Summary of Contents for Racegeek d10
- Page 1 Tactical Racing Display InsTRucTIons foR use v1.3...
- Page 2 medium...
-
Page 3: Table Of Contents
THE D10 IS A TACTICAL RACE TOOL AND SHOULD NOT BE RELIED ON FOR NAVIGATION. Contents See the “Safety and Product Information Manual” for this product at racegeek.ie for product warnings, safety statements, Declaration of Conformity, warranty and other important InTRoDucTIon information. -
Page 4: Introduction
Depth sensor offset Tide/current navigation overview Turning Angle Auto Acquire Marks Auto Progress course Additional settings Configure Navigation Mode Configuration InTRoDucTIon Configure Marks & Courses Manually choose Marks Wind overview seTTInGs settings specs Maintenance... -
Page 5: D10 Layout
Repeater The d10 is designed to provide you the information you need, when you need it. The display layout consists of four elements: Top Digits, Middle Digits, Graphic Smart Repeater mode is started by changing “Display Mode” in on the a10 Display and Touch Controls as shown in the illustration below. -
Page 6: Tactical Compass
Tactical Compass mode is started by changing “Display Mode” in Settings on the a10 app to “Full” or “Sport”. In Tactical Compass Mode “Full” the d10 displays information broken down into five pages: Prestart, Performance, Tide-Depth, Navigation and Wind. In Tactical Compass Mode “Sport” the d10 displays information broken down into three pages: Prestart, Performance, Tide-Depth. -
Page 7: Tactical Compass Overview
You can cycle though the screens back to your original screen by continuing to libraries. The d10 does not require the app to work on the water while racing, however touch the arrow in either direction. the a10 adds additional functionality by displaying the data streamed from the d10 in additonal formats and provides context specific remote and display functionality. -
Page 8: A10 App Overview
App overview change settings Manage Marks control d10 InITIAL seTuP Context Specific Remotes start, navigation, Wind Get highly detailed context specific information on the race course Multiple View Modes Daylight, night, color Modes to optimize viewability in all conditions... -
Page 9: Registration
App. To register racegeek.io Register at racegeek.Io your device you will need the d10’s UUID and DEVICE PIN - found in the documentation that came with your d10. create Account It is important to register your d10 at your first opportunity to prevent losing your security information. -
Page 10: Connect A10 App To D10
To make changes to the d10 via the a10 app you must be connected to the d10’s WiFi access point with the mobile or tablet the a10 app is installed on. You connect to the d10 by WiFi the... -
Page 11: Prestart Overview
Behind Line Distance To Line Down Arrow over Line The distance the d10 is from the start line measured perpendicular to the line. Timer Timer < 1 minute DTL offset Correction for the additional distance the d10 is from the bow of the boat. -
Page 12: Capture Line
To activate Distance To Line functionality, the Pin and Race Committee You can create a fixed start line using mark waypoints in the d10. Once fixed line is set you return to Prestart screen you will have Distance To Line functionality. -
Page 13: Timer
Timer Performance overview When the timer countdown hits zero the d10 automatically changes to display The Performance page can be accessed by touching the left the Performance Page and the timer begins counting the race duration. or right arrows in the touch controls until the graphic display shows “PERFORMANCE”... -
Page 14: Mean Wind
Mean Wind Before and After start open menu Before the start (when the countdown is not zero) the d10 builds up an average based on the readings taken each time you press the circle button. By capturing the mean ... -
Page 15: Shift Tracking
Tide/Depth overview shift Tracking The d10 uses the saved Mean Wind Direction compared to the boat’s current The Tide-depth page can be accessed by touching the left or right arrows in the heading to show changes in wind direction. After the start you can reset the touch controls until the graphic display shows “TIDE-DEPTH”... -
Page 16: Depth Sensor Offset
If Auto Switch is set to yes in the d10 Settings on the a10 App - when the boat turns downwind (below 80° of the mean wind direction) the d10 automatically changes to the Navigation page. -
Page 17: Turning Angle
Downwind When Navigation Mode in settings is set to: Course Mode, the d10 uses the current GPS position, saved mark GPS position and the Waypoint Arrival Distance to auto progress the course to the next saved mark. The Waypoint Arrival Distance can be changed in the d10 settings. -
Page 18: Additional Settings
Windward and Leeward Marks are fixed and manually entered based on distance and bearing from start line using a10 app. fixed Navigates route of marks sent to the d10. Auto advances route based on proximity set in Settings. Additional settings Arrival Distance - Sets the distance in meters from a mark that route advances. - Page 19 Manage Marks Manage courses View/sort Marks View/edit courses select mark from list select order Icon to sort select search Icon, select “courses” to swipe left to show course Detail screen View, Re-order, Add or swipe mark and Marks choose which filed to see all saved courses option to edit or Pops up.
-
Page 20: Manually Choose Marks
Apparent Brng Manually choose Marks Wind speed Waypoints that have been loaded onto the d10 can be selected manually from the Wind magnetic bearing Navigation menu at any time during a race. open Menu speed and WInd ... -
Page 21: Settings
The d10 settings can only be changed from the free a10 companion app. The app can be downloaded below: seTTInGs Manage settings Touch a setting you open side Menu choose “d10” to change settings wish to change and and select “settings”... - Page 22 Turn on/off d10 automatic page switching No, Yes Inclinometer In auto mode the d10 changes pages at the end of the countdown and when you change between windward and leeward PITcH offseT Compensates for any error in tilt of the d10 fore and aft...
-
Page 23: Specs
Maintenance The d10 is totally sealed against water and is not serviceable. General connectivity Any attempt to take the d10 apart will invalidate the warranty. • 190mm x 136mm x 24mm • NMEA0183 To clean, use only a damp soft cloth. No detergents, solvents or abrasives should be used.
