Vetra MegaSwitch VIP-802 User Instructions

User Instructions for VIP- 802 - KMD Series "MegaSwitch"™
Keyboard, Mouse and DVI Video Switch
Congratulations on your purchase of a VETRA "MegaSwitch"™! This quality product is designed and built in the
USA and is backed by a VETRA Three-year Warranty and unlimited free technical support. You are welcome to comment,
please email us at sales@vetra.com or call us at the numbers given at the end .
INTRODUCTION
The VIP-802-KMD series "MegaSwitch"™ Keyboard, Mouse and DVI Video Switches are available as full function,
Integrated Switches with keyboard control selection, switching keyboard, mouse, and video. The "MegaSwitch" allows one
Workstation comprised of a PC Keyboard, a PS/2 Mouse, and DVI Monitor to control and work with one or two PC's.
Note: The "MegaSwitch does not come with keyboard, mouse, or DVI extension cables. They may be ordered from Vetra
separately.
INSTALLATION
There are two main steps to connect the Switch:
1. Connect PC's to Switch unit:
a) Keyboard Connect the keyboard inputs of the PC's to the Switch using 6-pin PS/2 male/male extension cables.
Connect PC#1's keyboard port to the backpanel connector of the Switch marked "PC1 KBD". Connect PC#2's keyboard
port to the backpanel connector of the Switch marked "PC2 KBD".
b) Mouse Connect the mouse inputs of the PC's to the Switch using 6-pin PS/2 male/male extension cables. Connect
PC#1's mouse port to the backpanel connector of the Switch marked "PC1 MSE". Connect PC#2's mouse port to the
backpanel connector of the Switch marked "PC2 MSE".
c) DVI Video Connect the Video outputs of the PC's to the Switch using DVI-D male/male extension cables. Connect
PC#1's video output to the backpanel connector of the Switch marked "TO PC1 MON". Connect PC#2's video output to
the backpanel connector of the Switch marked "TO PC2 MON".
Or in the case of the D2, D3, and D4 series MegaSwitch
Connect PC#1's Monitor A video output to the backpanel connector of the Switch marked "PC1 MON A", and connect
PC#1's Monitor B video output to the back panel connector of the Switch marked "PC1 MON B". Repeat this step for PC
#2.
For the D3 and D4 series of MegaSwitch connect PC#1's Monitors C and D video outputs to the back panel connectors of
the Switch marked "PC 1 MON C" and "PC1 MON D". Repeat this step for PC #2.
2. Connect a Workstation to the Switch:
a) PS/2 Keyboard Connect the keyboard to the 6-pin DIN connector on the front panel of the Switch marked "KBD IN".
b) PS/2 Mouse Connect the mouse to the 6-pin DIN connector on the front panel of the Switch marked "MSE IN".
