VOICE MAGIC

DIGITAL VOICE RECORDER

OPERATION MANUAL

Table of Contents

Need help?

Do you have a question about the VOICE MAGIC and is the answer not in the manual?

Questions and answers

Summary of Contents for Maycom VOICE MAGIC

Page 1 VOICE MAGIC DIGITAL VOICE RECORDER OPERATION MANUAL...
Page 2 Information to the user This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 3: Table Of Contents
Contents Voice Magic Overview Features and Functions Installing Batteries Time Adjust Selection of Mode Recording Playback Erasing the Recorded Messages Connecting to External Equipments Connection to PC Specification Precautions Troubleshooting...
Page 4: Voice Magic Overview
Voice Magic Overview...
Page 5 DISPLAY...
Page 6: Features And Functions
Features and Functions Fast Transfer Speed to PC approx 10:1 (VR -2000 series only) Effective Variable Playback Speed (V.P.S) as x0.5, x0.7, x1.0, x1.5, x2.0 1164-minute Recording Time in case of VR -x032 (LP Mode) 5 Files-Each File contains up to 99 individual messages LCD Display shows message number, real-time counter, current time and operating modes Three (H/M/L) Steps for Sound Quality...
Page 7: Installing Batteries
Installing Batteries Loading/Replacing the Batteries Caution : Be sure to replace batteries in Clock mode. 1. Open the battery cover, press and then slide it off. 2. Load two “A A A ” batteries (LR-03) in the compartment, and then slide the cover back into place 3.
Page 8 Battery Life Battery Type LR-03 Alkaline Recording Mode Approx. 12 hours Speaker Play (VOL.12) Approx. 7 hours Earphone Play (VOL.12) Approx. 8 hours Cautions : 1. Do not use different kind of batteries together. 2. Remove the batteries when voice recorder will not be used for a long time.
Page 9: Time Adjust
Time Adjust Only available this function on Clock mode. Time Adjustment 1. Press ERASE button for more than 2 seconds during Clock mode. 2. When the digit blinks you can adjust time using forward( ) or rewind( ) button, Press PLAY/(PAUSE) button to adjust next digit. 3.
Page 10: Selection Of Mode
Selection of Mode Power On/Off In order to Power on/ off, you have to replace the battery. Clock Mode This mode display current time, and minimize battery consumption. If you press any button on clock mode, it will go to stand-by mode.
Page 11: Recording
Recording Following operations are available at the stand-by mode. How to Record 1. Press the REC/(STOP) b utton after turning the microphone toward the sound sources. 2. Now, the recording starts and “rEC” message, file and message No. will be displayed on LCD also, “REC”...
Page 12 ARS(Automatic Record System) mode selection Available only when any sound exists 1. Press REC/(STOP) button, for more than 2 sec. in stand-by mode. 2. “ARS”, “REC” icon will be blinked and “ARS” will be displayed on the LCD 3. Now, the recording starts with ARS mode. Sound quality (S.Q) mode selection Select recording mode with the S.Q/(VPS) button in stand-by mode.
Page 13 * The sound quality diminishes in LP mode. ARS Sensitivity selection Select recording mode with the ARS/(RPT) button in stand-by mode. : Hi sound input record : Medium sound input record : Low sound input record Microphone Sensitivity (MIC) selection Selecting the signal source’s distance or loudness.
Page 14 Record Monitoring You can monitor the records by an external earphone during record process. It’s not possible to control recording level by the volume control. Selecting a File Select a file among five files (1, 2, 3, 4 and 5) with the FILE button in stand-by mode.
Page 15: Playback
Playback Following operations are available at the stand-by mode. How to Playback 1. Select a message by sliding jog switch and press PLAY/(PAUSE) jog switch, then playback will start. 2. File No., Message No., playtime will be displayed in sequence on LCD. 3.
Page 16 FF & RW search in playback Use these functions to search fast and listen to what you want during playback. When you press Fast Forward( ) button or Rewind ( ) button shortly during playback, the message number will be increased or decreased and will playback automatically.
Page 17 Repeat one message or All messages If you press RPT/(ARS) button during playback, it will be displayed on LCD as bellows. Repeating one message. If you press RPT/(ARS) button ones again, it will be displayed on LCD as bellows Repeating all messages in a file. * If you want to cancel repeating message, press RPT/(ARS) button once again.
Page 18: Erasing The Recorded Messages
