Summary of Contents for Gorenje Plus GIT63B
- Page 1 GIT63B User manual GIT73B GIT95B GIT95XC...
- Page 2 Manual GB 3 - GB 39 Pictograms used Important information...
-
Page 3: Table Of Contents
CONTENTS Your induction hob Introduction Control panel Description Safety What you should pay attention to Connection and repair During use Temperaturna varnost Cooking-time limiter Using the touch controls Induction cooking How does induction workA magnet Pans Operation Switching on the hob and setting the power Pan detection Residual warmth indicator Automatic heat-up function... -
Page 4: Your Induction Hob
YOUR INDUCTION HOB Introduction This hob has been designed for the real lover of cooking. Cooking on an induction hob has a number of advantages. It is easy, because the hob reacts quickly and can also be set to a very low power level. Because, moreover, it can also be set to a high power level, it can bring things to the boil very quickly. -
Page 5: Control Panel
YOUR INDUCTION HOB Control panel GIT63B/GIT73B 21 20 19 GIT95B 1. Keep food warm/melt with indicator 13. Pause with indicator 2. Cooking timer indicator left front zone 14. Setting indicator right front zone 3. Reduce time button 15. Setting indicator left rear zone 4. - Page 6 YOUR INDUCTION HOB GIT95XC 1. Keep food warm/melt with indicator 13. Pause with indicator 2. Cooking timer indicator left front zone 14. Setting indicator right front zone 3. Reduce time button 15. Setting indicator left rear zone 4. Egg timer indicator 16.
-
Page 7: Description
YOUR INDUCTION HOB Description GIT63B GIT73B GIT95B 1. Cooking zone front left Ø210 3,7 kW 5. Cooking zone front left Ø180 3,0 kW 2. Cooking zone rear left Ø145 2,2 kW 6. Cooking zone rear left Ø180 3,0 kW 3. Cooking zone rear right Ø180 3,0 kW 7. - Page 8 YOUR INDUCTION HOB GIT95XC 1. Cooking zone front left Ø210 3,7 kW 5. Cooking zone front left Ø180 3,0 kW 2. Cooking zone rear left Ø145 2,2 kW 6. Cooking zone rear left Ø180 3,0 kW 3. Cooking zone rear right Ø180 3,0 kW 7.
-
Page 9: Safety
SAFETY What you should pay attention to • Induction cooking is extremely safe. Various safety devices have been incorporated in the hob such as a residual heat indicator and a cooking time limiter. There are nevertheless a number of precautions you should take. - Page 10 SAFETY • The zones heat up during use and stay hot for a while afterwards. Keep young children away from the hob during and immediately after cooking. • Grease and oil are inflammable when overheated. Do not stand too close to the pan. Should oil catch fire, never try to extinguish the fire with water.
-
Page 11: Temperaturna Varnost
SAFETY Temperaturna varnost • A sensor continuously measures the temperature of certain parts of the hob. Every cooking zone is equipped with a sensor that measures the temperature of the bottom of the pan to avoid any risk of overheating when a pan boils dry. In case of temperatures rising too high, the power is reduced automatically. -
Page 12: Use
Using the touch controls The touch controls may take some getting used to if you are used to other (rotary) controls. Place the tip of your finger flat on the control to achieve the best results. You do not have to apply any pressure. The touch sensors only react to the light pressure of a fingertip. -
Page 13: How Does Induction Worka Magnet
How does induction workA magnet A magnetic field is generated in the appliance. By placing a pan with an iron base on a cooking zone, a current is induced in the pan base. This induced current generates heat in the base of the pan. Easy The electronic controls are accurate and easy to set. - Page 14 You can check for yourself whether your pans are suitable using a magnet. A pan is suitable if the base of the pan is attracted by the magnet. Suitable Unsuitable Special stainless steel pans Earthenware Class Induction Stainless steel Hard-wearing enamelled pans Porcelain Enamelled cast-iron pans Copper...
