- Page 1 O P E R A T I N G I N S T R U C T I O N S A L L V A L V E A M P L I F I E R...
- Page 2 Introduction The design brief for the Bonneville was simply to build a single channel all valve guitar amplifier. Although it only has one channel, it can produce a wide range of tones due to the design of both the preamp and power amp sections.
-
Page 3: Front Panel Controls
FRONT PANEL CONTROLS Input A single jack socket is provided for connection to your instrument. This is a high impedance input which allows for perfect matching to both passive and active guitars. Gain This control adjusts the degree of drive in the preamp stage. This is used in conjunction with the PREAMP STYLE switch to set the amount of overdrive required. -
Page 4: Rear Panel
POWER AMP CONTROL Speaker output socket & impedance selector switch The Bonneville has connections for driving loads of 4Ω,8Ω or 16Ω depending upon which socket is used and how the switch is set. In one position the two sockets are for either 4Ω or 16Ω, as indicated on the unit, whereas with the switch in the other position either socket can be used to drive an 8Ω... - Page 5 Therefore, as an example, if two 8Ω cabinets are used, 8 x 8 = 64 = 4 so the 4Ω socket should be used. 8 + 8 16 Output Damping The OUTPUT DAMPING control determines how much effect the speaker cab has on the output stage. High damping, with the control fully anticlockwise, provides a lot of negative feedback which basically attempts to correct any distortions that are occurring in the output stage and speakers, this produces a tighter, cleaner sound with flatter response.
- Page 6 Six 12AX7’s are fitted to the Bonneville amplifiers and are used as follows:- Combo Version Looking at the unit from behind with the rear panel removed, the second row of three are for the actual preamp gain stages, the right hand valve being the input stage and therefore the most sensitive.
-
Page 7: Safety Instructions
électromagnétiques ou en émettent les enceintes de haut-parleur Trace Elllot ne devraient emit or be affected by electro magnetic fields. Trace Elliot loudspeaker enclosures should not be used less than 2 metres away from equipment which is likely to be affected by electro magnetic pas étre utilisées à... - Page 8 Alle høyttalere og pick–up'er til gitarer gir nødvendigvis fra seg eller påvirkes av röd färg. elektromagnetiske felter. Trace Elliot–høyttalerkabinetter må ikke brukes mindre enn 2 m fra utstyr Om en A 13 amp (BS1363) stickpropp används måste en 13 amp säkring användas eller om som trolig kan påvirkes av elektromagnetisk støy.
-
Page 9: Instruções De Segurança
áhrifum af rafsegulsviom. Trace Elliot hátalarakerfi ætti ekki ao nota í innan vio 2 metra fjarlægo frá tækjum, EMC advarsel sem kynnu ao veroa fyrir áhrifum rafsegultruflana. - Page 10 πρε ´πει να εκπε ´ µπουν η ´ να επηρεα ´ζονται απο ´ τα ηλεκτροµαγνητικα ´ πεδι ´ α. Τα εσω ´κλειστα µελαϕω ´νου της TRACE ELLIOT να µην χρησιµοποιου ´νται λιγο ´τερο απ ´ο 2 µε ´ τρα µακρια ´ απο ´ τη συσκευη ´ που πιθανο ´ν να επηρεα ´ζονταιι απο ´ ηλεκτροµαγνητικη ´...
