The Singing Machine SMM475 Instruction Manual

SMM475 US ENG+SPA+FRE MANUAL
Blank size: 244 (W) x 182(H) mm
Date: 14 Jun 18
SMM475
INSTRUCTION MANUAL
MANUAL DE
INSTRUCCIONES
MODE D'EMPLOI
The Singing Machine Company, Inc.
4060 E Jurupa Street, Unit B
Ontario, CA 91761-1413 USA
www.singingmachine.com
The Singing Machine® is a registered trademark of The Singing Machine Co., Inc.
Singing Machine® es marca registrada de The Singing Machine Co., Inc.
Singing Machine® est une marque déposée de The Singing Machine Co., Inc.
Copyright © 2018 All Rights Reserved.
Derechos de autor © 2018 Todos los derechos reservados.
Droit d'auteur © 2018 Tous Droits Réservés 475-1806-EFS01-US
MUSIC PLAYBACK AND MUSIC VOLUME
Music selection and music volume can be controlled by your Bluetooth Device. We
recommend you to adjust the music volume to a comfortable level.
5
The microphone can be easily located on top of the unit.
You can always sing through it when the unit has been
switched on.
6
You can adjust the microphone volume by sliding the
U
VOL button.
V
7
You can slide the ECHO button to adjust the echo effect
to your voice.
8
Press and hold the POWER button to turn the unit off;
all lights will turn off.
Energy Saving Mode (Auto Power System-APS)
The unit will automatically switch off after 30 minutes in the following situations:
1. There is no singing into the microphone;
2. The Bluetooth music has been stopped.
The unit can be switched on again by pressing POWER button.
APS is for energy saving purposes.
Troubleshooting Guide
Should this unit exhibit a problem, check the following before seeking service:
No Power
• Power is not on; press the POWER button to turn power on.
• Confirm that the unit is charged.
No Sound – General
• Volume is set to minimum; raise volume of your Bluetooth music device by its
volume control.
No sound from the microphone
• Microphone volume is set to minimum; raise microphone volume by sliding VOL
button up.
Bluetooth reception failure
• Put the external Bluetooth device close to the unit.
• Pair the unit with the Bluetooth Device as the procedures stated in this manual.
Statement: The battery is not replaceable.
- E3 -
Included
What's in the box
Manual
USB Charging Cable
Specifications
AUDIO SECTION
Output Power .................................................................................................. 2.5 Watts (RMS)
Output Impedance ............................................................................................................3 Ohms
BLUETOOTH
Bluetooth Version .................................................................................................................. V4.2
Working Distance .............................................. Up to 10 meters measured in open space
LINE IN SECTION ...........................................................................3.5 mm Stereo line in jack
POWER SECTION
Battery ........................................................................ Lithium ion battery 3.7 V 1,200 mAh
Input Power ........................................................................................... Micro USB DC 5 V 1 A
DIMENSIONS (each mic) ................. 3.2 x 3.2 x 10 (inches) / 8.1 X 8.1 X 25.4 (cm)
WEIGHT (each mic) .......................................................................... 0.24 (kgs) / 0.53 (lbs)
Important Safety Information
1. Read these Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all Instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
8. Only use attachments/accessories specified by the manufacturer.
9. Unplug this apparatus during lightning storms or when unused for long periods of time.
10. Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
11. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to
rain or moisture. Do not place objects filled with water, such as a vase, on the apparatus.
12. CAUTION: To reduce the risk of fire or explosion, do not expose batteries to excessive
heat such as sunshine, fire or other heat sources.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
Warnings
CAUTION
RISK OF ELECTRIC SHOCK
DRIPPING WARNING: This product shall not be
DO NOT OPEN
exposed to dripping or splashing, and no objects
filled with liquids, such as vases, shall be placed on CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
the product.
NO USER-SERVICEABLE PARTS INSIDE. REFER
Warnings:
SERVICING TO QUALIFIED SERVICE PERSONNEL.
Changes or modifications to this unit not
expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
To parents recommending that the adaptor be periodically examined for conditions that may
result in the risk of fire, electric shock, or injury to persons and that, in an event such
conditions, the adaptor should not be used until properly repaired.
FCC WARNING: This equipment may generate or use radio frequency energy. Changes or
modifications to this equipment may cause harmful interference unless the modifications are
expressly approved in the instruction manual. The user could lose the authority to operate
this equipment if an unauthorized change or modification is made.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
INDUSTRY CANADA NOTICE:
This device complies with Industry Canada Iicense-exempt RSS standard(s). Operation is
subject to the following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables auxappareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :(1) l'appareil ne
doit pas produire de brouillage, et(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre lefonctionnement.
