- Page 1 PI MANUFACTURING Powered by In nite Solutions 5.8GHz Wireless Outdoor CPE with DIP Function ANT-3526-H Installation Manual PI Manufacturing, www.pimfg.com...
-
Page 2: Table Of Contents
Product Features Contents Overview Package Includes Hardware Connection Web Interface IP Settings Management Typical Application DIP Switch Con gurations 8-15 Signal Strength Information Installation Notes 17-19 Frequently Asked Questions Speci cations PI Manufacturing, www.pimfg.com... -
Page 3: Overview
5.8GHz wireless outdoor CPE extends devices across buildings of varying distances via point-to-point or point-to-multi-point connecctions. Utilizing the Qualcomm AR9344 chipset, the ANT-3526-H delivers reliable and robust wireless connectivity. The outdoor CPE supports distances up to 4km or 13123 feet, useful for many installation scenarios where long distance is necessary. -
Page 4: Hardware Connection
Slide cover up when all the connections are nished * This wireless access point antenna is only compatible with the provided PoE injector. The antenna will not power up if used with a third party PoE device. PI Manufacturing, www.pimfg.com... -
Page 5: Web Interface
Go into your preferred web browser, and type the following into the web address. http://172.18.0.1 https://172.18.0.1 The default password is “password. ” (Once logged in, we recommend that you change the password to a more secure one. PI Manufacturing, www.pimfg.com... -
Page 6: Web Interface
Status > Overview > Connected Hosts System > Transmit Power > Mode > Router Access > Time > Backup / Restore > Update Firmware > Reboot Logout Note: For detailed options, view them on the web interface PI Manufacturing, www.pimfg.com... -
Page 7: Ip Settings Management
9 and 10 based on positions 9 and 10 Positions 2 - 8 Positions 2 - 8 in the down position in the down position is assigned to the IP segment 172.18.0.x is assigned to the IP segment 172.18.0.x PI Manufacturing, www.pimfg.com... -
Page 8: Typical Application
IP camera up to 4km or 13123 feet. Up to 4km for long distance communication Transmitter Receiver Camera 1 1 2 3 4 5 6 7 8 9 10 1 2 3 4 5 6 7 8 9 10 172.18.0.1 172.18.0.2 PI Manufacturing, www.pimfg.com... - Page 9 1 2 3 4 5 6 7 8 9 10 172.18.0.2 172.18.0.3 Camera 3 Camera 4 1 2 3 4 5 6 7 8 9 10 1 2 3 4 5 6 7 8 9 10 172.18.0.4 172.18.0.5 PI Manufacturing, www.pimfg.com...
-
Page 10: Dip Switch Con Gurations
2 3 4 5 6 7 8 No.14 172.18.13.x 5200 2 3 4 5 6 7 8 No.15 172.18.14.x 5240 2 3 4 5 6 7 8 No.16 172.18.15.x 5745 2 3 4 5 6 7 8 PI Manufacturing, www.pimfg.com... - Page 11 2 3 4 5 6 7 8 No.30 172.18.29.x 6025 2 3 4 5 6 7 8 No.31 172.18.30.x 6045 2 3 4 5 6 7 8 No.32 172.18.31.x 6065 2 3 4 5 6 7 8 PI Manufacturing, www.pimfg.com...
- Page 12 2 3 4 5 6 7 8 No.46 172.18.45.x 5220 2 3 4 5 6 7 8 No.47 172.18.46.x 5240 2 3 4 5 6 7 8 No.48 172.18.47.x 5745 2 3 4 5 6 7 8 PI Manufacturing, www.pimfg.com PI Manufacturing, www.pimfg.com...
- Page 13 2 3 4 5 6 7 8 2 3 4 5 6 7 8 No.64 No.64 172.18.63.x 172.18.63.x 6065 6065 2 3 4 5 6 7 8 2 3 4 5 6 7 8 PI Manufacturing, www.pimfg.com PI Manufacturing, www.pimfg.com...
- Page 14 2 3 4 5 6 7 8 No.78 172.18.77.x 5220 2 3 4 5 6 7 8 No.79 172.18.78.x 5240 2 3 4 5 6 7 8 No.80 172.18.79.x 5745 2 3 4 5 6 7 8 PI Manufacturing, www.pimfg.com...
- Page 15 2 3 4 5 6 7 8 No.94 172.18.93.x 6025 2 3 4 5 6 7 8 No.95 172.18.94.x 6045 2 3 4 5 6 7 8 No.96 172.18.95.x 6065 2 3 4 5 6 7 8 PI Manufacturing, www.pimfg.com...
- Page 16 2 3 4 5 6 7 8 No.110 172.18.109.x 5220 2 3 4 5 6 7 8 No.111 172.18.110.x 5240 2 3 4 5 6 7 8 No.112 172.18.111 .x 5745 2 3 4 5 6 7 8 PI Manufacturing, www.pimfg.com...
- Page 17 2 3 4 5 6 7 8 No.126 172.18.125.x 6025 2 3 4 5 6 7 8 No.127 172.18.126.x 6045 2 3 4 5 6 7 8 No.128 172.18.127.x 6065 2 3 4 5 6 7 8 PI Manufacturing, www.pimfg.com...
-
Page 18: Signal Strength Information
• 1st, 2nd lights on: signal is weak. • 1st, 2nd, 3rd lights on: the signal is regular. • 4th light on: the signal is too strong. • All 4 lights are on: the signal is at its optimal condition. PI Manufacturing, www.pimfg.com... -
Page 19: Installation Notes
• Adjust the angle based on the transmitting signal (viewable from the physical CPE and the web interface) for the best performance. For the best performance, move the CPE higher up to avoid obstructions and increase line of sight. PI Manufacturing, www.pimfg.com... - Page 20 Angle Adjustment Line of Sight PI Manufacturing, www.pimfg.com...
- Page 21 Make sure the transmitter and receiver are at least 2 meters apart or else interfer- ence may occur. At least 2 meters apart PI Manufacturing, www.pimfg.com...
-
Page 22: Frequently Asked Questions
A1: The SSIDs should be di erent for separate AP groups, otherwise there may be interference. Q1: Does the CPE include lightning protection? A1: No. Is is recommended to install a lightning conductor to avoid burning out the link port. PI Manufacturing, www.pimfg.com... -
Page 23: Speci Cations
MAC Address Control Encryption WEP 64/128bits, WPA, WPA2, 802.1x Operating Temperature -30 to +65° C -50 to +80° C Storage Temperature Humidity ≤95% (Non-condensed) Dimensions (L x W x H) 205 x 205 x 132.3mm 0.5kg (1 lbs) Weight PI Manufacturing, www.pimfg.com...
