SL1188P Ultrasonic transit-time flowmeter
Ultrasonic Flowmeter Instruction Manual
Model: SL1188P
Revision：2.0.0
Date：September.2012
Revision
Update
Record
Date
Page 1 of 81
Revision：2.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL1188P and is the answer not in the manual?

Questions and answers

Related Manuals for SiteLab SL1188P

Summary of Contents for SiteLab SL1188P

  • Page 1 SL1188P Ultrasonic transit-time flowmeter Ultrasonic Flowmeter Instruction Manual Model: SL1188P Revision：2.0.0 Date：September.2012 Revision Update Record Date Page 1 of 81 Revision：2.0.0...
  • Page 2 SL1188P Ultrasonic transit-time flowmeter WARNINGS IN THIS MANUAL Caution and warning statements are used throughout this book to draw your attention to important information. WARNING “Warning” statement appears with information that is important to protect people and equipment from damage. Pay very close attention to all warnings that apply to your application.
  • Page 3 SL1188P Ultrasonic transit-time flowmeter Product Components An inspection should be made of the desired area before installing the flowmeter. Check to see if the spare parts are present in accordance with the packing list. Make sure that there is no shipping damage. If you have any questions, please contact your representative as soon as possible.

  • Page 4: Table Of Contents

    SL1188P Ultrasonic transit-time flowmeter Content 1. Transmitter Installation and Connection ............6 1.1. Inspection Prior to Transmitter Installation ..................6 1.2. Power Supply Connections........................6 1.2.1. Direct Mount Method........................6 1.2.2. Connecting The Wiring ........................6 1.3. Powering on ............................7 1.4. KeyTPC Functions..........................7 1.5. KeyTPC Operation ..........................8 1.6.
  • Page 5 SL1188P Ultrasonic transit-time flowmeter 5.11. Analog Output Calibration .........................21 5.12. Flowmeter PORTABLE Software Usage....................22 5.12.1. Data Acquisition and Analysis ......................22 5.12.1.1. TPC Data Acquisition and Analysis Program................22 5.12.1.2. Main Interface ..........................22 5.12.1.3. Data Acquisition ..........................23 5.12.1.4. Data Analysis and Graph......................24 5.12.1.5.
  • Page 6 SL1188P Ultrasonic transit-time flowmeter 9.1. Sound Velocity and Viscosity for Fluids Commonly Used ..............53 9.2. Sound Velocity for Various Materials Commonly Used...............53 9.3. Sound Velocity In Water (1 atm) At Different Temperatures..............54 9.4. Sound Velocity and Viscosity of Common Liquid................55 9.5.

  • Page 7: Transmitter Installation And Connection

    1.1. Inspection Prior to Transmitter Installation Check the packing list and contents to ensure that all necessary and ordered parts are on hand. Should any parts be missing or damaged, please contact Sitelab Instruments as soon as possible. 1.2. Power Supply Connections 1.2.1.

  • Page 8: Powering On

    Run the flow meter procedure in the panel personal computer. Please turn to the instruction manual for details on how to use the panel personal computer. a) Identification area Software logo: Site Lab SL1188P b) Information display area Page 7 of 81...

  • Page 9: Keytpc Operation

    SL1188P Ultrasonic transit-time flowmeter When operating the keyboard, it will display the meter return information; when operating the short cut keyboard, it will display the information tips and the meter return information. c) Entering display area Display the keyboard operating information d) Main keyTPC area The button of the flow meter, and press this button equals to press the keyTPC.

  • Page 10: Flowmeter Menu Descriptions

    SL1188P Ultrasonic transit-time flowmeter Example 2: If the pipe material is “Stainless Steel”, Pipe Material press to enter Menu 14, then press Menu >1. Stainless Steel to modify the options. Then, select “1. Stainless Steel” from the drop-down menu (you may cycle through the...

