Arlec e-Saver Quick Start Manuals

> InTELLIgEnT

Quick start guide:

> for first time use or changing to a different charger, please follow these steps:
1
Plug e-saver and
charger to power outlet,
do not plug in phone
or device being charged
at this stage.
*for more info on learning function mode, please refer to instructions "Learning function mode set up" section.
E-saver does not switch on instantly, when phone or charging appliance is connected; E-saver does not
switch off instantly, when phone or charging appliance is charged. Please allow up to 15 minutes for e-saver to
automatically switch on or off the charging appliance, or press reset button once to quick charge.
Learning function mode set up >
If the e-saver appears to be not to be
working properly, it may cause by the
e-saver programmed factory setting that
does not compatible with the charger,
but e-saver has a learning function mode
that can adapt to different chargers.
To activate the learning function mode,
please follow the following procedure:
1. Plug e-saver into a power point.
2. Plug the charger into e-saver; do
not connect the device being charged
(e.g. cell phone etc) at this moment.
3. Press and hold the reset button on
e-saver for 3 seconds till the red LED
light flashes rapidly, the e-saver is in
learning function mode.
4. After 1 minute, the red LED light will
flash slowly, now connect the
device being charged (e.g. cell phone
etc) to the charger.
ImPortANt > Please read these instructions carefully before first use.
Standby Power Adaptor For Chargers
2
Press and hold the
reset button on the
e-saver for 3 seconds
until the red LEd light
flashes raPidLy.
3
after approximately 1
minute, the red LEd light
will flash sLowLy; now
connect your phone or
device being charged.
5. The red LED light will stop flashing and
stay on, e-saver will start the charging
process. After the device being charged
is fully charged, e-saver will cut off
the electricity to the charger, the
learning function mode is completed.
LED Indicator Light
To byPAss sTAnDby moDE or for InsTAnT chArgIng, PrEss
AnD hoLD ThE rEsET buTTon on E-sAvEr for 1 sEconD.
note >
1. E-saver only suits chargers with a charging current of
1 amp Dc or less. Please check the charger output Dc
current rating before connecting to the e-saver.
2. E-saver has built in overload protection, if your
e-saver does not function, please check your
charger Dc output current rating to
ensure hat it is less than 1 amp Dc.
CPIN002166/2
4
E-saver will automatically
allow charging and
power saving function to
commence, this might
take up to 15 minutes.
rEsET buTTon
*Charger shown for
e-saver
illustrative purposes only
and is not included.
ES001
