- Page 1 User’s Guide DMT6000 CXCI DMT6000 CXCI...
-
Page 2: Table Of Contents
DSR - Digital Satellite Receiver CONTENTS Page Page General Function Safety Select Channel For your safety Pause the Screen Outdoor Use Marking Previous Channel Recall Cable System Installation Marking TV & Radio Mode Polarized Attachment plug Marking TV & VCR Mode Important Safety Instruction Channel Information Volume &... -
Page 3: Safety
Safety COUTION : TO REDUCE THE RISK OF ELECTRIC SHOK DO NOT REMOVE COVER(OR BACK) NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lighting flash with arrowhead symbol, Within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 4: For Your Safety
Safety For Your Safety •Do not remove the cover •The space around the receiver should be clear to allow for proper ventilation of the receiver. • Do not allow the unit to be exposed to hot, •Do not cover the Receiver or place it on a unit cold or humid conditions that emits heat •... -
Page 5: Important Safety Instruction
Safety Important Safety Instruction 1) Read Instructions :All the safety and operating instructions should be read before the product is operated. 2) Retain Instructions :The safety and operating instruction should be retained for future reference. 3) Head Warnings :All warnings on the product and in the operating instructions should be adhered to. - Page 6 Safety Important Safety Instruction 13) Grounding or Polarization: This product may be equipped with a polarized alternating- current line plug(a plug having on blade wider than the other). This plug will fit into the power outlet only on way. This is a safety feature.
- Page 7 Safety Important Safety Instruction 20) Object and Liquid Entry : Never push objects of any kind into this product through opening as they may touch dangerous voltage points or short-out parts that could result in a fire of electric shock. Never spill liquid of any kind on the product.
- Page 8 Safety Important Safety Instruction Picture 1) Example of Portable cart warning (Symbol provided by RETAC) Picture 2) Example of antenna grounding as per national Electrical code, ANSI / NFPA 70...
-
Page 9: Fcc Information
FCC Information This device complies with part 15 of the FCC Rules, Operation is subject to the following two conditions : (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. -
Page 10: General Information
General Information A Digital Satellite Receiver is a convenient product that allows you to view a variety of programs provided through satellite. This user ’s guide covers the installation of the DSR and the necessary steps to operate various features. This also e xplains special features available only in this DSR in detail, and will allow you to make full advantage of these... -
Page 11: For Your Safety
General Information For Your Safety This STB has been manufactured to meet international safety stan dards. Please read all of the safety and operating instructions before operating the product. And keep all safety and operating instructions for future reference. 1. Main Supply : 90 -250V AC, 50/60Hz, 30W 2. -
Page 12: Unpacking
General Information Unpacking Make sure you have received all the items in the Satellite Recei ver carton. Digital Satellite Receiver DSR Remote Control Unit User’s Guide Batteries General Operation Throughout this manual you will notice that the everyday operati on of your DSR is based on a series of user friendly on screen display and menus. -
Page 13: Remote Control Unit (Rcu)
General Information Remote Control Unit (RCU) Function Turns power ON/OFF of the DSR When watching a channel, mutes the sound Enter number of the required menu item or 0 ~ 9 select a channel number to watch. TV/RADIO Switches between TV and Radio mode ß... -
Page 14: Front Panel
General Information Front Panel Function MENU Shows the main menu and command box on the screen. Executes the selected item in the menu. Returns to the previous menu on the menu screen. Turns on and off the power of the receiver. When watching, changing to the previou s and next channel, or moves to the next higher or lower item in the menu. -
Page 15: Rear Panel
General Information Rear Panel Connect to Digital Amplifier Power ON/OFF Connect to 12V to an external 0/12V switch AC Power Code Connect to the S-VHS Jack of TV or Connect VIDEO to TV using RCA Jack Connect to AUDIO R/L to TV or AUDIO TUNER Connect to TV or VCR Connect to TV ANT INPUT Connect to a PC for S/W Upgrade... -
Page 16: Installation
Installation This section explains the installation of DSR. Refer to the manu als supplied with the equipment for the installation of outdoor equipment such as the dish anten na. When adding new equipment, be sure to refer to the related parts of the manual for the inst allation. -
Page 17: Connecting To Tv Using Rf Support
Installation Connecting to TV using S-VHS support Connecting to TV using RF support -17-... - Page 18 Installation Connecting to Digital Amplifier -18-...
