Summary of Contents for Tecme NEUMOVENT

  • Page 1 Graph ventilator Technical manual (review 04) MAY 2006...
  • Page 2 CONTENT CHAPTER I GENERAL AND OPERATION FEATURES TECHNICAL DATA AND SPECIFICATIONS CONTROL PANEL SAFETY MECHANISMS CHAPTER II MAINTENANCE INSTRUCTIONS CHAPTER III TROUBLE SHOOTING CHAPTER IV SENSOR VERIFICATION CHAPTER V EQUIPMENT OPENING AND CLOSURE CHAPTER VI DETAIL OF ASSEMBLIES CHAPTER VII ELECTRONIC BOARDS: DETAIL CHAPTER VIII CALIBRATION...
  • Page 3 CHAPTER I GENERAL AND OPERATION FEATURES...
  • Page 4 An explosion or fire may result. Description The NEUMOVENT Graph Ventilator comprises a system of related elements and designated to alter, transmit and apply energy directly, and in a predetermined mode, replacing or contributing with the patient's muscular capacity in the execution of the work of breathing with the intention of achieving an efficient gas exchange.
  • Page 5 In this case, it will control the ventilation. The NEUMOVENT Graph Ventilator is able to control the pressure waveforms like the flow waveforms. This control also can be doing in a single inspiration.
  • Page 6 (pneumotachograph), then the ventilator is classified as a flow controller. The Volume mode of the NEUMOVENT Graph Ventilator uses the flow as the control variable. The Pressure Support mode with Volume Assured is able to change, in oneself inspiratory phase, from pressure controller to flow controller.
  • Page 7 Date: 09/05/06 Principles of Operation Operative definition The NEUMOVENT Graph Ventilator is a pressure or flow controller. The inspiration is triggered by pressure, flow, time or manually. It is pressure, volume or flow limited and pressure, volume, flow or time cycled.
  • Page 8 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Control valves The mentioned proportional valves regulate the gas flow to the patient. The flow control is able to send flows up to 180 L/min when the gases are from a central-supply system, and of 120 L/min when a portable compressor provides the air.
  • Page 9 Likewise, the screen shows messages indicating an alarm state or to execute some action. Respiratory cycle The process of insulation of gas to the lungs by means of the mechanic ventilation with the NEUMOVENT Graph Ventilator comprises four steps: 1) Start of inspiratory phase 2) Progression of inspiration...
  • Page 10 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 The form in the flow administration depends on the ventilatory mode and of the selected flow waveform. In the VCV mode the flow waveforms, which can be selected, are: descending ramp (decelerating), rectangular (continuous flow), sinusoidal, ascending ramp (accelerating).
  • Page 11 Date: 09/05/06 The expiratory phase can be modifying adding Positive Pressure at the End of Expiration (PEEP). The NEUMOVENT Graph Ventilator produces this positive pressure by means of a digital regulation of the closing force of the expiratory valve diaphragm.
  • Page 12 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06...
  • Page 13 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06...
  • Page 14 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Operative modes According to the described functional characteristics, as well as the controls and limits assigned to this device, the following operative modes have been included. These modes agree with the descriptions of the classic world literature, which is mentioned partly in "Bibliography."...
  • Page 15 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Volume VCV Assist/Control Definition and Operative Proceeding: It is a ventilatory mode with specific regulation of the tidal volume. The inspiratory pressure is variable, and it depends on the respiratory impedance to regulated volume. During this mode, the ventilator works as a flow-controller where the selected flow waveform is sustained during any lung compliance/resistance variation.
  • Page 16 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 lung size, the existent pressure gradient at the beginning of inspiration between the upper airway and the alveoli, the respiratory system compliance and the available inspiratory time. The pressure waveform developed during inspiration is rectangular, being the flow of the descending ramp type (decelerating flow).
  • Page 17 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 to maintain the adjusted value of positive pressure. It can be programmed with or without pressure support. During the inspiratory phase, there is a decrease of the airway pressure proportional to the demand.