CAN ICES-3(B)/NMB-3(B)
Specifications are subject to change without notice. Please retain the instructions
for further reference, as they contain important information.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks and logos by The Singing Machine Company,
Inc. is under license. Other trademarks and trade names are those of their respective
owners.
- E4 - PRINTED IN CHINA
Before you get started
EXIT "TRY ME" MODE
Press and hold the POWER button 4-5 seconds or charge the unit to exit the "TRY
ME" mode.
CHARGING THE UNIT
1
Lift the rubber cover on the side of the unit.
Insert the included USB charging cable into the unit micro
2
u
USB port v.
Plug the other end of the cable into computer USB port or
3
w other USB charging device (not included). We recommend
to charge the unit 4 hours to ensure it is fully charged.
v The speaker will light in red and slowly flash while the unit is
4
charging. The light will change to solid red once the unit is
fully charged.
NOTE: Please charge the unit when you see the light on the
speaker flashing red.
LINE IN CONNECTION
This unit is able to connect your favorite audio device (e.g. iPhone/Tablet/MP3
player,etc.). You can connect your device by 3.5mm audio cable w (cable not
included). LINE IN function is automatically selected once the audio cable is plugged
in.
Warning
- To avoid excessive over amplified sound output, it is recommended that the volume
control is initially adjusted to one third or less and then increase if required.
Operation
Press the POWER button to turn the unit on (either one
1
of the microphones); the light on the speaker flashing
blue.
u
LIGHT MODE
Press the DUETS button repeatedly to select mode as
2
v
follows:
Light Mode 1: The speaker will light up with changing light
colors. When there is music playback or singing, the lighting
will flash with the audio signal.
Light Mode 2: The speaker will light up with color changing
lights continuously.
Light Mode 3: The light will be turned off.
- E1 -
Se incluyen
Contenido de la caja
Manual de instrucciones
Cable de carga USB
Especificaciones
AUDIO
Potencia De Salida (Max) ............................................................................. 2.5 Watts (RMS)
Impedancia De Salida .......................................................................................................3 Ohms
BLUETOOTH
Versión de Bluetooth ............................................................................................................ V4.2
Distancia de trabajo ................................... Hasta 10 metros medidos en espacio abierto
SECCIÓN DE ENTRADA DE LÍNEA ............................... Auriculares estéreo de 3.5 mm
ENERGÍA
Pila .............................................................................. Pila de iones de litio 3.7 V 1,200 mAh
Potencia de entrada ....................................................................... Micro USB DC 5 V 1 A
Dimensiones (cada micrófono)... 3.2 x 3.2 x 10 (inches) / 8.1 X 8.1 X 25.4 (cm)
Peso (cada micrófono) .................................................................. 0.24 (kgs) / 0.53 (lbs)
Información importante sobre seguridad
1. Lea estas instrucciones.
2. Conserve estas instrucciones.
3. Preste atención a todas las advertencias.
4. Siga todas las instrucciones.
5. No utilice este artefacto cerca del agua.
6. Límpielo únicamente con un paño seco.
7. No obstruya las aberturas para ventilación. Instálelo de acuerdo con las instrucciones del fabricante.
8. No instale cerca de fuentes de calor, como radiadores, rejillas de calefacción, estufas u otros aparatos
(incluso amplificadores) que produzcan calor.
9. Desenchufe este artefacto durante las tormentas eléctricas o cuando no se lo utilice durante períodos
prolongados.
10. Derive todas las reparaciones al personal de reparaciones calificado. Es necesario reparar el artefacto
cuando se encuentra dañado; por ejemplo, cuando el cable de suministro de energía o el enchufe
están dañados, cuando se derrama líquido sobre la unidad o caen objetos dentro del mismo, cuando el
producto ha estado expuesto a la lluvia o a la humedad, cuando no funciona con normalidad o cuando
se ha caído.
11. ADVERTENCIA: Para reducir el riesgo de incendio o descarga eléctrica, no exponga este artefacto a la
lluvia o la humedad. No coloque objetos llenos de agua, como jarrones, sobre el aparato.
12. PRECAUCIÓN: Para reducir el riesgo de incendio o explosión no exponga las baterías al calor excesivo,
como al rayo del sol, fuego u otras fuentes de calor.
