PX A51 Product Manual

Night vision hd dashcam
Hide thumbs

Advertisement

Quick Links

Download this manual
Night Vision HD Dashcam
Product Manual
<Release V.01>

Advertisement

loading
Need help?

Need help?

Do you have a question about the A51 and is the answer not in the manual?

Questions and answers

Related Manuals for PX A51

Summary of Contents for PX A51

  • Page 1 Night Vision HD Dashcam Product Manual <Release V.01>...
  • Page 2 Thanks for purchasing A51 Dashcam from PX, please read this manual before using the Dashcam. Make sure the items in the package are complete, if any shortage or damage is found, pleasecontact the original vendor immediately. The contents of this manual are subject to change without notice 1、Product packaging content...
  • Page 3 1、Product packaging content Charging cable USB Cahrger HD Dashcam (use only original one) (use only original one) Suction Cap Holder Product Manual (with 3 small suction caps) <Release V.01>...
  • Page 4 2、Quick Installation Guide Step 1 Micro SD card Installation(support up to 32G) ● Insert the Micro SD card horizontally into the Dashcam’s memory card slot. ※ Insert memory card with wrong direction may cause damage to the card slot and the memory card itself. ※...
  • Page 5 Step 3 Format the SD Card Format ● In order to maintain the stability of the video recording, 系統設定 > 格式化 系統設定 > 格式化 > YES please insert the memory card into the dash cam and format it when first time useage. And be sure to format it monthly.
  • Page 6 Installation of the Dashcam Step 5 ● Fasten the screw of holder to the 1/4” of HD CAM ● Adjust the direction to make the best position. Install the Power Supply Step 6 ● Connect the charging cable to the USB charger and press the USB charger into the car cigarrete lighter position ※Use only original one...

  • Page 7: Product Appearance Introduction

    3、Product Appearance Introduction Dashcam(Front)
  • Page 8 Dashcam(Back) Name Description Lens 6 pieces of glass lens Microphone Use to record voice, can be turn off. RESET Forced shutdown Manually turn on/off the dashcam. Press 2 sec Power Switch to manually turn off, press 8 sec. to force restart.
  • Page 9 Name Description Operation Indicator: 【Standby】Red light constantly 【Recording】Red light flashing 【Charging】Green light flashing ※ The red/green lights are independent. Output screen to TV( Output only when browsing videos Mini HDMI output port ※ Please prepare your own wire. For the first time useage, be sure to fomatting the SD Micro SD Memory card slot card to increase the stability of it.
  • Page 10 Name Content Function Reserved Speaker Play the sound Screen 2.4” LED screen Mode(Short Press)： Menu Short press once：Switch between Dashcam/Recording/Playback/ Menu Key System Setup modes, once entering the menu this key acts as Return Key return key. 1.Dashcam mode：Acts as Start/Stop Recording key. 2.In each Menu, this key acts as “Next”...
  • Page 11 4. User Interface Navigation & Functional Introductions 00:25 Recording Mode 2016/11/03 04:21:18...
  • Page 12 Name Description System Mode Recording Mode SD card is installed No SD card SD Card Detection SD card is full Bad SD card Motion Detection Motion detection is currently ON. WDR is currently ON. Star the file Lock when collide. Backup Lock ※...
  • Page 13 Name Description Mic (Recording) Recording with sound Recording without sound System Time Current system time: Year/Month/Day Hour/Minute/Second G-sensor Lock File This function is triggered...
  • Page 14 While standby in the recording mode, press Recording Functional Interface key to enter the Recording menu. Use key to Recording Setup > Resolution select function, always press key to confirm your selection. ※ During recording, you have to stop recording by pressing REC key to enter functional interface menu.
  • Page 15 Icon Name Description Motion Detection Max. Heigh Heigh Med. Gravity Sensor Lower Very Low Mic Setup -0.7 -0.3 -0.7 -0.3 EV Value...
  • Page 16 20160104_022755 錄影模式 Playback Mode 00:22...
  • Page 17 Name Description Playback Mode Camera Mode System Mode SD card installed No SD card SD Card Detection SD card is full Bad SD card Current file name File Name Current battery level Charging Battery Capacity File length in recording time (minute:sec.) File Time...
  • Page 18 Playback Functional Interface While standby in the recording mode, press key to enter the Recording menu. Use key to Playback > Menu Selection select function, always press key to confirm your selection. ※ During recording, you have to stop recording by pressing REC key to enter functional interface menu.

