- Page 1 JohnsonSuisse barossa pivot semi-frameless shower screen INSTALLATION GUIDE...
- Page 2 CONTENTS Introduction....04 Care....10 Warranty....11 JohnsonSuisse...
- Page 3 GENERAL INFORMATION Please inspect the product immediately upon receipt for damage, missing components or manufacturing faults. Damage reported later connot be accepted. Please handle the product with care avoiding knocks and shock loading to all sides and edges of glass.
- Page 4 COMPONENTS Before commencing installation, please check you have received the correct parts required; outlined below [1] 1 x Installation Instruction. [2] 1 x Handle Set. [3] 2 x Magnetic Seals. [4] 1 x Door Panel.
- Page 5 INSTALLATION [14] Assembly Drawing [13] [15] [16] [12] [17] [11] [10] [18] [20] [19] [1] 9xWall Plugs [11] 2xMagnetic Seals [2] 8xFlat Screws M4x35 [12] 1xBracket [3] 8xScrews M4x10 [13] 1xWall Connector [4] 8xScrew Cover Caps...
- Page 6 INSTALLATION Before starting: Ensure floor area for installation is completely level. Walls must be plumb to within 5mm over the height of the screen. Check-measure that the screen size shown on the packaging suits the intended installation area.
- Page 7 INSTALLATION Step 3 Door Panel Fixed Panel Down View from inside Step 4...
- Page 8 INSTALLATION Step 5 Step 6 Ensure wall profiles are plumb. Adjust enclosure to be square and level. Wheels should be adjusted to square the doors and ensure smooth running.
- Page 9 INSTALLATION Step 7 3.2mm Screw M4x10 View from inside Step 8 24 hours Allow 24 hours for silicone to dry before using shower.
- Page 10 CARE INSTRUCTIONS This screen has been treated with easy-to-clean glass surface treatment. Please follow the care instructions to ensure your treatment is long lasting. After use, your shower should be cleaned with a mild detergent and water.
- Page 11 This product is covered by a 2 year product replacement and a 1 year parts and replacement warranty. Refer to www.johnsonsuisse.com.au for full warranty terms and conditions. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for the major failure and for compensation for any other reasonably foreseeable loss or damage.
- Page 12 FOR FURTHER INFORMATION PLEASE CONTACT YOUR NEAREST BPA OFFICE: HEAD OFFICE (SYDNEY) ADELAIDE 2/97 Banksia St. Botany, NSW 2019 T 0499 221 201 T 1300 717 717 F 1800 225 315 F 1300 746 480 E bpa.info@johnsonsuisse.com.au...