  • Page 18 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 VT: Regulation of the propelled volume by the ventilator in the mandatory inspiration. Flow Waveform: To change the flow waveform. PSV: Regulates the level of pressure support. Rise Time: To vary the PSV pressurization. Synchronized intermittent ventilation with pressure-controlled mandatory inspiration and spontaneous inspirations with pressure support.
  • Page 19 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Airway Pressure Release Ventilation (APRV) It is a mode which ventilates applying periodic switching between two adjustable levels (P-high and P-lower) of continuous positive airway pressure (CPAP) during preset periods of time. Spontaneous breathing is possible without restriction at both levels.
  • Page 20 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 As the device does not recognize difference between effort reduction and apnea, generically this last term is used. For default the apnea time is established in 15 seconds, but it can be modified at 5, 10, 30 or 60 seconds (Menu key). The backup ventilation for ADULT and PEDIATRIC category is made by volume or pressure mode.
  • Page 21 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Alarms and Safety Mechanisms The device has an alarm system with simultaneous messages to alert conditions that, if they persist, they put or they can put in danger the patient's state and could require immediate attention.
  • Page 22 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Value change: With the [Alarm Settings] key Screen message The audible alarm signal recovers automatically if the pressure returns to an inferior value to the limit. The panel light signal does not disappear until the [Reset] key is pressed.
  • Page 23 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Technical failure (Nonadjustable by the user) Definition: Important alteration (electronic circuit or software) or burnt fuse of the annex board. Ventilator action: The ventilator stops to work. The screen fades. Continuous light and audible signal is activated.
  • Page 24 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Value Change: With the [Alarm Settings] key. The audible signal is suspended when the pressure recovers accepted limits. The light signal does not disappear until the [Reset] key is pressed. Screen message The audible signal of the alarm is suspended if the pressure returns to an inferior value to the limit.
  • Page 25 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Apnea (Adjustable by the user) Definition: It is a condition where the ventilator considers a breathing stop during spontaneous ventilation modes after an adjustable period of time. Selection: In Pressure Support, Continuous Positive Airway Pressure and Combined Modes (optional in SIMV).
  • Page 26 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 seconds of persisting the alteration. If, after one minute, no action is taken by the operator, the alarm status is changed to as a Medium Priority Signal. Signal type: Audible, and warn in the screen. Silence: It can be silenced temporarily.
  • Page 27 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Alarm Complements ƒ Silence 30/60 seconds It suspends the audible signal of some alarms. It does not suspend the sound of the power loss and technical alarms. ƒ Reset It is a key with multiple functions, used alone or in combination with other keys.
  • Page 28 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Universal Voltage: The power source is self-regulated for alternate current from 100 to 240 volts. Automatic Zero Reset: The pressure transducers are zeroed every 15 minutes or when the operator activates this function ([Ctrl] + [Ptr-Vtr]). Line Purge: In order to avoid any obstruction of and/or humidity in the internal transducers, air is injected through the tubes connecting the expiratory pneumotachograph at reset.
  • Page 29 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 References 1. Abraham E, Yoshihara G. Cardio-respiratory effects of pressure control ventilation in severe respiratory failure. Chest 1989; 96:1356. 2. Amato MB, Barbas CS, Bonaza J. Volume- Assured Pressure Support Ventilation: a new approach for reducing muscle work load during acute respiratory failure.
  • Page 30 CHAPTER II MAINTENANCE INSTRUCTIONS...
  • Page 31 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Items to be checked during maintenance every 5000 hours of use: 1-External check-up, clean-up and disinfection of the device. 2-Functional control. 3- Control of alarms sound: Press “Ctrl” + “Reset” 4-Functional inspection of keys.

  • Page 32: Trouble Shooting

    CHAPTER III TROUBLE SHOOTING...
  • Page 33 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 TROUBLE SHOUTING PROBLEM CORRECTIVE ACTION POTENTIAL CAUSE Device does not 1. Leak in the patient’s circuit. 1. Check the patient’s circuit. pass initial 2. Gas supply closed. 2. Open the gas supply valve. calibration 3.