  • Page 11: Pipe Parameter Entry Shortcuts

    SL1188P Ultrasonic transit-time flowmeter 2. Pipe Parameter Entry Shortcuts Example: Lets say we have a DN200 (8”) pipe, measuring water, Material is carbon steel with no liner. These parameters should be entered as follows: Step 1. Pipe outside diameter Press...
  • Page 12 SL1188P Ultrasonic transit-time flowmeter Step 7. Transducer mounting methods Press the key to enter menu 24, Menu Transducer Mounting press the key, use the select transducer-mounting from drop-down menu, then press the key. Step 8. Adjust Transducer spacing Transducer Spacing...

  • Page 13: Measurement Site Selection

    SL1188P Ultrasonic transit-time flowmeter 3. Measurement Site Selection When selecting a measurement site, it is important to select an area where the fluid flow profile is fully developed to guarantee a highly accurate measurement. Use the following guidelines to select a proper installation site: Choose a section of pipe that is always full of liquid, such as a vertical pipe with flow in the upward direction or a full horizontal pipe.

  • Page 14: Transducer Installation

    SL1188P Ultrasonic transit-time flowmeter Ensure that the pipe surface temperature at the measuring point is within the transducer temperature limits. Consider the inside condition of the pipe carefully. If possible, select a section of pipe where the inside is free of excessive corrosion or scaling.

  • Page 15: Z Method

    SL1188P Ultrasonic transit-time flowmeter 4.1.4. Z Method The signal transmitted in a Z method installation has less attenuation than a signal transmitted with the V method. This is because the Z method utilizes a directly transmitted (rather than reflected) signal which transverses the liquid only once.

  • Page 16: Signal Quality (Q Value)

    SL1188P Ultrasonic transit-time flowmeter transducer mounting spacing should be re-adjusted and the pipe should be re-inspected. If necessary, change the mounting to the Z method (Z has the highest signal strength). 4.2.2. Signal Quality (Q value) Q value is short for Signal Quality (displayed in menu 90). It indicates the level of the signal detected. Q value is indicated by numbers from 00~99.

  • Page 17: Operating Instructions

    Picture 5-1 logout operation of panel personal computer 5.2 Establishing Bluetooth communications Connect the TPC with transmitter through Bluetooth, the TPC will automatically launch the SiteLab Flowmeter application and search for Bluetooth devices. It will show a list of compatible Bluetooth devices with range.

  • Page 18: Connecting The Transmitter

    SL1188P Ultrasonic transit-time flowmeter If you are still unable to communicate, activate the reset function. This will force a reboot and recycle the TPC software, again, once the TPC software is completely booted up, the flow meter will automatically launch.
  • Page 19 SL1188P Ultrasonic transit-time flowmeter When installing transducers to relatively small pipes {sizes under 8” in most applications}, the transducer spacing displayed in MENU25 may be less than 7.5” (190mm), then we can install the transducers in single slide ruler rack. The installation method is unscrewing a transducer off the rack at first, then install the two transducers to one rack face-to-face.
  • Page 20 SL1188P Ultrasonic transit-time flowmeter When finished installing both transducers in a single rack, they should appear as shown in the photo below. The oval transducer crystals should be facing each other. They are designed to send signals back and forth to one another, and if they are installed backwards, they will not function.

  • Page 21: System Normal Identification

    SL1188P Ultrasonic transit-time flowmeter 5.4. System Normal Identification keys. If the letter “*R” displays on the screen, it indicates system normal. Press the Menu If the letter “E” is displayed, it indicates that the current loop output is over ranged by 120%. This refers to the settings in menu 57.

  • Page 22: 20Ma Current Loop Verification

    SL1188P Ultrasonic transit-time flowmeter Keep the password in mind or recorded in a safe place or the instrument cannot be used. 5.8. 4~20mA Current Loop Verification 4-20mA+ 4-20mA- Black 4-20mA + 4-20mA - The 4~20mA current output connects to the 7-pin din jack on the panel. The color of cable core is red（4-20mA+）...

  • Page 23: Flowmeter Portable Software Usage

    \programs\Data. You can see four directories: SL1188P, Display, Output, and Setup. The “SL1188P” directory is used for storing the collected Flowmeter data, “Output” for storing output setup files of the Flowmeter, “Display” for storing the display setup files of the Flowmeter and “Setup” for storing setup and configuration files of the Flowmeter.