  • Page 19: System Setup

    5. System Setup In Standby within Recordind mode, press key 3 times to enter “System Setup” menu. Use key to select your function and press to confirm your selection. ※ If in「Recording」, press「REC」key to stop the recording in order to enter the System Setup menu.
  • Page 20 Icon Name Description Date & Time Year/Month/Day Minute:Sec. Button Sound power Saving Mode 1 Minute 3 Minutes 5 Minutes Rotate the Screen Traditional Simplified Language English Chinese Chinese Delayed Shutdown 30 Sec. 60 Sec. Light Source 50Hz 60Hz Frequenccy Format Restore to Default Currently display firmware version, total space and System Infomation...
  • Page 21 7. Q & A ： The Dashcam could not start up after the car is started ： Ans. 1. Make sure the car charger LED is ON and the Micro USB connector is properly connected to Dashcam’s power port. 　　 2.
  • Page 22 Q4：I have other devices need to use the cigarette lighter Ans.：Please use an one-to-many cigaretter lighter power expansion set, and make sure the set is compliant to your local safety regulation and its Amperage is enough for all the devices to work properly. Q5：The video image playback on the computer screen is slightly shaking Ans.：1.
  • Page 23 ： When playback SD card’s video file on PC, there are some pauses Ans. : 1) Check if your PC meets the requirement : (CPU 2.0GHz, Memory 1GB and above) 2) Close all the resident programs in your PC. 3) Copy the video files into your PC first then playback. 4) Use other video player software.
  • Page 24 Q9：How to quickly identify the type of file？ Ans. : Use the computer to read the SD card then select the desired file by file name. % of capacity Beginning letter Item in SD card for the file snapshots Independent Folder event Time-slape Photos...
  • Page 25 Q10：Why when the Dashcam is connected with PC with a USB cable, the Dashcam could not be operate and it’s screen displays “Mass Storage”？ Ans. : When the Dashcam is connected with a PC, it becomes a storage Mass Storage device.

  • Page 26: Product Spec

    8. Product Spec. Item Description HD 2M SONY CMOS SENSOR Screen Size 2.4” Visual Angle 140 degree (FOV) Lens Aperture 6 glass lens f/1.8 WDR Wide Dynamic Support Audio/Video Output Support, Mini HDMI(for viewing videos only) ※Not included USB Specifications USB 2.0 External Memory Card Support up to 32GB micro SD (SDHC)
  • Page 27 Item Description Loop Recording Support 2/3/5 min. Internal Mic Support ON/OFF Automatic shutdown after Support Delay shutdown the vehicle is off Motion Detection Support ON/OFF Emergency Backup Support max. to 20% storage of the SD card ， Internal Lithium Battery Support 700mAh Lithium-polymer Recording while Charging...

  • Page 28: Special Notice

    9. Special Notice 1. Operation： (1) Prolonged usage of the Dashcam will cause temperature rise, this is normal and no need to worry. Please use it at ease. (2) Please do not hit heavily on the Dashcam nor the LED screen. (3) Keep hands dry when using the Dashcam to avoid failure due to the moisture.
  • Page 29 3. Memory Card Handling (1) It is recommended to use a Class 10 or higher level Micro SD card of 8GB or more with the Dashcam, and format it regularly to ensure stability of R/W for the recording files. Don’t unplug it during recording. Please plug/unplug it when the machine is off.
  • Page 30 4. Limited Warranty Statement (1) Dashcam can only be used as an auxiliary device. It can not guarantee driving safety or securing responsibility. Please drive carefully and take the initiative to avoid danger. (2) The video recorded by the Dashcam can only used for reference. It can not guarantee to be used as evidence of legal liability.