  • Page 34 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 TROUBLE SHOUTING PROBLEM CORRECTIVE ACTION POTENTIAL CAUSE Low Tidal Volume 1. Incorrect initial calibration of 1. Redo initial calibration of the circuit. 2. Check expiratory valve and the patient’s circuit. 2.
  • Page 35 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 TROUBLE SHOUTING PROBLEM CORRECTIVE ACTION POTENTIAL CAUSE High PEEP 1. Diaphragm of the expiratory 1. Replace the diaphragm of the valve stuck. expiratory valve. 2. Obstruction of the patient’s 2.
  • Page 36 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 TROUBLE SHOUTING PROBLEM CORRECTIVE ACTION POTENTIAL CAUSE Water in the device 1. Open the device and Water has entered clean all pneumatic through the air or components (2.8kg/cm2 oxygen supply. pressure regulators, proportional valves, nonreturn valves, 10 PSI...
  • Page 37 CHAPTER IV SENSOR VERIFICATION...
  • Page 38 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Sensor Inspection Access to the Calibration Menu When the device is off, press the key, and turn it on while keeping the key pressed. “ ” Reset The message “Enter Code” will be displayed on the screen. At that moment, press any key four times. A message will then be displayed warning that the code entered is incorrect.
  • Page 39 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Sensor Inspection - The value for the opening of the chosen valve may be increased or decreased with selection keys This opening value may range between 0 (Closed Valve) and a maximum of 4095 (Valve completely opened).

  • Page 40: Air Flow Sensor

    Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Sensor Inspection Air Flow Sensor: 1) - Disconnect the supply gases from the device - Check if the reading of the “Air Flow” is a stable value in correspondence with that indicated in Table 1.
  • Page 41 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Sensor Inspection Expiratory Flow Sensor (ExpFlow): 1) - Disconnect the supply gases from the device - Check if the reading of the “Exp Flow” is a stable value in correspondence with that indicated in Table 1.
  • Page 42 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Sensor Inspection Pneumotacograph: Fig.:1 Ventilator Flow Analyzer Patient outlet AirVal and OxyVal: 1) -Connect the flow analyzer in the Patient outlet (Fig.:1). 2)-Open the air/Oxy valve until 160 L/min. 3)-Check if the reading of the first column Air Flow is below 1024.
  • Page 43 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Sensor Inspection Proportional valves: AirVal: 1)-Press the “ ” key. Reset At that moment, the Calibration Menu is displayed on the screen. 2)-Choose the option “Air Val” with the “selection” keys 3)-Put target value in 5 L/m and press the “fiO ”...
  • Page 44 CHAPTER V EQUIPMENT OPENING AND CLOSURE...
  • Page 45 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 How to Open and Close the Neumovent Graph Ventilator Operation Description Removal of back cover: Open the ventilator by removing the eight screws located in the positions indicated in the figure.
  • Page 46 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 How to Open and Close the Neumovent Graph Ventilator Operation Description Disconnect the following cables: - Con.6, battery cable of the Ancillary Board. - Con.12, speaker cable of the CPU Board.
  • Page 47 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 How to Open and Close the Neumovent Graph Ventilator Operation Description Separation Back Cabinet – Front Cabinet: - Remove the screws indicated with arrows in Fig.:2-A-B. Fig.:2-B Fig.:2-A Rear View...
  • Page 48 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 How to Open and Close the Neumovent Graph Ventilator Operation Description Separation Front Cabinet – Back Cabinet, electrical part Back Gabinet To Con14 of CPU Board Proportional Valves Cables Fig.:3-A...
  • Page 49 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 How to Open and Close the Neumovent Graph Ventilator Operation Description Separation Front Cabinet – Back Cabinet, pneumatic part Fig.:4-A Front Cabinet F.scape 0,7 Kg/cm Pneumatic Box Neumo inspiratory...
  • Page 50 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 How to Open and Close the Neumovent Graph Ventilator Operation Description Cabinets Separated Fig.:4-B Cabinet sealing joint Rear Cabinet Front Cabinet...
