Alemlube 6603A Owner Technical Manual

DESCRIPTION

The 6603A multi-purpose fluid sprayer is an industrial quality sprayer manufactured with highly resistant materials for
use with animal and vegetable oils, hydrocarbon based solvents, lubricants and petroleum products in applications
such as brake cleaning, tar removal from vehicle bodies and tools, machinery and motor cleaning, lubricant application,
degreasing, waterproofing and de-waxing fluids. It is not however suitable for use with acids.
The easily accessed and wide filling opening provides a real benefit for safe and minimal spill filling of up to 1.45 litres
of fluid and its ergonomic design makes it a pleasure to use.
Designed with one of the most user friendly pull/push handles the 6603A also features a 2.5 bar safety valve with
depressurisation option, strong translucent tank with level indicator, protective valve chamber sleeve and adjustable
conical nozzle.
A must for all automotive workshops, construction sites and industry in general, the 6603A multi-purpose fluid sprayer
available from Alemlube is ideal for a wide range of cleaning activities and protective fluid applications.

TECHNICAL SPECIFICATIONS

Total capacity
Useful capacity
Net weight
Gross weight
Maximum pressure
Litres/min
Joints and materials resistant to oils and most hydrocarbons
and solvents
2.5 bar safety valve
Large filling aperture
Ergonomic design
Strong translucent tank with level indicator
Protective sleeve for valve chamber
Easy assembly and disassembly for maintenance
1
2
NSW/ACT QLD/PNG
TEL: (02. 9677 1555 TEL: (07. 3204 9166
FAX: (02. 9675 1155 FAX: (07. 3204 1224
Visit our website at
OWNER'S TECHNICAL MANUAL
Multi-Purpose Fluid Sprayer
1.5 Litres
1 Litre
0.46 kg
0.60 kg
2.5 bar - 42 psi
3 bar: 0.50 L/min
MAX.
X 15
1L
VIC/TAS
TEL: (03. 8787 8288
FAX: (03. 8787 8266
www.alemlube.com.au
3
4
WA SA/NT
TEL: (08. 9302 4199 TEL: (08. 8241 7111
FAX: (08. 9303 2095 FAX: (08. 8241 7011
or www.alemlube.co.nz
6603A
30º
5º
NZ
TEL: (09. 447 1007
FAX: (09. 447 1008