  • Page 24: Data Acquisition

    SL1188P Ultrasonic transit-time flowmeter copyright and version information. SL1188P Config Flow Key Pad Menu Signal Aout Error Comm Table&Graph Data Acquisition UFMData Setting About SL1188P Read File 5.12.1.3. Data Acquisition To collect data, click “Data Acquisition” menu to enter Data Acquisition mode. After inputting the File Name and Time of Acquisition, operators can click the “start”...

  • Page 25: Data Analysis And Graph

    SL1188P Ultrasonic transit-time flowmeter OK Button : Click to exit this page. Coordinate: Curves that display Flow Rate and Flow Velocity during data acquisition. Red Box: Displays the value of the Flow Rate. Blue Box: Displays the value of the Flow Velocity.

  • Page 26: Data Acquisition Control For The Internal Sd Card

    SL1188P Ultrasonic transit-time flowmeter flow rate and flow velocity in the “Data Table”. Dct201107120917.dat Flow Velo Qmax 6.8292 9.9250 Qmin 1.1987 1.7421 Qavg 3.8466 5.5904 0.8199 1.1915 UPmax 3410.5788 1.3768 DNmax 10134.9431 4.0914 Graph Qmax: Maximum values of flow rate and flow velocity;...

  • Page 27: Data Reading For The Sd Card

    SL1188P Ultrasonic transit-time flowmeter after the “File name”. Select the interval time among the options after “Interval time”. Input the time of acquisition (Unit: min) after “Time of Acquisition”. Then click “Start” button to enter the data collecting status. The content of the data logging contains: Date and Time, Flow rate, Flow velocity, Net Totalizer, Pos Totalizer, Neg Totalizer, ESN, Pipe Inner Diameter, Pipe Outer Diameter, Pipe material, Liner material and Fluid Type.

  • Page 28: Ufm Data Analysis And Printing Program

    SL1188P Ultrasonic transit-time flowmeter Read File Delete All List Read Delete “List”: read the files content in the SD card. “Read”: read the selected file to TPC, and convert the file to *.dat format. “Delete”: delete the selected file. “Delete all”: select this option, click “delete” will delete all the files in the SD card.

  • Page 29: Graph Display And Printing

    SL1188P Ultrasonic transit-time flowmeter “Open” button: Press this button to read in the Flowmeter data files under “Flowmeter” directory. Theses files are data collected by the TPC. “Graph” button: Press this button to jump to the “Graph” page, where data are displayed in graphs.

  • Page 30: Data Analysis And Printing

    SL1188P Ultrasonic transit-time flowmeter This page is divided up into 2 parts: the graph display area with black background is the main page and the left is the graph display setup area. “Curve” check box: Placing a check mark to the left of the graph name displays the corresponding graph in the graph area.

  • Page 31: Configuration Information Display

    SL1188P Ultrasonic transit-time flowmeter 5.12.2.4. Configuration Information Display This page displays the configuration information of the Flowmeter. This page cannot be printed. Flowmeter Serial Number: Displays Flowmeter serial number； Fluid Type: Displays fluid type being measured； Page 30 of 81...

  • Page 32: Menu Functions

    SL1188P Ultrasonic transit-time flowmeter Pipe Outer Diameter: Displays pipe outer diameter； Pipe Inner Diameter: Displays pipe inner diameter; Pipe Material: Displays pipe material; Liner Material: Displays liner material. 5.12.2.5. Menu Functions There are three menus in the Menu bar of the program: “File”, “Edit” and “Help” the File submenu has the following functions: “Open”: Opens the data files stored under the “Flowmeter”...

  • Page 33: Check Flow Of Every Day/Month/Year

    SL1188P Ultrasonic transit-time flowmeter numbers that do not need to be changed, and then press again to confirm the modification. 5.15. Check Flow of Every Day/Month/Year Window M82 allows you to read flow data history and the operating state of the instrument in the past 64 days.

