Command center for ductfree split systems
Hide thumbs Also See for XK41:

Advertisement

Submittal Data: XK41
Job Name
Purchaser
Submitted To
Unit Designation

GENERAL FEATURES

- Large Easy to Read LCD Display
- Tactile Feedback Keypad
- Easy Setup and Programming
- Sleek Thin Design Blends into any Décor
- Convenient LCD Display Backlighting
- Reaches up to 26 feet.
- Ready to use cable included.
- No Batteries Required
Compatible with the following Models:
XK41 Command Center allows fast & easy access to a large number. The following is a list of typical system
features and functions support by the X41 controller:
Note: Some indoor models may not support specific system features or functions.
On/Off - The On/Off button allows you to start and stop the system.
Operating Mode - Allows users to select an operating mode (i.e. Cooling, Heating, Dry, and Fan Only).
Fan Speed -The indoor fan (i.e. High, Medium, Low & Auto) can be adjusted for peak comfort and quietness.
Room Setpoint – Adjust room setpoint temperature between 61 deg F to 86 deg F (16 ~ 30℃ range).
Timer Mode - Program a time period (i.e. 0.5-24 hr.) to which the system will turn ON or OFF.
Sleep Mode – Automatically adjust room temperature during your sleep time (i.e. 0.5-24 hr. range).
Turbo Mode – Turbo will force system to run at higher speeds to reach the desired room temperature faster.
X-fan Mode - Removes moisture build up on coil when the system is turned OFF to prevent mold and mildew.
Privacy Lock - Privacy Lock to prevent unauthorized access to the controls and tampering with system settings.
*** Additional system features and functions my be found in the indoor unit Owner's Manual. ***
Indoor Models
Neo+ Wall Mount XK-41
Terra Wall Mount XK-41
Evo+ Wall Mount XK-41
Always refer to the indoor unit Owner's Manual.
© Gree Corporation 2014
XK41 Command Center for Ductfree Split Systems
Location
Date
Engineer
For
Reference
Schedule No.
Wired Controller
Type
Part Number
MC207059
MC207059
MC207059
V1
Construction
Approval

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XK41 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gree XK41

  • Page 1 Evo+ Wall Mount XK-41 MC207059 XK41 Command Center allows fast & easy access to a large number. The following is a list of typical system features and functions support by the X41 controller: Note: Some indoor models may not support specific system features or functions.
  • Page 2 DIMENSIONAL SPECIFICATIONS Units: inch (mm) XK41 Command Center for Ductfree Split Systems Dimensions Type Part Number 1.375 (35) XK-41 MC207059 3.625 (92) 3.625 (92) SYSTEM WIRING DIAGRAM Max 26 Ft Interconnecting Wire (Factory Supplied) www.greecomfort.com Specifications are subject to change without notice. Manufacturer reserves the right to discontinue or modify specifications or designs without notice or without incurring obligations.