  • Page 51 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 How to Open and Close the Neumovent Graph Ventilator Operation Description Separation Pneumatic Box - Front Cabinet, pneumatic part: - Disconnect the tubes indicated in Fig.:5-A Pneumatic Box Fig.:5-A G.Exh.
  • Page 52 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 How to Open and Close the Neumovent Graph Ventilator Operation Description Separation Outlet Manifold – Box – Front Cabinet: -Remove the screws indicated in Fig.:5-B Fig.: 5-B Front Gabinet...
  • Page 53 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 How to Open and Close the Neumovent Graph Ventilator Operation Description Separation Outlet Manifold – Box – Front Cabinet: -Disconnect tubes 1, 2, 3, and 4, and remove the outlet manifold, Fig.:5-C Front Cabinet F.scane...
  • Page 54 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 How to Open and Close the Neumovent Graph Ventilator Operation Description Disconnection: Pneumatic Box – Front Cabinet, electrical part: 1- Disconect cables J1 , J2 y S/N 2- Disconect power cable ancillary board – Pneumatic Box 3- Disconnect flat (ribbon) cables, CON 4 and CON 10, box, of the CPU board Fig.
  • Page 55 CON 4...
  • Page 56 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 How to Open and Close the Neumovent Graph Ventilator Operation Description Removal of Shield 1-Remove the 5 screws indicated in Fig.:8-A. 2-Remove the shield, Fig.:8-B. Front Cabinet Fig.:8-A Shield...
  • Page 57 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 How to Open and Close the Neumovent Graph Ventilator Operation Designation Removal of Keyboard Board 1- Disconnect the cables indicated in Fig.:9-A. 2- Remove the Keyboard Board, by removing the 20 screws that attach it to the panel.
  • Page 58 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 How to Open and Close the Neumovent Graph Ventilator Operation Description Removal of Shield- Front Cabinet 1- Remove the washer screws and foam filler. 2- Do not remove the hexagonal fillers since they do not hold the panel.
  • Page 59 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 How to Open and Close the Neumovent Graph Ventilator Operation Description Removal of the gas control set 1- Disconnect cables 1 and 2 from the connector indicated in Fig.:11-A.
  • Page 60 CHAPTER VI DETAIL OF ASSEMBLIES...
  • Page 61 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 ASSEMBLY DETAILS Code:1782 A1V Name: Oxygen inlet CODE DESCRIPTION IMP. GAS INLET, BODY WITH 6 HOLES 1782 M1V 1781 M1V IMP. GAS INLET, BODY 319 M2V 9/16 CONNECTOR 206 C1V POROUS METAL FILTER 207 C0V 2120 O´RING...
  • Page 62 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 ASSEMBLY DETAILS Code:1781 A1V Name: Air inlet CODE DESCRIPTION 1782 M1V IMP. GAS INLET, BODY WITH 6 HOLES 1781 M1V IMP. GAS INLET, BODY 659 M2V 3/4 CONNECTOR 206 C1V POROUS METAL FILTER 207 C0V 2120 O´RING...
  • Page 63 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 ASSEMBLY DETAILS Code: 2200-A1V Name: Expiratory valve CODE DESCRIPTION 2657 A1V COMPLETE EXPIRATORY VALVE COVER 1111 G0V PEEP VALVE DIAPHRAGM 2658 A1V COMPLETE EXPIRATORY VALVE BODY M 3x6x120 mm CRYSTAL TUBE...
  • Page 64 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 ASSEMBLY DETAILS Code: 0554-A1V Name: 2.8Kg/cm and 0.7 Kg/cm Regulator’s...
  • Page 65 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 ASSEMBLY DETAILS Code: 0554-A1V Name: 2.8Kg/cm and 0.7 Kg/cm Regulator’s CODE DESCRIPTION 0480 M1T ADJUSTING SCREW 0253 C0U M 4x0,7 HEXAGONAL NUT 0560 C0A WASHER 0491 M1V REGULATOR COVER 1326 M1 R ADJUSTMENT SPRING 0511 G0V...