  • Page 34: Windows Display Explanations

    SL1188P Ultrasonic transit-time flowmeter 6. Windows Display Explanations 6.1. Windows Display Codes Flow Totalizer Display Setup Options Flow Rate/Net Totalizer Damping Flow Rate/Velocity Low Flow Cutoff Value Flow Rate/POS Totalizer Set Zero Flow Rate/NEG Totalizer Reset Zero Date Time/Flow Rate...

  • Page 35: Display Explanation

    SL1188P Ultrasonic transit-time flowmeter 6.2. Display Explanation While reading this section, please compare it with the instrument in order to improve your understanding. Menu Flow 0.1154m3/h *R Flow Rate／Net Totalizer 0x1m3 Display flow rate and net Totalizer. If the net Totalizer has been turned off (refer to M34), the net Totalizer value displayed is the total prior to its turn off.
  • Page 36 SL1188P Ultrasonic transit-time flowmeter Menu Pipe Outer Perimeter Pipe Outer Perimeter Enter the pipe outer perimeter. If the diameter of the know, enter it in window M11. Menu Pipe Outer Diameter Pipe Outside Diameter 200 mm Enter the pipe outside diameter, The pipe outside diameter must range from 10mm to 6000mm.
  • Page 37 SL1188P Ultrasonic transit-time flowmeter Menu Liner Material [16 Select the Liner Material 0. None, No Liner The following options are available: 0. None ,No Liner 1. Tar Epoxy 2. Rubber 3. Mortar 4. Polypropylene 5. Polystryol 6. Polystyrene 7. Polyester 8.
  • Page 38 SL1188P Ultrasonic transit-time flowmeter Menu Fluid Viscosity [22 Fluid Viscosity 1.0038 Enter fluid’s kinematics viscosity. It only can be used when item “Other” is selected in Window M20, i.e. it is unnecessary to enter all the fluids that listed in Window M20.
  • Page 39 SL1188P Ultrasonic transit-time flowmeter Menu Cross-sectional Area Cross-Sectional Area 31415.9 Display the cross-sectional area inside the pipe. Menu Holding with PoorSig Holding With Poor Sig Select “Yes” to hold last good flow signal displayed if the Flowmeter experiences a poor signal condition.
  • Page 40 SL1188P Ultrasonic transit-time flowmeter Menu Totalizer Units Totalizer Units Options Cubic Meter (m3) Select Totalizer units. The available unit options are as same as those found in Window M31. The user can select units as their required. Factory default is Cubic Meters.
  • Page 41 SL1188P Ultrasonic transit-time flowmeter Menu Totalizer Reset? [37 Totalizer Reset Selection Totalizer reset; all parameters are reset. Press arrow to select “YES” or “NO”. move After “YES” is selected, the following options are available: None, All, NET, POS, NEG If it is necessary to recover the factory default,...
  • Page 42 SL1188P Ultrasonic transit-time flowmeter Menu Set Zero Set Zero Press ENT to go When fluid is in the static state, the displayed value is called “Zero Point”. When “Zero Point’ is not at zero in the Flowmeter, the difference is going to be added into the actual flow values and measurement differences will occur in the Flowmeter.
  • Page 43 SL1188P Ultrasonic transit-time flowmeter Menu CL Mode Select [55 Current Loop Mode Select 20 mA Select the current loop mode. The following options are available: 4-20mA set up the output range from 4-20mA 0-20mA set up the output range from 0-20mA...
  • Page 44 SL1188P Ultrasonic transit-time flowmeter Menu CL 4 mA Output Value CL 4mA or 0mA Output Value 0 m3/h Set the CL output value according to the flow value at 4mA or 0MA.(4mA or 0mA are determined by the settings in Window M56). The flow unit’s options are as same as those in Window M31.
  • Page 45 SL1188P Ultrasonic transit-time flowmeter Menu Working Timer [72 Working Timer 00000011:16:38 Display the totalized working hours of the Flowmeter since last reset. It is displayed by HH:MM:SS. If it is , and select “YES”. necessary to reset it, press Menu...
  • Page 46 SL1188P Ultrasonic transit-time flowmeter signal strength should be ≥60.0. Signal quality Q is indicated by 00 ～ 99.Therefore, 00 indicates the poorest signal while 99 indicates the best signal. Normally, signal quality Q value should be better than Menu TOM/TOS*100 [91 TOM/TOS*100 0.0000%...
  • Page 47 SL1188P Ultrasonic transit-time flowmeter press to display the last uTPCte before the last 00 00-07-18 12:40:12 64 times of on/off time and flow rate values. “ON” on *ON 123.65 m3/h right hand indicates that time power is on; “00” on the upper left corner indicates “00-07-18 12:40:12”...
  • Page 48 SL1188P Ultrasonic transit-time flowmeter Aout Analog Output(%): Shortcut Key for Analog Output +2.000000E+01 Displays analog output（ 4~20mA）information. Error Error Code: Shortcut Key for Error Code Display error codes during an operation. See chapter 5 for error code contents. Comm Communication Setup:...

