Summary of Contents for Small Scale Shop YAKOVLEV YAK-38
- Page 1 YAKOVLEV YAK-38 1/144 Assembly Guide Parts List Main Body Main Engine Nozzles Upper Intake Door Lower Exhaust Doors Lift Engines Canopy Left Straight Wing Left Folded Wing Right Straight Wing Right Folded Wing...
-
Page 2: Assembly Guide
YAKOVLEV YAK-38 1/144 Assembly Guide STEP 1 – Main Engine Nozzles STEP 3a – Upper Intake Door You can choose to point the nozzles down or You can choose to pose the intake door open or closed. The auxiliary engines STEP 2 –... - Page 3 YAKOVLEV YAK-38 1/144 Assembly Guide STEP 4 – Lower Exhaust Door STEP 6a – Straight Wings You can choose to pose the exhaust doors open or closed. (left) (right) The model comes with two wing versions. For a straight wing use parts 7 and 9.
- Page 4 YAKOVLEV YAK-38 1/144 Assembly Guide assembled model should look like this.