Erasing the Recorded Messages Erasing one message 1. Select the message number you want to erase, then press ERASE button at stand-by mode. 2. “ErASE” sign will appear and blink on LCD. 3. Press the ERASE button once more, then the message will be erased.
Page 19: Connecting To External Equipments
Connecting to External Equipments Recording with External Microphone Record after connecting an external microphone to the external microphone jack, as shown in the figure below. You can record your voice in action by mounting the external microphone on your collar. And you can record with better sound quality when the microphone is closer to the sound source.
Page 20 Connection to External Appliance Following figure explains how to record from external appliance to the set, and send recorded messages back to external appliance by connecting audio cable. Recording from External Appliance Lower the sound volume of the external appliance, and connect the audio cables between External Mic.
Page 21: Connection To Pc
Jet Voice Mail is a program to save the recorded messages to PC by the sound card in PC and send the voice mail and edit the saved messages. Please check above PC conditions before using PC and connect Line-in/out cable between PC and Voice Magic as the drawing right side.
Page 22 <How to Install Program> 1. Turn on power and insert CD disc into CD-ROM drive. 2. The program will be set automatically. 3. Press NEXT to continue and press CLOSE to exit SETUP. 4. Jet-Voice Mail is automatically d isplayed on screen. 5.
Page 23 <Trouble/Solution> 1. Question : During recording/playback is not activated after installation. Answer : Sound card is not inserted Check if sound card is properly inserted in PC. 2. Question : No sound during playback after recording. Answer : 1) Check if cord is properly connected into mic -in of sound card.
Page 24 S/W CD. (VR -2000 series : Basic, VR-1000 series : Option) This is the program to save the recorded messages into PC by using a PC serial port. 1. Installing The Voice Magic Manager 1) Operation Environment - At least Pentium 150 PC, which has a sound card, serial port.
Page 25 * Voice Magic Manager : To save the recorded messages into PC. (Fast Transfer approx.10:1) * Jet Voice Mail : To save the recorded messages to PC and send the voice mail. 2. How to Operation 1) Execute the Voice Magic Manager.
Page 26 2) Selection of Com Port. Please select the serial port in PC before operating and connecting cable to serial port. MENU(M) → PORT → COM1 or COM2 * Cautions : It causes electric shock when connect cable to non-serial port. 3) Connection of Cable If you connect cable to Voice Recorder, the Voice Recorder will be able to correspond.
Page 27 (d) Set Time : Setting the time in PC to Voice Recorder. (e) Connect : Refresh the recorded messages in Voice Recorder. Note : Even though the date will not be displayed in Voice Recorder, the date of recorded will be displayed on Voice Magic Manager. 5) Tree View...
Page 28 6) File List View Display the recorded Wave file in PC. 7) Messages View Display the recorded message in voice recorder. Press right button on mouse and then, it can be changed to play or upload the recorded messages. Note : We would like to recommend choose the “C:\WINDOWS\SNDREC32.EXE”...
Page 29: Specification
Specification VR-x008 VR-x016 VR-x032 Model Name (8MB) (16MB) (32MB) Recording time(LP) 290 min 581 min 1164 min Recording System Built-in Flash Memory Dimension 104(L) x 26(W) x 18(H)mm Weight Approx. 34g without Battery Power Supply DC 3V, “AAA” Size Alkaline Batteries x 2 About 12 hours in Recording mode Battery Life About 8 hours in Earphone Play at volume 12...
Page 30: Precautions
Precautions Please read following precautions before using the voice recorder 1. Do not use or place the product at the following conditions: - Hot places (above 60 - Cars whose windows are closed - At a high humidity place (like bathroom) - Under direct sunlight or near the heaters - Dusty Areas 2.
Page 31 10. If any malfunction (such as smoke or transformation due to heat) happens, remove batteries immediately. 11. A magnetic card like a credit card or a subway communication ticket may not work any longer once it is placed on or close to the speaker.
Page 32: Troubleshooting
Troubleshooting SYMPTOM REASON REMEDY Batteries are exhausted. Replace the batteries. No display on LCD Batteries’ polarities are not Place the batteries in the correctly placed. right position. Set HOLD switch to OFF HOLD switch is ON. position. Recording does not All message number or spaces Erase unnecessary operate...