  • Page 49: Error Diagnoses

    SL1188P Ultrasonic transit-time flowmeter 7. Error Diagnoses The ultrasonic Flowmeter has advanced self-diagnostics functions and displays any errors in the upper right corner of the LCD via definite codes in a date/time order. Hardware error diagnostics are usually performed upon each power on.

  • Page 50: Table 2. Error Codes And Solutions (During Operation)

    SL1188P Ultrasonic transit-time flowmeter 7.2. Table 2. Error Codes and Solutions (during operation) Code M08 Display Cause Solution System Normal System normal No errors SCPU Fatal Error Hardware defect Contact the factory Signal Not Detected Signal not detected. Attach transducer to the pipe and tighten it securely.

  • Page 51: Frequently Asked Questions And Answers

    SL1188P Ultrasonic transit-time flowmeter 7.3. Frequently Asked Questions and Answers Question: New pipe, high quality material, and all installation requirements met: why still no signal detected? Answer: Check pipe parameter settings, installation method and wiring connections. Confirm if the coupling compound is applied adequately, the pipe is full of liquid, transducer spacing agrees with the screen readings and the transducers are installed in the right direction.

  • Page 52: Product Overview

    SL1188P Ultrasonic transit-time flowmeter 8. Product Overview 8.1. Introduction The Flowmeter PORTABLE Ultrasonic Liquid Flow Meter consists of a flow sensor (two ultrasonic transducers), a flow transmitter and a Personal Digital Assistant (TPC). The Model Flowmeter PORTABLE Ultrasonic Flowmeter is a state-of-the-art universal transit-time Flowmeter designed using SLSI technology and low-voltage broadband pulse transmission.

  • Page 53: Applications

    SL1188P Ultrasonic transit-time flowmeter Ultrasonic frequency of reflection Pipe Diameter θ The angle between the ultrasonic signal and Downstream Transducer the flow down Transit time in the forward direction Flow Transit time in the reverse direction down ΔT=T –T down Upstream Transducer 8.4.

  • Page 54: Appendix1 - Flow Application Data

    SL1188P Ultrasonic transit-time flowmeter 9. Appendix1 - Flow Application Data 9.1. Sound Velocity and Viscosity for Fluids Commonly Used Alcohol 1440 Sound Fluid Viscosity Velocity (m/s) Glycol 1620 water 20℃ 1482 Glycerin 1923 1180 water 50℃ 1543 0.55 Gasoline 1250 0.80...

  • Page 55: Sound Velocity In Water (1 Atm) At Different Temperatures

    SL1188P Ultrasonic transit-time flowmeter 9.3. Sound Velocity In Water (1 atm) At Different Temperatures ℃ t( ) v(m/s) 1517.7 1554.5 1402.3 1519.7 1554.7 1407.3 1521.7 1554.9 1412.2 1523.5 1555.0 1416.9 1525.3 1555.0 1421.6 1527.1 1555.1 1426.1 1528.8 1555.1 1430.5 1530.4 1555.0...

  • Page 56: Sound Velocity And Viscosity Of Common Liquid

    SL1188P Ultrasonic transit-time flowmeter 9.4. Sound Velocity and Viscosity of Common Liquid Glycerin 1923 1180 Velocity of Viscosity Liquid Sound(m/s) 1250 0.80 Water 20℃ 1482 66#Gas 1171 Water 50℃ 1543 0.55 80#Gas 1139 Water 75℃ 1554 0.39 0#Gas 1385 Water 100℃...

