Thank you for purchasing the"AIRAID" Intake System.
Please read the instruction manual carefully before proceeding with the installation. Contact AirAid (480-443-3333: 8:00
AM - 5:00 PM MST weekdays ) for questions regarding fit or instructions that are not clear to you.
Your intake system was carefully inspected and packaged. Check that no parts are missing or were damaged during
shipping. The air filter element is protected from direct exposure to water and debris in its new location. Care should be
taken not to drive through deep water. WATER INGESTION IS THE DRIVERS RESPONSIBILITY !
The conical air filter is washable oiled cotton gauze element. It is a lifetime element.
PARTS LIST
KITP300
S.S. COUPLER
KIT104TAC
TUBE 13" X 3.5"
KIT104H
PLASTIC T.B. ADAPTER
KITFEL60038
T.B. GASKET
700-420
FILTER 3.5" x 9"
KIT104HP
HARDWARE PACK
INSTRUCTION SHEET
KITPOLISHEDB SUPPORT BRACKET
KITBOLT51618
3/8" X 1" BOLT
3/8" LOCKING NUT
KITACDSTUD
S-SHAPED 6MM STUD
KITBN41187
6MM WASHERED NUT
KITNUT
ALUM INUM NUT
KITGATES2019
RUBBER ELBOW
KITSNP18M4
RATCHET CLAMPS
EVG042
AIRAID DECAL
#200-104 INSTALLATION INSTRUCTIONS
1988-95 G.M. 5.0-5.7 T.B.I. Engines
1
1
1
1
1
1
x1
x1
x1
x1
x1
x1
x1
x1
x2
x1
Tool List
Ratchet wrench
10 mm socket
5/16 socket or nut driver
3/8 socket
6" socket extension
Flat blade screwdriver
Pliers
Advertisement
Table of Contents
Summary of Contents for Airaid 200-104
- Page 1 Thank you for purchasing the“AIRAID” Intake System. Please read the instruction manual carefully before proceeding with the installation. Contact AirAid (480-443-3333: 8:00 AM - 5:00 PM MST weekdays ) for questions regarding fit or instructions that are not clear to you.
- Page 2 Locate dipstick tube mounting bracket on passenger side cylinder head. Using a 3/8”socket remove the screw and save. b) Carefully pull the dip stick away from the cylinder head and position the “AIRAID” mounting bracket between the cylinder head and dipstick mounting bracket. Fasten with original screw. Finger tighten only, adjustments needed later.
