- Page 1 V8-04.18 Assembly Instructions Miami Swing (W x D x H) 1.89m x 1.62m x 1.80m Pressure Treated products should not be treated with any other products for the first month. PLEASE KEEP THIS INSTRUCTION Zest4Leisure 01352 752555 option 1 – sales@zest4leisure.co.uk...
- Page 2 Miami Swing Assembly Instructions Requires 2 person assembly. PLASTIC STRAPPING ON CANOPY SLATS IS TO REMAIN FIXED AND SHOULD NOT BE REMOVED BY THE CUSTOMER Tools required: Corded / Cordless Drill, Pozi-drive Bit / Screwdriver, Socket Set, Hammer. 3mm Drill Bit, required in order for you to drill all screw holes before construction.
- Page 3 Miami Swing Assembly Instructions Requires 2 person assembly. Tools required: Corded / Cordless Drill, Pozi-drive Bit / Screwdriver, Socket Set, Hammer. 3mm Drill Bit, required in order for you to drill all screw holes before construction. Left Right Notched holes face inwards...
- Page 4 60mm screws. (Figs. 12a, 12b & 12c) Insert (rotate and flex simultaneously) Centre Batten N and once fully central attach to slats using 16no 30mm Screws, (1no per canopy slat). (Figs. 13a, 13b & 13c). Miami Swing is now complete.