  • Page 57: Sound Velocity In Water (1 Atm) At Different Temperatures

    SL1188P Ultrasonic transit-time flowmeter 9.6. Sound Velocity In Water (1 atm) At Different Temperatures Temperature Sound Speed in Water Temperature Sound Speed in Water ℃ ℉ 203.0 1,547 5,076 Ft/s 204.8 1,546 5,072 141.8 1,551 5,089 206.6 1,545 5,069 143.6...

  • Page 58: Common Pipe Dimensions (English)

    SL1188P Ultrasonic transit-time flowmeter 9.7. Common Pipe Dimensions (English) INCH SCHEDULE WALL 1/8" 0.405" 0.049" 0.307" 1/8" 0.405" 0.068" 0.269" 1/8" 0.405" 0.095" 0.215" 1/4" 0.540" 0.065" 0.410" 1/4" 0.540" 0.088" 0.364" 1/4" 0.540" 0.119" 0.302" 3/8" 0.675" 0.065" 0.545"...
  • Page 59 SL1188P Ultrasonic transit-time flowmeter 11/2" 1.900" 0.200" 1.500" 11/2" 1.900" 0.281" 1.388" 11/2" 1.900" 0.400" 1.100" 2" 2.375" 0.065" 2.245" 2" 2.375" 0.109" 2.157" 2" 2.375" 0.154" 2.067" 2" 2.375" 0.218" 1.939" 2" 2.375" 0.344" 1.687" 2" 2.375" 0.436" 1.503"...
  • Page 60 SL1188P Ultrasonic transit-time flowmeter 5" 5.563" 0.134" 5.295" 5" 5.563" 0.258" 5.047" 5" 5.563" 0.375" 4.813" 5" 5.563" 0.500" 4.563" 5" 5.563" 0.625" 4.313" 5" 5.563" 0.750" 4.063" 6" 6.625" 0.109" 6.407" 6" 6.625" 0.134" 6.357" 6" 6.625" 0.188" 6.249"...
  • Page 61 SL1188P Ultrasonic transit-time flowmeter 10" 10.750" 0.594" 9.562" 10" 10.750" 0.719" 9.312" 10" 10.750" 0.844" 9.062" 10" 10.750" 1.000" 8.750" 10" 10.750" 1.125" 8.500" 11" 11.750" 0.375" 11.000" 11" 11.750" 0.500" 10.750" 11" 11.750" 0.875" 10.000" 12" 12.750" 0.156" 12.438"...
  • Page 62 SL1188P Ultrasonic transit-time flowmeter 16" 16.000" 0.844" 14.312" 16" 16.000" 1.031" 13.938" 16" 16.000" 1.219" 13.562" 16" 16.000" 1.438" 13.124" 16" 16.000" 1.594" 12.812" 18" 18.000" 0.188" 17.624" 18" 18.000" 0.250" 17.500" 18" 18.000" 0.312" 17.376" 18" 18.000" 0.375" 17.250"...
  • Page 63 SL1188P Ultrasonic transit-time flowmeter 24" 24.000" 0.375" 23.250" 24" 24.000" 0.500" 23.000" 24" 24.000" 0.562" 22.876" 24" 24.000" 0.688" 22.624" 24" 24.000" 0.969" 22.062" 24" 24.000" 1.219" 21.562" 24" 24.000" 1.531" 20.938" 24" 24.000" 1.812" 20.376" 24" 24.000" 2.062" 19.876"...

