3.1 Wiring
On the following pages are typical wiring diagrams for various types
of systems.
Note: Whilst every attempt has been made to ensure the accuracy of this
information it is recommended that the specifi c information relating to
the ancillary controls is obtained from the manufacturers concerned.
GB
ELECTRONICS
N/O
N/C
N L 1 2 3 4 5 6
ON
COM
OFF
TS975 ON A SET WALLPLATE
NOTE:
For mains voltage applications a link must be fi tted between
terminals L and 5.
SET1E
6
