SEATING USER GUIDE
ELEVATION SERIES: OPS-B14 IMPACT
ARMREST UP & DOWN ADJUSTMENT
Press button located underneath the arm-
pad and lift or press down to adjust arm
rests. Arm rests also rotate left/right.
LUMBAR SUPPORT ADJUSTMENT
Pull handle on back of chair to adjust
lumbar support up and down.
www.openplan.com | 844.OPS.OPS1 | sales@openplan.com |
SEAT HEIGHT ADJUSTMENT
Lift button on right under seat to adjust
height.
BACKREST TILT ANGLE ADJUSTMENT
Press button under left side of seat to
adjust backrest tilt. Lift button to lock
position.
REV 08.09.16
SEAT DEPTH ADJUSTMENT
Lift second button on right under seat to
adjust seat depth.
BACKREST TILT TENSION ADJUSTMENT
Twist knob under seat to adjust backrest
tension. Twisting clockwise increases
tension.
