Kit Contents
ICE-Base Unit
12V DC
28-Pin DIP Flex-POD for the
CY8C29466-24PXI
Blue CAT 5e Cable
Two 28-Pin DIP
MiniEval-
Samples
Evaluation and
(CY8C29466-
Programming
24PXI)
Board
Univeral 110/220
Power Supply
POD
ISSP Cable
PSoC
Designer CD-ROM
TM
Not Pictured
•C Compiler Activation Instructions
•PSoC Designer Release Notes
Backward
Compatibility
Adapter
USB 2.0 Cable
Web:www.cypress.com
Support: wwtw.cypress.com/support/
US: 800.669.0557 Intl: 425.787.4814
CY3215-DK
Getting Started Guide
Step 1:
Verify Kit Contents
KIT CONTENTS
•ICE-Cube In-Circuit Emulator Base Unit
•28-Pin DIP Flex-Pod for the CY8C29466-24PXI
•Two 28-Pin DIP Samples (CY8C29466-24PXI)
•MiniEval - Evaluation and Programming Board
•C Compiler Activation Instructions
•PSoC Designer CD-ROM
•PSoC Designer Release Notes
•USB 2.0 Cable
•ISSP Cable
•Universal 110/220 Power Supply
•European Plug Adapter
•Backward Compatibility Adapter
•Blue Cat 5e Cable (for Backward Compatibility)
•Getting Started Guide
See Reverse for images of kit contents
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Cypress MicroSystems CY3215-DK
- Page 1 Kit Contents ICE-Base Unit Univeral 110/220 Backward Power Supply Compatibility Adapter 12V DC CY3215-DK Getting Started Guide 28-Pin DIP Flex-POD for the ISSP Cable USB 2.0 Cable Step 1: Verify Kit Contents CY8C29466-24PXI KIT CONTENTS •ICE-Cube In-Circuit Emulator Base Unit Blue CAT 5e Cable •28-Pin DIP Flex-Pod for the CY8C29466-24PXI...
- Page 2 Step 2: Step 3: Support Install PSoC Designer Install PSoC Programmer Install from the included CD-ROM. For assistance refer PSoC Programmer is a separate application and must The following Application Notes and documents to PSoC Designer: Integrated Development be installed separately from PSoC Designer. Install are available at www.cypress.com/psoc Environment User Guide, available on the CD-ROM.
