2
iLevil
SW
Wireless Integrated Avionics Module
Instruction Manual
AHRS, GPS, ADS-B 978 / 1090 MHz Receiver

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iLevil 2 SW and is the answer not in the manual?

Questions and answers

Summary of Contents for Levil Technology iLevil 2 SW

  • Page 1 iLevil Wireless Integrated Avionics Module Instruction Manual AHRS, GPS, ADS-B 978 / 1090 MHz Receiver...
  • Page 2 2 SW SOLAR PANELS ADS-B/ LED GPS / LED ON / OFF SERIAL PORT ADS-B ANTENNA CHARGING / LED MINI USB-PORT...
  • Page 3: Package Contents

    Package Contents • Wireless iLevil2 SW • 12V plug car charger with 2 USB outlets • USB to Mini USB cable • ADS-B Antenna • Rubber stoppers or rubber pad • Protective bag • User Manual Charge before use • Charge the iLevil2 SW fully using the USB cable and dual 12V car charger supplied. •...
  • Page 4 Alignment • Attach the supplied ADS-B antenna. • Find a location that will allow your iLevil SW 2 to have a clear view of the sky, for satellite reception, and “line of sight” to ADS-B ground stations and other aircraft around you. •...
  • Page 5 Connecting to your favorite App The iLevil series offers the most compatibility with Apps on both iOS and Android platforms. • Turn ON your iLevil by flipping the ON/OFF switch. (LEDs will light up) • Tap Settings icon on your tablet. •...
  • Page 6: Led Indicators

    LED Indicators Label Status Slow Blink Green: Power ON / No GPS Fix Power/GPS Solid Green: Power ON / GPS fix acquired Off: Power Off Slow Blink Green: Traffic Received ADS-B Solid Green: Weather and traffic received Off: No traffic or Weather received Solid Green: Charging Charging...
  • Page 7: Magnetic Heading

    Magnetic Heading There are two ways to obtain heading information from the iLevil, depending on the navigation App of choice, you may choose between the following: - True Track: Heading information based on GPS track. - Magnetic Heading: Heading information determined by a combination of 3-axis magnetometer and gyros that form part of the internal AHRS.
  • Page 8: Specifications

    Specifications WIFI AHRS • Android and iOS compatible • 360 degree pitch and bank operation • Supports up to 10 devices connected • GPS Independent attitude. simultaneously (UDP broadcast) • 300 deg/sec max turn rate • Supports multiple protocols: • 4Gs max rating. GDL90 (default) •...
  • Page 9: Environmental Requirements

    Environmental requirements • Temperature range: -10° to 40 ° C (14 ° F to 104 ° F). • Clear view to sky for best GPS reception. • For best ADS-B reception line of sight view with ADS-B ground based towers and min 2000 ft. •...
  • Page 10: Serial Port

    Serial Port The iLevil2 features a serial port that can be used for data transfer or 5V external power input for automatic ON/OFF operations. For more informationCheck the iLevil ECHO feature on our website. Battery Safety Instructions • Batteries only have a 30% charge when you receive your iLevil2-SW. •...
  • Page 11: Helpful Tips

    Helpful Tips • You can upgrade the firmware on your iLevil2. We are always integrating new and exciting features, so check the website for firmware updates. • We are always innovating! Stay up to date with Levil developments and App integrations by filling out the Warranty registration card and check the “sign me up for newsletters”...
  • Page 12: Warranty

    Warranty Levil Technology Corp. warrants this product to the original purchaser to be free from defects in material and workmanship for a period of one year from the date of the original purchase. The following are not covered: software, damage resulting from accident, neglect, misuse, improper voltage supply or failure to follow operational guidelines supplied with this product.
