RUBICON EXPRESS 3290 MONIER CIR., RANCHO CORDOVA, CA. 95742 916-473-4600
Congratulations on purchasing the ultimate suspension package available for the Jeep JK.
Application Notes:
1)
The JK long arm upgrade kit is not a complete kit, additional parts such as but not limited to coil springs, track bars, track bar
brackets, and steering components will also be needed for a complete installation. This kit is designed to replace the stock short
arm configuration. Installation of the system will require the rear lower rear control arm brackets are removed from the frame
along with modification or removal of the upper rear arm brackets. The front lower control arm brackets can remain on the frame
but we suggest that they are removed for a better visual appearance.
2)
This kit does require the removal of the fuel tank for installation. Special tools are not required to remove the fuel tank.
3)
This kit does not require modifications to the exhaust system, however it is recommended that the exhaust, from the transmission
cross member back is removed prior to and replaced after installation to better access the frame rail during rear bracket
installation.
4)
The transmission skid plate must be removed and will not be reinstalled due to drive shaft clearance.
5)
It is absolutely necessary that a front and rear CV drive shaft be used in conjunction with this lift.
Safety Warning:
Suspension systems or components that enhance the off-road performance of your vehicle may cause it to handle differently, on and off-road, than it did
from the factory. Care must be taken to prevent loss of control or vehicle rollover during sudden maneuvers. Failure to drive the vehicle safely may result
in serious injury or death to driver and passengers. We recommend you always wear your seat belt, drive safely and avoid quick turns and other sudden
maneuvers. Constant maintenance is required to keep your vehicle safe. Thoroughly inspect your vehicle before and after every off-road use.
Installation Warning:
All procedures described in these instructions were performed while the vehicle was properly supported on a vehicle lift. Use caution when
supporting the vehicle as removing and installing parts will change the vehicle center weight. Rubicon Express recommends that chassis support
jacks are always used at the front and rear of the vehicle during the installation of a suspension system.
We recommend that certified technicians perform the installations of our products. Attempts to install these products without knowledge or experience
may jeopardize the safety of the vehicle. These instructions only cover the installation of our products and may not include factory procedures for
disassembly and reassembly of factory components. Read instructions from start to finish and be sure all parts are present before disassembling the
vehicle. Included instructions are guidelines only for recommended procedures and in no way are meant to be definitive. Installer is responsible to insure a
safe and controllable vehicle after performing modifications. Do not perform test drives on public roads with partially completed installations. Always
double and triple check your work before use.
ESP WARNING NOTE: The 2007+ Jeep Wrangler JK is equipped an Electric Stability Program (ESP). This system is designed to help control
the vehicle in times of uncertain traction conditions and roll stability. Due to the complex nature of this program Rubicon Express strongly
suggest that after lifting the vehicle it is returned to the dealer for a computer "flash" to re address tire size and proper ESP control settings.
Rubicon Express also recommends that you become familiar with the ESP controls and how the different level of settings can help you to keep
better control of your vehicle.
KIT CONTENTS
RE4070 Extreme Duty Control Arm Front Lower Left
RE4080 Extreme Duty Control Arm Front Lower Right
RE4075 Extreme Duty Control Arm Front Upper, pair
RE4085 Extreme Duty Control Arm Rear Lower Left
RE4095 Extreme Duty Control Arm Rear Lower Right
RE4090 Extreme Duty Control Arm Rear Upper, pair
RE4520 3 Piece Extreme Duty Front Cross Member
RE4525 Rear Control Arm Bracket kit
TYPICAL TOOLS REQUIRED
1.
Basic mechanical hand tools
2.
1" & 1.25" bi-metal hole saws
3.
½" drill motor & drill bits
4.
angle grinder
5.
welder
6.
plasma cutter, or reciprocating saw w/metal cutting blades, or cutting wheels for angle or die grinder (to
remove control arm mounts)
INSTALLATION INSTRUCTIONS FOR:
RE7330 2 & 4 DOOR JK WRANGLER
LONG ARM UPGRADE KIT
RI7330 Page 1 of 9
Advertisement
Related Manuals for Rubicon Express RE7330
Summary of Contents for Rubicon Express RE7330
- Page 1 “flash” to re address tire size and proper ESP control settings. Rubicon Express also recommends that you become familiar with the ESP controls and how the different level of settings can help you to keep better control of your vehicle.
- Page 2 PRE INSTALLATION NOTE: Control arm bushings are pre-lubed during initial assembly at Rubicon Express. As general maintenance the control arm bushings should be lubed with a silicone base grease as needed. Silicone base grease can be purchased at your local auto parts store.
- Page 3 O2 sensors before removal. (photo 4) Using the supplied 9/16” x 4.5” bolt from the Rubicon Express front arm kit, install passengers side arm (pocket bracket faces drivers side) into the cross member mount. (photo 5) Next install the bushing end of the arm into the stock control arm location on the axle housing using the stock hardware.
- Page 4 Photo # 6 Photo # 7 Front bump stops and coil springs Place the front bump stop on the center of the lower spring mount on the axle tube. Insert a center punch thru the center and mark the hole to be drilled. Drill the marked hole to 5/16”, use the supplied self-tapping bolt to secure the bump stop to the lower spring cup.
- Page 5 Photo # 10 Photo # 11 Front Track bar Set the track bar at an initial setting of 32 5/8” center to center. Using the supplied ½” bolt, install the Super-Flex end of the bar into the drop track bar bracket. Using the stock track bar bolt, install the bushing end into the axle bracket.
- Page 6 First, separate the six brackets (3 per side) that make up the left and right bracket kits. The brackets in the photo are shown as left and right assemblies with the top of the photo being the front of the vehicle. (Photo 13) Using the drivers side inner reinforcement plate, locate the indexing oval on the inside of the driver frame rail.
- Page 7 Photo # 16 Photo # 17 Photo #18 Photo # 19 Photo # 20 Photo # 21 Step 5 – Rear arm and component installation Rear arms Prepare the rear of the vehicle for control arm and component installation by removing the following items: shocks, sway bar links, coil springs, track bar, brake line brackets at the frame, e-brake cables at the body and the drivers side upper and lower control arms.
- Page 8 Set the upper arm to an initial setting of 17.5” center to center, install the coupler end at the mounting point on the lower arm with the supplied ½” hardware and the other end at the upper mount on the axle using the factory hardware.
-
Page 9: Troubleshooting
Retighten all bolts after 50 miles and again after every off road excursion. After all adjustments have been made, Rubicon Express recommends that your local Jeep dealership “flash” the computer to adjust for proper tire size and ESP control settings. .