-
Page 19: Menu Information
Menu Information Once you properly installed and connected cables of the DSR, th e menu will be displayed This menu consists of 6 main menus as follows. - Channel Manager - Program Guide - Timer - User Installation - Common Interface - Receiver Information To move up and down, press “PR+ or PR -”. -
Page 20: Antenna Setup - 1) Diseqc1.2
User Installation This menu consists of 5 sub-menus as follows. - Antenna Setup - Channel Search - System Setting - Parental Lock - Factory Default Antenna Setup-1) DiSEqC 1.2 1)Antenna : You can select maximum 16 antennas with the combination of switches. -
Page 21: User Installation
User Installation 7) East, West Limit Press E continuously until your antenna reaches to the easternmost point and then press OK key on the RCU. The message of “Would you like to set East limit of DiSEqC motor? ” will be displayed for your confirmation. -
Page 22: Antenna Setup-2) Fixed
User Installation Antenna Setup-2) Fixed 1) Antenna : You can select maximum 16 antennas with the combination of switches. 2) Type : Select your antenna type to be Fixed. 3) Univ. LNB: Select your LNB type. If you have universal LNB, select otherwise select NO. -
Page 23: Channel Search - 1) Diseqc1.2
User Installation Channel Search-1)DiSEqC 1.2 1) Antenna : Select your antenna number. 2) Satellite : Select a satellite using keys or if you press OK key. Then, the list of satellite will be displayed so that you can select easily. You can see the information of the selected satellite in the right side. - Page 24 User Installation 6) Polarization : Select Hor or Ver . 7) 22KHz : Select ON or OFF. 8) Search 1 Sat : DSR allows you to search channels with convenient options as follows, select one using arrow keys. -Search 1 SAT : Search channels in one satellite which selected on Satellite column.
- Page 25 User Installation 12) Re-Sync : When all location of searched satellites are shifted by unknown reason, you can realign all of them at once if you adjust one satellite ’s location. 13) Go to 0 for DiSEqC1.2 : When you install the motor of DiSEqC 1.2 antenna at first, you can select this function to move the center of antenna to be 0...
-
Page 26: Channel Search-2) Fixed
User Installation Channel Search-2) Fixed 1) Antenna : Select your antenna number. 2) Satellite : Select a desired satellite using 56 keys or if you press OK key, list satellite will displayed so that you can select easily. You can see the information of selected satellite in the right side. -
Page 27: System Setting
User Installation System Setting System Setting menu provides variety of choice which is matching to your environment. 1) OSD Color : You can select the color of Night, Ocean, Wine, Grass. 2) OSD Language : Select your desired OSD Language. 3) Audio Language : Select your desired audio language to be in the top priority under the condition... -
Page 28: Parental Lock
User Installation Parental Lock This function allows you to lock the channel with your password in order to prevent from accessing the channel by your children or any other person. And also you can protect your installed data and information by using Install Lock. ★... -
Page 29: Factory Default
User Installation ★ How to use Install Lock 1) Enter the current password. 2) Select ON of Install Lock 3) Enter new password 4) Confirm your new password by entering new password again 5) Exit this menu and Turn off the DSR Turn press MENU key on the RCU... -
Page 30: Common Interface
Common Interface DSR makes you enjoy various scrambled channels encrypted by Viaccess , Nagravision , Irdeto , Conax , Cryptoworks and SECA. Preparing To be able to receive scrambled digital satellite channels you will need a Smartcard and a Common Interface CA (Conditional Access) module form the Service Provider of your choice. -
Page 31: General Function
General Function The following describes the basic functions of your DSR while watching satellite TV or listening to satellite radio. DSR enables you to watch various scrambled channels by inserting the CAMs and Smartcards according to your choice. While watching, the current channel information will be shown on the bottom of the screen if you press INFO button on the RCU. -
Page 32: Pause The Screen
General Function Pause the frame Press PAUSE key on the RCU to pause the screen. To bring it back to the normal mode, press PAUSE key once again. Previous channel recall Press ← PR key on the RCU to move the previous channel which you were watching before the current channel. -
Page 33: Channel Information
General Function Channel Information Every time you change channels, you will receive program information for a few second. While watching channel, you can see the current channel information anytime by pressing INFO key on the RCU. Note : Channel information will be displayed for 6 seconds and disappeared. -
Page 34: Channel Manager
Channel Manager DSR provides most powerful channel managing function in the worl d and this function allows you to have a more interesting and useful operation as well as watching channels simply. Channel Manager Channel Manager consists of TV Channel and Radio Channel. - Page 35 Channel Manager Favorite When you select channel manager, default favorite list will be showed on the screen as Favorite 1. Select your favorite channel and then press key. Then will be marked at rear of your selected channel name. And if you want to delete the channel name in the favorite channel list, press OK key once again, then the...