  • Page 64: Common Pipe Dimensions (Din)

    SL1188P Ultrasonic transit-time flowmeter 9.8. Common Pipe Dimensions (DIN) Identification N.B(inches) N.B(mm) O.D(mm) WALL(mm) Schedule STD,XS,XXS Number 33.4 33.4 33.4 33.4 1 ¼ 42.2 1 ¼ 42.2 1 ¼ 42.2 1 ¼ 42.2 1 ½ 48.3 1 ½ 48.3 1 ½...
  • Page 65 SL1188P Ultrasonic transit-time flowmeter 219.1 22.2 219.1 2300 273.0 273.0 273.0 273.0 12.7 273.0 15.1 273.0 18.3 273.0 21.4 273.0 25.4 273.0 28.6 323.9 323.9 323.9 323.9 10.3 323.9 12.7 323.9 14.3 323.9 17.5 323.9 21.4 323.9 25.4 323.9 28.6 323.9...
  • Page 66 SL1188P Ultrasonic transit-time flowmeter 457.0 45.2 508.0 508.0 508.0 12.7 508.0 15.1 508.0 20.6 508.0 26.2 508.0 32.5 508.0 38.1 508.0 44.4 508.0 50.0 559.0 559.0 559.0 12.7 559.0 22.2 559.0 28.6 559.0 34.9 559.0 41.3 559.0 47.6 559.0 54.0 610.0...

  • Page 67: Cement Lined Pipes Liner Thicknesses

    SL1188P Ultrasonic transit-time flowmeter 914.0 12.7 914.0 15.9 914.0 19.0 9.9. Cement Lined Pipes Liner Thicknesses Size(in) Nominal Standard Thickness Double Thickness Pipe Minimum Weight Weight Minimum Weight Weight Length(ft) Thickness(in) Thickness(in) Per Length(lb) Foot(lb) Length(lb) Foot(lb) 1/16 0.87 1.71 1/16 2.57...

  • Page 68: Ductile Iron Pipe Data

    SL1188P Ultrasonic transit-time flowmeter Class E Class F Class G Class H Nominal Outside Outside Wall Outside Wall Wall Outside Wall Pipe Size Diamete Diameter Thickness Diameter Thickness Thickness Diameter Thickness (in.) (in.) (in.) (in.) (in.) (in.) (in.) (in.) (in.) 3.80...

