number 2002480-001 Rev D
©2014 Steelcase Inc.
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Eno Play and is the answer not in the manual?

Questions and answers

Related Manuals for Steelcase Eno Play

Summary of Contents for Steelcase Eno Play

  • Page 1 Steelcase ēno play ® Installation and Operation Guide Part number 2002480-001 Rev D ©2014 Steelcase Inc. All rights reserved...

  • Page 2: Table Of Contents

    ēno play Table of contents Overview ................................ 3 What is ēno play? ............................3 Register your product........................3 Install ēno play ............................... 4 Important considerations ..........................4 Driver pack positioning ..........................4 Amplifier positioning ..........................4 Power and audio input cable length considerations ................. 4 Cable routing options to the amplifier .......................

  • Page 3: Overview

    ēno play Overview Congratulations on your purchase of the ēno ® play option to provide audio with your ēno classic interactive whiteboard. This manual describes how to install and operate ēno play. What is ēno play? ēno play enables you to control audio directly from your ēno classic interactive whiteboard using driver options on your computer.

  • Page 4: Install Ēno Play

    Power and audio input cable length considerations Steelcase provides an audio input cable with ēno play. Determine the cable path from the ēno play amplifier to the audio source. If the distance to your audio source is longer or considerably shorter, obtain alternate audio input cables from a third party.

  • Page 5: What Comes In The Box

    ēno play What comes in the box 1 Driver pack mounting template 2 ēno play Quick Reference Guide 3 #8 x 1/2” fasteners (x4) 4 L-clip fasteners (x4) 5 Foam pads 6 Cable tie holders (x10) 7 Power cable and adapters 8 3.5mm stereo male to male audio input cable 25 ft (7629mm) 9 Power cable extension 10 Driver packs (x2)

  • Page 6: Prepare The Ēno Classic Whiteboard

    ēno play Prepare the ēno classic whiteboard Before beginning to install the ēno play components: 1. If installing ēno play on a new ēno classic whiteboard, unpack the whiteboard and wall modified L-clips. 1. If installing ēno play on an ēno classic whiteboard that is already mounted to a wall. Detatch and remount the ēno interactive whiteboard using modified L-clips.

  • Page 7: Cable Routing For Whiteboards Mounted Directly To The Wall

    Before beginning to install the ēno play components, measure and plan cable routing for the ēno play amplifier power source and audio input. Steelcase provides a 25 ft (7629 mm) audio input cable, and a power connector with a 6 ft (1829mm) cable plus a 10 ft (3048mm) power cable extension.

  • Page 8: Install The Driver Packs

    ēno play Install the driver packs Locate and have ready to use: • driver packs (x2) • alcohol wipes (x2) • driver pack mounting template • tape To install the driver packs: 1. Slide the driver pack mounting template to the upper left corner of whiteboard and tape it in place.
  • Page 9 ēno play 2. Use the illustrations on the template to select the template no tches that are appropriate for the type of whiteboard mounting solution in your installation. 3. Using an alcohol wipe, clean the area about 3” (76mm) below the correct template location. 4.
  • Page 10 ēno play 9. Reverse the template and tape it to the upper right corner of the whiteboard. 10. Repeat steps 1 through 8 to install the second driver pack. 10 of 23 2002480-001 Rev D Installation and Operation Guide...

  • Page 11: Install The Amplifier

    ēno play Install the amplifier Important Note: The location of the amplifier is important. Install the amplifier in either the lower left or the lower right corner of the whiteboard and no other location. To install the amplifier: 1. Determine which side of the whiteboard provides the best access for audio input and power to the amplifier.

  • Page 12: Add Cable Ties And Tape

    ēno play 1. Connect the cable from the driver pack on the LEFT side of the whiteboard to the amplifier connector labeled "R out" for right. 2. Connect the cable from the driver pack on the RIGHT side of the whiteboard to the amplifier connector labeled "L out"...

  • Page 13: Install The Amplifier Cable Tie

    ēno play 2. Position the tie holder one inch below a driver pack and one inch towards the center of the board so the tie holder holes to run approximately vertical and horizontal with the board. 3. Press the tie holder to the board. 4.

  • Page 14: Install A Cable Tie At The Center Of The Whiteboard

    ēno play 4. Install a tie wrap through the vertical holes in the holder and capture both driver pack wires (and the power supply and permanent audio input cables if appropriate for your installation). Refer to “Plan power and audio input cable routing”. amplifier cable tie 5.

  • Page 15: Install A Cable Tie Between The Center And Bottom Of The Board

    ēno play 4. Install a tie wrap through the horizontal holes in the holder and capture both driver pack cables (and the power supply and permanent audio input cables if appropriate for your installation). Refer to “Plan power and audio input cable routing”. center cable tie 5.

  • Page 16: Install Cable Ties For Power Or Audio Cable Routing Options

    ēno play 2. Pull the cables toward to bottom edge of the board to remove all slack. 3. Ensure that all cables are taut, then remove self adhesive back from a tie holder. 4. Press the tie holder to the board. 5.

  • Page 17: Tape Cables To The Back Of The Whiteboard

    ēno play Tape cables to the back of the whiteboard To prevent any interference with ēno play audio from unwanted vibrations, tape cables to the back of the whiteboard. To tape cables to the back of the whiteboard: 1. Use tape provided to attach cables to the board. Tape can be torn with fingers or cut with scissors.

  • Page 18: Install Modified L-Clips

    ēno play To install modified L-clips: NOTE: DO NOT USE L-clips that ship with eno interactive whiteboard. Modified L-clips #8 x 1/2" #8 x 1/2" 18 of 23 2002480-001 Rev D Installation and Operation Guide...

  • Page 19: Connect Cables And Verify Amplifier Operation

    6. Assure that vibrations from loose components do not interfere with the audio. Add foam strips to prevent unwanted vibrations Test the sound from your system. If you detect unwanted vibrations, Steelcase provides four foam strips for sound damping. To damp unwanted vibrations using the foam strips provided: 1.

  • Page 20: Removing And Replacing The Cable Tie Holders, Driver Packs Or Amplifier

    ēno play Removing and replacing the cable tie holders, driver packs or amplifier The adhesive backing on the driver packs and amplifier create a tight bond to the whiteboard. Additional self-adhesive strips are provided in case you need to remove and replace a component. To remove and replace a driver pack, amplifier or cable tie holder: 1.

  • Page 21: Operating Ēno Play

    ēno play Install the driver Refer to ēno User Guide for instructions to install the ēno Application. Operating ēno play ēno play amplifies audio from sources including: • the computer with the driver installed that controls the ēno interactive whiteboard •...

  • Page 22: Using The Guest Audio Input Connector

    ēno play Using the guest audio input connector The ēno play amplifier provides two audio input connectors: permanent and guest. The permanent audio input connector is located facing the center of the whiteboard. The guest audio input connector is located at the edge of the whiteboard for easy access to temporary connections.

  • Page 23: Specifications

    Amplifier Power supply • Output power: 24VDC; 1.88A • Input power: 100-240 VAC; 50/60Hz • Steelcase Replacement# 2002532-001 • Mfg# K-Tec KSAS0452400188D5 Driver Pack • Size: 5.9" L x 2.4" W x 0.9" D (152.0mm L x 60.0mm W x 22.9mm D) •...
