Page 4
SZU06C1 Product Manual Module features Mini 33-pin stamp-like SMT package interface U.FL interface for external SMA antenna Firmware upgrade via serial port Small form factor: 19 mm x 25 mm x 3.7 mm Hardware Supported AES-128 encryption ...
The maximum output power of RF chip is 19.5dBm, and the receive sensitivity is -101dBm typically. Module Chip FLAH Sealing Dimension SZU06C1 EFR32MG1B232 256KB 32KB 19mm * 25mm * 3.7mm Table 1- 1 Model of SZU06C1 Module The SZU06C1 is used for ZigBee applications (www.zigbee.org). If you want to develop your SZU06C1 PM(Rev 1.0)
Ember Z-net_5.9.0 or later protocol stack of Silicon Labs. 2 Approvals 2.1 CE Approvals(ETSI) SZU06C1 ZigBee wireless communication module is certified CE at the power level of 8dBm by the following standards: EMC: Draft ETSI EN 301 489-1 V2.2.0:2017 ...
SZU06C1 Product Manual The "CE" marking must be placed in a prominent position of OEM products. Please refer to http://ec.europa.eu/enterprise/faq/ce-mark.htm for more information about CE certification mark. Important tips: In Europe, frequency band of 2.4GHz is used only for the equipment with the maximum equivalent isotropically radiated power (e.i.r.p.) of less than 10mW(10dBm).
Page 8
SZU06C1 Product Manual Channel 11-25 Channel 26 16dBm 10dBm Table 2-2 Maximum Power Settings for FCC FCC caution: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
SZU06C1 Product Manual 2.3 ATEX Approvals The SZU06C1 ZigBee wireless communication module has been tested to comply with the ATEX 2014/34/EU regulation about explosion proof products. Intended Use:Zone 2 GAS. This device meets the following parameters: U =3.9V, I =1A, P=0.98W, C =15.32 μF, L =5.64μH, -40 ...
Page 10
SZU06C1 Product Manual The maximum input parameters stated above shall be considered during installation. The rules for interconnection of intrinsically safety circuits according EN 60079-11 and EN 60079-14 have to be taken into account. The maximum service temperature of the communication module when incorporated into apparatus is -40°C to +80°C.
3 Module Pinout Fig. 3- 1 SZU06C1 Pinout (top view) In order to facilitate the user to develop and design the products based on SZU06C1 ZigBee wireless communication module, we have detailed the pin information of SZU06C1 ZigBee wireless communication module in the following Table 3-1.
Page 12
System Power Supply,see note 2 System GND. Table 3- 1 Description of SZU06C1 Pinout Notes: Low level is adopted for system reset. In case of nRESET=’0’, the module is staying in reset state, and the low level time should be longer than 20μs.
4 Hardware Description 4.1 Hardware Diagram Fig. 4-1 Hardware Diagram of SZU06C1 SZU06C1 wireless communication module is based on EFR32MG1B2321 chip from Silicon Labs, which integrates the RF transceiver complying with 2.4-GHz IEEE 802.15.4, high performance 32-bit ARM 40MHz Cortex ®...
32.768 Table 4-1 SZU06C1 Interface Characteristics SZU06C1 ZigBee wireless communication module provides a U.FL interface for attaching one external SMA antenna or a PCB antenna. In order to obtain the module’s optimal RF performance, it is recommend to use the antenna and feeder provided by our company.
5.2 Customized firmware For customers who have batch requirements of SZU06C1 module, we can customize the firmware on their demand. SZU06C1 PM(Rev 1.0)
SZU06C1 Product Manual Absolute Maximum Ratings Parameter Symbol Min value Max value Unit Note Supply voltage -0.3 Supply current 1000 Pin voltage -0.3 RF input level Output power 19.5 Storage temperature range ℃ Operating temperature ℃ range Reflow temperature Lead-free soldering ℃...
SZU06C1 Product Manual 6.2 Recommended operating conditions Parameter Min value Typical value Max value Unit Environment Supply voltage RF input power RF frequency 2405 2480 Operating temperature ℃ Relative humidity Table 6-3 Recommended Operating Conditions 7 DC Electrical Characteristics 3.3V,T 2400MHz 2483.5MHz.