Advertencias: Los cambios o modificaciones efectuadas a esta unidad que no fueron
expresamente aprobados por la parte responsable del cumplimiento, podrían anular la
autoridad del usuario para operar el equipo.
TO START SINGING WITH ONE MIC ONLY
3
CONNECT A BLUETOOTH DEVICE
+ Switch on the Bluetooth function of your Bluetooth
compatible device within three feet of the unit. You
will see "Singing Machine DUETS" appear on your
device's search list.
Select "Singing Machine DUETS" to start pairing. Wait for
the completion of the pairing until you hear a indicating sound from the microphone.
Notes:
•When both microphones have been switched on, you can only pair one microphone.
•Press POWER button to disconnect the bluetooth device.
TO ADD A SECOND MICROPHONE FOR DUET PERFORMANCES
Switch on the other microphone. Press and
+ +
hold the DUETS button on either one of the
microphones within three feet of the other
microphone. Wait for the completion of the
pairing.
Note: No music playback will happen during microphones pairing process.
TO LINK BOTH MICROPHONES TOGETHER FASTER
4
Turn both microphones on. The speaker will light up
with indicating light colors. Press and hold the DUETS
+
button on either one of the microphones within three
feet of each other. Microphone will make a sound to
indicate both microphones are paired together.
Switch on the Bluetooth function of your Bluetooth
compatible device within three feet of the microphones. You will see one "Singing
Machine DUETS" appear on your device's search list.
Select "Singing Machine DUETS" to start pairing. Wait for the completion of the
pairing. Both microphones will make a sound indicating that they have paired with
Bluetooth device.
Note: Press and hold the DUETS button to switch off the DUETS mode. Remember
to press and hold DUETS button again when you want to turn on Duets mode.
Notes:
- If your Bluetooth device prompts you for a passcode during the pairing process,
please enter "0000" to connect. If pairing fails, repeat steps. If you have paired
before, a list of previously searched results will be displayed. Select "Singing
Machine DUETS" again. On some Bluetooth devices (i.e.,computers), once pairing
is completed, you must select your Bluetooth device as "Use as Audio Device" or
similar.
- Ensure any other Bluetooth devices are turned off to avoid accidental pairing.
- Please always refer to the user manual of your Bluetooth device for detailed
instructions.
- E2 -
Antes de empezar
SALIR DEL MODO "PRUÉBAME" (TRY ME)
Presione y mantenga presionado el botón de ENCENDIDO (POWER) 4-5 segundos,
o cargue la unidad para salir del modo "PRUÉBAME" (TRY ME).
CARGA DE LA UNIDAD
1
Levante la cubierta de goma en el costado de la unidad.
Inserte el cable de carga USB incluido, en el puerto Micro
2
u
USB v de la unidad.
Conecte el otro extremo del cable en el puerto USB de la
3
w
computadora o en otro aparato de carga USB (no incluido).
Recomendamos cargar la unidad durante 4 horas para
asegurarse de que esté totalmente cargada.
v
El altavoz se iluminará con color rojo y titilará lentamente
4
mientras se carga la unidad. La luz cambiará a rojo fijo una
vez que la unidad esté completamente cargada.
NOTA: Cargue la unidad cuando vea que la luz en el altavoz es
rojo intermitente.
CONEXIÓN DE ENTRADA DE LÍNEA
Esta unidad puede conectar su dispositivo de audio favorito (por ej.,
iPhone/tablet/reproductor de MP3, etc.). Puede conectar su dispositivo utilizando
el cable suministrado w (cable de audio de 3,5 mm). La función ENTRADA DE LÍNEA
(LINE IN) se selecciona automáticamente una vez que el cable de audio se enchufa.
Advertencia
- Para evitar la salida excesiva de sonido amplificado, se recomienda ajustar
inicialmente el control de volumen a un tercio como máximo y luego aumentarlo si
es necesario.
Funcionamiento
Mantenga presionado el botón de ENCENDIDO/APA-
1
GADO (POWER) para encender la unidad; las luces del
altavoz comenzarán a cambiar en forma gradual.
u
MODO DE LUZ (LIGHT MODE)
Oprima varias veces el botón de DUETS para seleccionar
2
v
el modo de la siguiente manera:
Modo de luz 1 (Light mode): El altavoz se encenderá con
colores de luz cambiantes. Cuando se reproduzca música o se
escuchen canciones, la luz titilará con la señal de audio.
Modo de luz 2 (Light mode): El altavoz se encenderá con
colores de luz cambiantes en forma continua.
Modo de luz 3 (Light mode): La luz se apagará.
- S1 -