- Page 36 Channel Manager Lock In the TV Channel Manager Page, press MENU key on the RCU, and select Lock on the command menu. This Lock command allows you to lock the channel. First, select the channel, which you want to lock and press OK key and then, will be marked at rear of the selected channel name.
- Page 37 Channel Manager Delete In the TV Channel Manager Page, press MENU key on the RCU, and then select Delete on the command menu. Then, sub -menu like Delete CH, TP, Satellite and all will be displayed. This Delete command allows you to delete the channel permanently.
-
Page 38: Fast Edit Mode
Channel Manager Fast Edit mode Fast edit mode allows you to edit channel faster than normal without showing channels selected. If you turn off the Fast edit mode, DSR will show each channels selected in the small PIG screen and it takes few seconds more to edit channels. Go To Function GoTo function enables you to go to any page of the menu tree by the adoption of Open... -
Page 39: Electronic Program Guide(Epg)
Electronic Program Guide(EPG) DSR provides EPG function for you to get access to the TV Guide(or Radio Guide if you are listening to radio channels) which will show the titles and other information of the current and next programs on different channels. -
Page 40: Timer
Timer You can adjust the real time as well as you can program the timer with various ways. This function is one of the strong point of DSR. Time Adjust Usually you get the information of real time from the satellite automatically but sometimes they emit wrong information. -
Page 41: Antenna Direction Help
Antenna Direction Help Although you entered correct value in Antenna Set up menu, if your antenna is positioned incorrectly, you could not receive signal from the Satellite. So DSR provides Antenna Positioning Help in order for you to have exact information to direct your antenna toward a satellite. -
Page 42: Front Panel Display
Front Panel Display Front Panel Display : Up load Procedure : VCR Mode : Down load Procedure : System Waiting : Error in Data transmitting : Flash ROM Error : TV Mode : System Booting -42-... -
Page 43: Trouble Shooting
Trouble Shooting Problem Possible causes What to do The display on the front panel Main cable is not connected. Check that the main cable is does not light up. plugged into the power socket. No sound or picture, but the The DSR is in standby Press the standby button. - Page 44 Trouble Shooting Problem Possible causes What to do No Welcome Menu on the The system is connected by If the system is connected by screen after you switched on SCART leads and TV is not in SCART leads, switch the TV to the DSR for the first time.
-
Page 45: System Specification
System Specification 1) TV System : PAL B/G, I, D/K 2) Input Data Rate : 2-45 MBPS 3) Modulation : QPSK(DVB Specification) 4) Inner FEC : Viterbi Convolutional Coding Rate 1/2, 2/3, 3/4, 5/6. 7/8(DVB) 5) Outer FEC : Reed Solomon Coding(204, 188) T=8(DVB) 6) System Decoding : ISO/IEC 13818-1(MPEG2) TS...
