Summary of Contents for Southern Enterprises FA939100TX
- Page 1 FA939100TX- ESPRESSO LYNDEN MEDIA FIREPLACE MANTEL For assistance with assembly contact: ASSEMBLY INSTRUCTION Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
-
Page 2: Parts List
FIREPLACE LYNDEN MEDIA Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below. - Page 3 Quantity Quantity of 1 of 2 BIG UPPER PANEL MIDDLE SIDE PANEL Quantity Quantity of 1 of 1 SMALL MIDDLE PANEL SHELF PANEL Quantity Quantity of 1 of 1 LEFT ADJUSTABLE SHELF PANEL RIGHT ADJUSTABLE SHELF PANEL Quantity Quantity of 1 of 1 BIG LEFT SIDE PANEL BIG RIGHT SIDE PANEL...
- Page 4 (11) Quantity (12) Quantity of 1 of 1 BOTTOM PANEL LEFT DOOR PANEL (13) Quantity (14) Quantity of 1 of 1 RIGHT DOOR PANEL MIDDLE BACK PANEL (15) Quantity (16) Quantity of 2 of 1 SIDE BACK PANEL TOP PANEL (17) Quantity (18)
- Page 5 LYNDEN MEDIA FIREPLACE Assembly Instructions Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated on the front page Insert cam locks (C) into predrilled holes on the two lower side panel (7) &...
- Page 6 LYNDEN MEDIA FIREPLACE Assembly Instructions Insert cam locks (C) into predrilled holes on the middle side panel (2) and small middle panel (3). Screw cam bolt (A) into predrilled holes on the big upper panel (1). Attach the big upper panel (1) to three middle panel by inserting wood dowel (B) &...
- Page 7 LYNDEN MEDIA FIREPLACE Assembly Instructions Insert cam locks (C) into predrilled holes on the upper side panel (17) . Screw cam bolt (A) into predrilled holes on the top panel (16). Attach the top panel (16) to the upper side panel by inserting wood dowel (B) &...
- Page 8 LYNDEN MEDIA FIREPLACE Assembly Instructions Insert the shelf pin (D) into the pre-drilled hole on the cabinet side panel and divided panel, and well put the two adjustable shelf panels (5) & (6) on it as shown. Figure 7 Assemble the door hinge (L) on the cabinet and right door panel (13) by screw (K).
- Page 9 LYNDEN MEDIA FIREPLACE Assembly Instructions Well put the fireplace (M) into cabinet and avoid any scratch. Figure 9 Assemble the wood holder (19) on the bottom panel by using screw (I). Figure 10...
- Page 10 LYNDEN MEDIA FIREPLACE Assembly Instructions Now you can enjoy your new fireplace. Figure 11...
- Page 11 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
- Page 12 This unit contains a permanent warning sticker located on back panel. Do not allow children under 16 years old to move the cart. Model: FA939100TX- ESPRESSO LYNDEN MEDIA FIREPLACE MANTEL...