From EM4H to wake 20μs e m h w u From EM4S to wake 290μs s w u Table 7-1 DC Electrical Characteristics of SZU06C1 8 Digital IO Specifications 3.3V,T ℃. Parameter value Parameter Test conditions Min.
SZU06C1 Product Manual AC Electrical Characteristics V =3.3V,T =25 ,SZU06C1 connected a SMA aten na with 50Ω load ℃ Parameter Test conditions Typ. Unit Frequency range 2400 2500 See Table 9-2 for the correspondence Channel number CH11 CH26 between channel and...
Page 20
Actual minimum output Output power at lowest power power setting:-26dBm Table 8-1 RF Characteristics of SZU06C1 RF Transceiver Notes: Reference sensitivity level is -85 dBm. Filter is characterized as a symmetric band-pass centered on the adjacent channel having a 3dB bandwidth of 4.6 MHz and stop-band rejection better than 26 dB beyond 3.15 MHz from the adjacent carrier.
SZU06C1 Product Manual 10 Physical Dimensions and Footprint 10.1 Physical Dimensions Fig. 10-1 Physical Dimensions of SZU06C1 Parameter Parameter Description Parameter value Module width 19mm Module length 25mm Distance between semi-holes 1.27mm Distance from semi-hole to PCB 0.8mm Distance from U.FL center to PCB edge Distance from U.FL center to PCB edge...
10.2 Recommended Footprint Fig. 10-2 Recommended Footprint of SZU06C1 Notes: 1. When the surface mounted SZU06C1 ZigBee wireless communication module is used, it is suggested that the bonding pad shall be 1mm wide and 1.2mm high. 2. L=25mm. 3. You must ensure that the corresponding PCB of “keep-out area” part in Fig. 3- 1shall have no any device, running line or applied copper.
11 Soldering Temperature Time Profile (for reflow soldering) 11.1 Recommended temperature time profile for lead-free solder Fig. 11-1 SZU06C1 Temperature Profile for Lead-free Solder Notes: Preheat: The recommended temperature climbing speed shall be 2℃/s and not exceed 2.5℃/s at the preheat area.
SZU06C1 Product Manual 12 Reliability Test To guarantee the environment adaptability of SZU06C1, we have done the the following measurements. Test items Test methods Setting the vibration frequency of 50Hz, amplitude of 1.5mm, Vibration test and each side of XYZ vibrates for 20 minutes respectively...
13 Application Precautions 13.1 Safety precautions Before use of SZU06C1, check and evaluate their operation when mounted on your products . These products may short-circuit. If electrical shocks, smoke, fire, and/or accidents involving human life are anticipated when a short circuit occurs, then provide the following failsafe...
(5)Mechanical stress shall be avoided in assembly or operation of SZU06C1. (6)Do not press the shielding cover or tighten the objects to the shielding cover (7)When the SZU06C1 is working, the safe distance between it and human body must be greater than 20 centimeters.
SZU06C1 Product Manual Fig. 14-4 Orientation of SZU06C1 14.2 Reel Fig. 14-5 Reel Dimensions Each reel will be packed in a electrostatic shielding bag SZU06C1 PM(Rev 1.0)
19mm * 25mm * 3.7mm Visible barrier-free communication distance is 2500m 16 Drawing of Product Label Fig. 15-1 SZU06C1 Product Label The label dimensions are 15.2mm*17mm and the label will withstand temperatures used during reflow soldering. SZU06C1 PM(Rev 1.0)
We reserve the right to modify or improve the product, company name and LOGO at any time without prior notice. In addition, Chengdu Diyue Technology Co., Ltd. does not convey any license under its patent rights or assume any responsibility for the use of the described product.
19 Data Sheet Status In order to improve design performance and supply the best possible products to customers, Chengdu Diyue Technology Co., Ltd. reserves the right to change the product specifications without notice. Please download the latest product specifications provided by our company before initiating or completing one design.