  • Page 66 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 ASSEMBLY DETAILS Code: 2460-A1V Name: Line nonreturn valve CODE DESCRIPTION 2138 M1V BODY 2305 G1V CHOKE 2182 M1R SPRING 211 C0V 2009 O’RING 2137 M1V COVER...
  • Page 67 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 ASSEMBLY DETAILS Code: 2294-A1V Name: Pneumotacograph N° CÓDIGO DESIGNACIÓN 2781-M1V Left cover 2453-A1V Mesh holder 2772-M1V Pneumotacograph body 2773-A1V Right cover 2493-A1V Safety valve...
  • Page 68 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 ASSEMBLY DETAILS Code:2545-A1V Name: Complete NV-Graph proportional valve CODE DESCRIPTION 2547 A1V SOLENOID SET 2548 A1V MAIN PROPORTIONAL VALVE...
  • Page 69 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 ASSEMBLY DETAILS Code: 2493-A1V Name: Safety valve CODE DESCRIPTION 2488 M1 V SAFETY VALVE, PRESS 2486 M1 V SAFETY VALVE, BODY 2489 M1 V SAFETY VALVE, SPRING 2487 M1 V SAFETY VALVE, CHOKE O-ring 2-013 0515-C0O...
  • Page 70 CHAPTER VII ELECTRONIC BOARDS: DETAIL...
  • Page 71 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 ELECTRONICS DETAILS Code: 2410-A1V Designation: CPU-Board Without components Q:14,35 put it in the reverse position. Optional Con3 : flat cable 20 conductors. of 70mm...
  • Page 72 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 ELECTRONICS DETAILS Code: 2410-A1V Designation: CPU-Board Code Obs. Placed Batery 3V 35mAh LITIO Piezoeléctrico con osc.12V BUZZER BUZZER TYD12 paso .3” diametro máx .65” CONECTOR CON3 STMM-110-02-G-D CABLE TCSD-10-D-09.00-01-F-N J1;J2 Jack:413990-2 Plug:413985-1...
  • Page 73 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 ELECTRONICS DETAILS Code: 2410-A1V Designation: CPU-Board Placed Code Obs. Transistor Q:1;10;15;28 BC337 Transistor Q.3;4;6;7;8;9;11;12;16;17; BC327 18;19;20;24;25;26;27;29 Transistor Q:14;35 MPSA13 Transistor Q:30 TIP32C Transistor Q:2;5,13; 21 TIP31C Array de 10 pines 10K: Array de 8 pines R:4;110...
  • Page 74 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 ELECTRONICS DETAILS Code: 2410-A1V Designation: CPU-Board Placed Code Obs. Prom OTP 512Kb x 8 AT27C040-12JC PLCC32 Cuadruple amplificador U:4;7;13 OP400FY DIP14 Memoria EEPROM U:6;5 25C320/P Controlador pantalla, S1D13503F00A100 montaje superficial Microcontrolador AM188EM-40KC Reloj de tiempo real DIP8...
  • Page 75 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 ELECTRONICS DETAILS Code : 2109-A1 V Designation: Ancillary Board...
  • Page 76 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 ELECTRONICS DETAILS Code:2109-A1V Designation:Ancillary Board Obs. Placed Resistencia 1% metalfilm R2,R60 Resistencia 1% metalfilm Resistencia carbón R14,R68 Resistencia metalfilm Resistencia carbón R7,R9 Resistencia carbón R8,R16,R19,R21,R24, R26,R27,R28,R37,R38, R41,R65,R67 Resistencia carbón R10,R12 Resistencia carbón R11,R13,R15...
  • Page 77 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 ELECTRONICS DETAILS Code:1799-E2V rev7 Designation: Sensor Board, electric part. Differentials sensors pressure TECME S.A. P/N 1799E2V Rev 6 Designation: Sensor Bard,pneumatic part.
  • Page 78 CHAPTER VIII CALIBRATION...