  • Page 69: Sound Speeds In Various Fluids

    SL1188P Ultrasonic transit-time flowmeter 9.12. Sound Speeds In Various Fluids All data given at 25℃(77℉)unless otherwise noted Chemical Kinematic △ ℃ Substance Sound speed Specific Viscosity× 10 Formula Gravity ㎡/s ft/s m/s/℃ Acetic anhydride(22) 1.082 1180 38714 0.769 8274 (20℃) Acetic acid, anhydride(22) 1.082...
  • Page 70 SL1188P Ultrasonic transit-time flowmeter 2-Butanol 0.81 1240 40682 3.239 34.851 Sec-Butylalochol 0.81 1240 40682 3.239 34.851 n-Butyl bromide(46) 1.276 1019 33432 0.49 5.272 (20℃) (20℃) (68℉) (15℃) (59℉) n-Butyl chloride(22,46) 0.887 1140 37402 4.57 0.529 5.692 (59℉) tert Butyl chloride 0.84...
  • Page 71 SL1188P Ultrasonic transit-time flowmeter Diamylamine 1256 4120.7 1,2 Dibromo-ethane(47) 2.18 3264.4 0.79 ℉ (68 ) (20℃) Trans-1,2-Dibromoethene 2.231 3067.6 (47) Dibutyl phthalate 1408 4619.4 Dichloro-t-butyl alcohol 1304 4278.2 2,3Dichlorodioxane H6Cl 11391 4563.6 Dichlorodifluoromethane 1.516 774.1 2539.7 4.24 ℃ (3)(Freon 12)
  • Page 72 SL1188P Ultrasonic transit-time flowmeter Ethanol 0.789 1207 3960 1.39 14.956 Ethanol amide 1.018 1724 5656.2 Ethoxyethane 0.713 3231.6 4.87 0.311 3.346 Ethyl acetate(33) 0.901 1085 3559.7 0.489 5.236 Ethyl alcohol 0.789 1207 3960 1.396 15.020 Ethyl benzene(46) 0.867 1338 4389.8 0.797...
  • Page 73 SL1188P Ultrasonic transit-time flowmeter Hexalin 0.962 1454 4770.3 70.69 760.882 ℃ ℉ (17 ) (68 ) Hexane(16,22,23) 0.659 1112 3648.3 2.71 0.446 4.798 n-Hexane(29,33) 0.649 1079 3540 4.53 2,5-Hexanedione 0.729 1399 4589.9 n-Hexanol 0.819 1300 4265.1 Hexahydrobenzene(15) 0.779 1248 4094.5 5.41...
  • Page 74 SL1188P Ultrasonic transit-time flowmeter ℃ (20 ) Methyl carbinol 0.789 1207 3960 1.396 Methyl-chloroform(47) 1.33 3231.6 0.902 9.705 ℃ ℉ (20 ) (68 ) Methyl-cyanide 0.783 1290 4232.3 0.441 4.745 3-Methyl cyclohexanol 0.92 1400 4593.2 Methylene chloride(3) 1.327 1070 3510.5 3.94...
  • Page 75 SL1188P Ultrasonic transit-time flowmeter Pentane(36) 0.626 1020 3346.5 0.363 3.905 ℃ (20 ) n-Pentane(47) 0.557 1006 3300.5 0.41 4.413 Perchlorocyclopentadiene 1.718 1150 3773 (47) Perchloro-ethylene(47) 1.632 1036 3399 Perfluoro-1-Hepten(47) 1.67 1912.7 Perfluoro-n-Hexane(47) 1.672 1666.7 Phene(29,40,41) 0.879 1306 4284.8 4.65 0.711 7.65...
  • Page 76 SL1188P Ultrasonic transit-time flowmeter Propylene(17,18,35) 0.563 3159.4 6.32 ℃ ℃ ℉ (-13 ) (-13 ) (9 ) Pyridine 0.982 1415 4642.4 0.992 10.673 ℃ ℉ (20 ) (68 ) Refrigerant 11(3,4) 1.49 828.3 2717.5 3.56 ℃ ℉ (0 ) (32 ) Refrigerant 12(3) 1.516...
  • Page 77 SL1188P Ultrasonic transit-time flowmeter ℃ ℃ ℉ (20 ) (20 ) (68 ) o-Toluidine(46) 0.999 1618 5308.4 4.394 47.279 ℃ ℃ ℉ (20 ) (20 ) (68 ) p-Toluidine(46) 0.966 1480 4855.6 1.863 20.053 ℃ ℃ ℉ (45 ) (50 )

  • Page 78: Sound Speed In Various Pipe Materials

    SL1188P Ultrasonic transit-time flowmeter 9.13. Sound Speed in Various Pipe Materials Sound Speed* Sound Speed* ℃ ℃ Material Shear Wave(25 ) Long Wave(25 ) ft/s Mm/us In./us Steel, 1% Carbon, Hardened 3150 10335 5.88 0.2315 Carbon Steel 3230 10598 5.89 0.2319...

  • Page 79: Appendix

    External Storage SD Card Note SL1188P.apk and Dctp.pdb file are put under the SD kagan Please ensure that the catalogue. 3. Click “SL1188P.apk” to install the application according to the clue. mnt sdcard SL1188P Do you want to install this application? Aldiko...
  • Page 80 Done 5. Bluetooth communications Connect the TPC with transmitter through Bluetooth, the TPC will automatically launch the SiteLab Flowmeter application and search for Bluetooth devices. It will show a list of compatible Bluetooth devices with range. Select the suitable device to connect and in the event that a data window appears asking for a password, enter the password of 1234.

  • Page 81: Ufm Data Installation

    SL1188P Ultrasonic transit-time flowmeter 10.2. UFM Data Installation 10.2.1. Hardware requirements CPU: PII266 or faster，Memory: 64M or more，Display resolution: 1024*768 or higher。 10.2.2. OS Requirements Windows 98SE 4.10.2222A or later, IE4.01 or later. 10.2.3. Installing Method Step 1: Open Setup file in the UFM Data directory to enter installation page. Click “Next” to proceed.
  • Page 82 SL1188P Ultrasonic transit-time flowmeter Step 4: Click “Finish” to finish installation. Page 81 of 81 Revision：2.0.0...
