Summary of Contents for ECX BARRAGE ECX00018T1
- Page 1 1/24 SCALE 4WD ELECTRIC FPV UTILITY VEHICLE INSTRUCTION MANUAL BEDIENUNGSANLEITUNG MANUEL D’UTILISATION MANUALE DI ISTRUZIONI ECX00018T1/ECX00018T2...
-
Page 2: Meaning Of Special Language
NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit http://www.horizonhobby.com and click on the support tab for this product. MEANING OF SPECIAL LANGUAGE The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious injury OR create a high probability of superficial injury. -
Page 3: Box Contents
Box Contents • Barrage FPV Utility Vehicle ® ® • 2-CH Transmitter (ECX10003) • AA (4) Batteries • USB 4.8V NiMH Charger (DYNC1060) • NiMH, 220mAh, 4.8V (DYNB0007) • Spektrum Video Monitor (SPMVM435) ™ Specifications Transmitter Video Transmitter Frequency 2404 MHz – 2476 MHz Input voltage 2.5–5V Battery... -
Page 4: Getting Started
Getting Started Charge the Vehicle Battery Refer to charging warnings. 1. Connect the battery to the battery charger. 2. Connect the battery charger to a powered USB. 3. The battery will charge in under 2 hours. The LED sequence for the USB charger is Red = charging, Green = charge is complete. -
Page 5: Transmitter Controls
Transmitter Controls THROTTLE TRIGGER Reverse STEERING WHEEL Controls steering. Forward Stop Right and Left Controls power to the motor steering for forward or reverse REVERSE SWITCH BATTERY LEVEL INDICATOR Solid Red and Green: Battery voltage is good (above 4V). Solid Red: Battery voltage is critically low (below 4V). - Page 6 Power on the vehicle Installing Your Transmitter Batteries CAUTION: NEVER remove the transmitter batteries while the model is powered on. Loss of model control, damage or injury may occur. CAUTION: If using Re-install the body on the rechargeable batteries, vehicle charge only rechargeable batteries.
- Page 7 Wireless Video System NOTICE: If you are operating this product in North Select the video frequency America, you are required to have an Amateur Radio (HAM) license. Visit www.arrl.org for more information. Video Transmitter (VTX) Button The video transmitter channel and band are changed using the button on the left side of the Shown with tire removed for clarity.
- Page 8 Video Monitor controls 5.8GHz Antenna connector Menu Buttons: Use the + and – buttons to make changes: Frequency Band Button Single push to change band Channel Selection Button Single push to change channel Micro Memory Card Slot AV In ON/Off Switch Charge Status LED Red = charging Green = charged...
- Page 9 When You Are Finished Binding Troubleshooting Binding is the process of programming the receiver to recognize the GUID (Globally Unique Identifier) Power off the vehicle code of a single specific transmitter. The included transmitter and receiver are bound at the factory. If you need to rebind, follow the instructions below.
-
Page 10: Troubleshooting Guide
Troubleshooting Guide Problem Possible Cause Solution Battery damaged/not charged Check/change battery Short run time Motor dirty Check/clean Motor dirty Check/clean Sluggish action Bind in drivetrain Clean/adjust Vehicle battery is not charged Replace/recharge Controls reversed ST. REV or TH. REV Change switch position Conditions too challenging for Avoid driving in grass, mud, and other Motor/ESC overheat... -
Page 11: Limited Warranty
Limited Warranty What this Warranty Covers STRICT LIABILITY OR ANY OTHER THEORY OF LIABILITY, EVEN IF HORIZON HAS BEEN ADVISED Horizon Hobby, LLC, (Horizon) warrants to the OF THE POSSIBILITY OF SUCH DAMAGES. Further, original purchaser that the product purchased (the in no event shall the liability of Horizon exceed the “Product”) will be free from defects in materials individual price of the Product on which liability... -
Page 12: Warranty Requirements
damaged parcels, as Horizon is not responsible for Non-Warranty Service merchandise until it arrives and is accepted at our Should your service not be covered by warranty, facility. An Online Service Request is available at service will be completed and payment will be http://www.horizonhobby.com/content/service- required without notification or estimate of the center_render-service-center. -
Page 13: Fcc Information
FCC Information IC Information FCC Statement IC Information FCC ID: XNZKTH91802G IC: 20264-KTH91802G This equipment has been tested and found This device complies with Industry Canada license- to comply with the limits for Part 15 of exempt RSS standard(s). Operation is subject to the the FCC rules. - Page 14 ECX203003 ECX202034 ECX202032 DYNS1203 ECX202032 ECX202034...
- Page 15 REAR ASSEMBLY RÜCKENMONTAGE ASSEMBLAGE ARRIÈRE MONTAGGIO POSTERIORE ASSEMBLED GEBAUT ASSEMBLÉ ASSEMBLATO ECX202031 ECX206003 ECX202033...
- Page 16 FRONT ASSEMBLY FRONTMONTAGE ASSEMBLAGE AVANT MONTAGGIO ANTERIORE ASSEMBLED GEBAUT ASSEMBLÉ ASSEMBLATO ECX202030 ECX202033 ECX206003 ECX202033...
- Page 17 ECX201015 ECX206003 ECX201015 ECX201016 ECX206003 ECX201015 ECX201016 ECX206003 REAR RÜCKSEITE ARRIÈRE POSTERIORE ECX206003 ECX206003...
- Page 18 FRONT VORDERSEITE AVANT ANTERIORE ECX206003 Scale Accessories | Zubehör skalieren Use a #48 (.076in/1.93mm) drill bit to punch holes for mounting detail parts. ECX200020 Verwenden Sie einen # 48 (1.93mm) Bohrer, um Löcher für die Montage von Einzelteilen zu stanzen. ECX200020 ECX200020 Accessoires d’échelle |...
- Page 19 ECX200020 ECX200020 ECX200020 BLH8517EU REPLACEMENT PARTS / ERSATZTEILE / PIÈCES DE RECHANGE / PEZZI DI RICAMBIO Part # Description Beschreibung Description Descrizione ECX201015 Chassis Supports Karosserieträger Supports de châssis Supporti telaio Ensemble d’arbre ECX202034 Drive Shaft Set Antriebswellensatz Kit albero trasmissione d’entraînement ECX202032 TRANSMISSION:...
- Page 20 REPLACEMENT PARTS / ERSATZTEILE / PIÈCES DE RECHANGE / PEZZI DI RICAMBIO Part # Description Beschreibung Description Descrizione ECX206003 HARDWARE SET HARDWARESATZ ENSEMBLE DE MATÉRIEL SET BULLONERIA SPMVX5801 FPV Antenna FPV Antenna FPV Antenna FPV Antenna Moniteur vidéo FPV 4.3“ 4.3"...
- Page 21 ® ECX00018T1 | ECX00018T2 www.ecxrc.com © 2018 Horizon Hobby, LLC. ECX, the ECX logo, Barrage, Dynamite, and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. Created 08/2018 58318...