  • Page 79 - The EMI must be periodically calibrated by an official organization and the calibration must be recorded and filed. -The air used must be free of oil, humidity, and particles larger than 0.3 m Procedure for Initial Calibration and Setup Neumovent Graph Ventilator Operación Descripción Access to the Calibration and Setup Menu: When the device is off, press the “Reset”...
  • Page 80 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Procedure for Initial Calibration and Setup Neumovent Graph Ventilator Operation Description 2- If the changes in the calibration are not to be saved, press any key three times The next message will be displayed on the screen:...
  • Page 81 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Procedure for Initial Calibration and Setup Neumovent Graph Ventilator Operation Description Clock Adjustment: -To changes the date and hours values: a-Select the desired option with the “Selection” key b- Press “enter” to enter and modify the values with “Selection” key c-Press “enter”...
  • Page 82 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Procedure for Initial Calibration and Setup Neumovent Graph Ventilator Operation Description Ambient Pressure Changes the values with “Selection” Press “Menú” and the next message will be displayed on the screen:...
  • Page 83 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Procedure for Initial Calibration and Setup Neumovent Graph Ventilator Operation Description Air Flow Air Flow Target Lectura Flow Memory Apertura a- Connect the device outlet to a standard flowmeter Fig.:1-A (end of chapter ).
  • Page 84 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Procedure for Initial Calibration and Setup Neumovent Graph Ventilator Operation Description Air Valve Air valve Target Flujo Apertura Memoria a-If the valve don’t have previous calibration the next message will be displayed...

  • Page 85: Pressure Sensors

    Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Procedure for Initial Calibration and Setup Neumovent Graph Ventilator Operation Description Oxigen Valve Do the same operations than Air valve. Pressure Sensors Presssure Sensors Derecho 0 0 0 Cm H...
  • Page 86 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Procedure for Initial Calibration and Setup Neumovent Graph Ventilator Operation Description b-Maximum value for the graph sensor (left) 1- Select the desired option with the “Selection” 2- Connect a 100 cmH 2 O pressure at the at the P1 and P2 inlets. simultaneously with a Y piece connection 3- Save the value with “Enter”.
  • Page 87 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Procedure for Initial Calibration and Setup Neumovent Graph Ventilator Operation Description PEEP Valve Press “Volume “ key Verify sensors reading Press “Menú” and the next message will be displayed on the screen:...
  • Page 88 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Procedure for Initial Calibration and Setup Neumovent Graph Ventilator Operation Description Initial Options Category Adult Idiom Spanish -Select the desired option with the “Selection” key and press “Enter”. -Press “Enter” to exit.
  • Page 89 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Procedure for Initial Calibration and Setup Neumovent Graph Ventilator Connection for the calibration of Flows Fig.:1 Ventilator Standard flowmeter Patient outlet Connection for of Comp.Neumo Fig.:2 Ventilator Patient´s Circuit...
  • Page 90 CHAPTER IX FINAL CONTROL...
  • Page 91 Date: 09/05/06 Final Control Neumovent Graph Ventilator Objective The purpose of this document is to provide the necessary information for the final control of the operation of the NEUMOVENT Graph ventilators. Elements ƒ Ventilator. ƒ Adult or Pediatric Patient’s Circuit ƒ...
  • Page 92 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Final Control Neumovent Graph Ventilator Operation Description Fittings: Nebulizer: Check operation. Manual trigger: Check operation. O2 100%: Check operation. Alarms Maximum Pressure Lower the alarm limit to the peak pressure level read.
  • Page 93 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Final Control Neumovent Graph Ventilator Operation Description PCV (Pressure Control) Mode Select PCV Programming: PCV = 10 ± 2 cm H2O Ti= 1.5 sec. Peep = 0 The rest is programmed with <CTRL> + <ENTER>...
  • Page 94 Review : 04 TECHNICAL AND MAINTENANCE MANUAL Graph VENTILATOR Date: 09/05/06 Final Control Neumovent Graph Ventilator Operation Description MMV Mode Programming: VE = 7 L / min. Min. VE Alarm = minimum value PSV = 10 cm H2O <ENTER>. Trigger the test lung at a low frequency to obtain a VE lower than that programmed.
