MIDI THING V1 - ASSEMBLY GUIDE
THANKS FOR CHOOSING ONE OF OUR KITS!
This assembly guide has been designed taking into account the common issues that we
often find people experience in our workshops. The order in which the components are
placed on the board is meant to make assembly as easy as possible.
Some steps are not obvious, so even if you're an experienced DIYer, please take the
time to read the steps thoroughly before starting.
If this is your first project, please read this article before you start assembling the
kit:
www.befaco.org/howto/
GOOD LUCK!

MAIN PCB (The small one)

OPEN MAIN BOARD BAG A

RESISTORS

Qty Value Code
4 1k Brown, black, black, brown, brown
4 47k Yellow, violet, black, red, brown
4 68k Blue, gray, black, red, brown
3 4K7 Yellow, violet, black, brown, brown
2 10k Brown, black, black, red, brown
1 5k6 Green, blue, black, brown, brown
1 270 Red, purple, black black, brown

DIODES

Solder the diodes observing their polarity. The black or white line on the diode must
match with the white line on the diode symbol on the PCB silkscreen.
Qty Value
1 1N4148
2 1N5817

FERRITES

Solder the two ferrite beads by using a recycled resistor leg passed through each
ferrite and proceed as if it were a resistor. Ferrite beads don't have polarity.
The space for the ferrites is a bit tight. You can either leave some slack in the
leads or leave them until after you have fitted the power connector.
Qty Name on PCB
2 F1, F2
Name on PCB
D9 (orange)
D10, D11 (black)
Name on PCB
R5, R11, R13, R14
R2, R4, R6, R16
R1, R3, R12, R15
R9, R10, R19
R8, R17
R7
R18
