GDS BlueBeam Installation Instructions Manual

Supplied Items
• 1 x Light Fitting
• 2 x M4 Machine Screws
• Instruction Leaflet
CAUTION!
DO NOT CONNECT THIS UNIT DIRECTLY TO THE MAINS!
This light fitting requires 11 to 36 Volts DC. Current consumption
varies from 100mA to 300mA depending on operating voltage.
Suitable power supplies are available from your distributor.
Conformity
The BlueBeam and BlueDome range of LED fittings conform to the
following standards:
EN 61000-6-3 Light Industrial Emissions
EN 61000-4-2 Heavy Industrial Immunity
EN 60945 Marine
Further information can be obtained from
Installation
The BlueBeam is designed to be fitted straight onto a standard metal
or plastic conduit box. For maximum flexibility and to future proof
the installation, pull 3 cables from the PSU to the BlueBeam fittings,
one for Power, one for Ground
and one for Control.
cables should be terminated
with crimp M4 eyelets.
Installation Instructions
BlueBeam and BlueDome
Optional Accessories
Please contact your distributor for further
information.
•
•
•
•
technical@gds.uk.com
The
• Minimum Operating Voltage: 11V DC
• Maximum Operating Voltage: 36V DC
• Nominal Input Voltage:
• Nominal Input Power:
• Operating Current:
• Standby Current:
•
Control Line Impedance:
BS-PS1 – 1 Zone Power Supply
BS-DM1 – Dimmer Control Module
BS-BC – Light Spill Control Cowl
BS-EL – Eyelid Light Baffle
Electrical Properties
24V DC
3W
125mA @ 24VDC
6 - 8mA
100KΩ