-
Page 15: Operation
OPERATION Switching on the hob and setting the power The power has 9 settings. There is also a ‘boost’ setting, which is indicated by a ‘P.’ in the display (see page 15 ‘Boost’). • Put a pan on a cooking zone. •... -
Page 16: Automatic Heat-Up Function
OPERATION Automatic heat-up function The automatic heat-up function temporarily increases the power (setting ‘9.’) to heat the contents of the pan faster. This function is available in all settings except the ‘Boost’ setting and setting ‘9.’. Switching on the automatic heat-up function The hob is switched on and a pan has been placed in a cooking zone. -
Page 17: Boost
OPERATION Boost The ‘Boost’ function is used to cook at maximum power for a short period of time (maximum 10 minutes). The power is reduced to setting 9 at the end of the maximum boost time. Switching on the boost function The hob is switched on and a pan is on the cooking zone. -
Page 18: Topljenje/Ohranjanje Toplote
OPERATION Topljenje/ohranjanje toplote Use the ‘keep food warm’ button to switch on the function to melt or keep food warm. The cooking timer is used to set the maximum melting/ warming time. The melt function (u) The function to keep food warm (U) The melt function keeps the The function to keep food warm keeps temperature of the food at a... -
Page 19: Switching Off The Hob
OPERATION Switching off the hob Switching off one cooking zone The cooking zone is switched on. The display shows a power setting between 1 and 9, or ‘P.’. • Touch and hold the - and the + button for one second to switch off the cooking zone. -
Page 20: Child Lock
OPERATION Child lock You can secure the hob with the child lock. With this setting, the hob cannot be switched on and the cooking zone settings cannot be changed. The child lock button gives you access to the following two functions: (Standard) lock mode Child lock mode The (standard) lock mode... -
Page 21: Pause
OPERATION Switch the hob to child lock mode before cleaning it to prevent it from accidentally switching on. Pause Use the pause function to ‘pause’ the whole hob for 10 minutes while cooking. The power for all of the cooking zones is automatically switched off. -
Page 22: Memory
OPERATION Memory The memory function enables you to retrieve the last settings within 6 seconds of the hob switching off. This is convenient, for example, if the whole hob was accidentally switched off by touching the On/Off button. Recognising a mode Stand-by mode The display for each cooking zone shows ‘0.’. -
Page 23: Cooking Timer/Egg Timer
Touch the - button and the + button for the cooking timer and the egg timer once at the same time. ‘00.’ is shown in the display and the red light in the middle under the display (GIT63B/GIT73B) or to the right under the display (GIT95B/ GIH674BL/GIH884BL GIT95XC) flashes. - Page 24 OPERATION • Touch and hold the - button for the cooking timer/egg timer until ‘01.’ shows in the display. Touch the - button again. The cooking timer/egg timer is now in stand-by mode. The cooking timer/egg timer automatically switches off after 10 seconds. Assigning and switching on the cooking timer The hob is switched on.
- Page 25 OPERATION Switching off the cooking timer/egg timer alarm When the set time/cooking time has elapsed, the alarm rings and the red light for the active cooking zone/egg timer flashes ‘00’. • Touch any button to switch off the alarm. • You can touch and hold the - or the + button to set the desired cooking time faster.
-
Page 26: Cooking
COOKING Healthy cooking Burning point of different types of oil To ensure your food is fried as healthily as possible, Gorenje+ recommends choosing the type of oil according to the frying temperature. Each oil has a different burning point at which toxic gasses are released. - Page 27 COOKING Use setting 7 to: • fry thick pancakes; • fry thick slices of breaded meat; • fry bacon (fat); • fry raw potatoes; • make French toast; • fry breaded fish. Use setting 6 and 5 to: • complete the cooking of large quantities; •...
-
Page 28: Maintenance
MAINTENANCE Cleaning Set the child lock before you start cleaning the hob. Daily cleaning • Although food spills cannot burn into the glass, we nevertheless recommend you to clean the hob immediately after use. • Best for daily cleaning is a damp cloth with a mild cleaning agent. •... -
Page 29: Troubleshooting
TROUBLESHOOTING General If you notice a crack in the glass top (however small), switch the hob off immediately, unplug the hob, turn off the (automatic) fuse switch(es) in the meter cupboard or, in the event of a permanent connection, set the switch in the power supply lead to zero.) Contact the service department. - Page 30 TROUBLESHOOTING Symptom Possible cause Solution The hob is not working There is no power supply due Check the fuses or the electric and nothing appears in the to a defective cable or a faulty switch (if there is no plug). display.
-
Page 31: Installation
Clearance Sufficient all-round clearance is essential to the safe use of the hob. Check that there is enough clearance. * GIT63B: min. 65 cm GIT73B: min. 78 cm cooker hood GIT95B: min. 91 cm cabinet GIT95XC: min. - Page 32 INSTALLATION Installation dimensions The dimensions and recesses are shown in the illustrations beneath. GIT63B GIT73B 640-645 770-775 min 20 min 20 min 40 min 40 488-490 min 600 488-490 min 600 min 50 min 50 748-750 558-560 GIT95B / GIT95XC...
-
Page 33: Ventilation
INSTALLATION Ventilation The electronics in the appliance need cooling. The appliancewill automatically switch off if there is insuffi cient air circulation.There are ventilation openings on the underside of the appliance.It must be possible for cool air to be drawn in through theseopenings. There are outlet openings on the underside and at thefront of the appliance. -
Page 34: Lower Kitchen Cabinet With An Oven
INSTALLATION Lower kitchen cabinet with an oven • Installing the oven under an induction hob is possible with oven types EVP4.., EVP2.., which are fi tted with a cooling fan. Before installing the oven, the rear wall of the kitchen cabinet should be removed. -
Page 35: Electrical Connection
INSTALLATION Electrical connection Common connections: • 2 phase and 1 zero connection (2 1N, 400 V~/ 50 Hz): ▷ The voltage between the phases and the zeros is 230 V~. The voltage between the two phases is 400 V~. Fit a connecting bridge between connecting points 4-5. - Page 36 INSTALLATION Connection for hobs with 5 cooking zones: • 3 phases with 1 zero connection (3 1N, 400 V~ / 50 Hz): ▷ The voltage between the phases and the zero is 230 V~. The voltage between the phases is 400 V~. Fit a connecting bridge between connecting points 4-5.
-
Page 37: Building In
INSTALLATION Building in Check that the cabinet and the cut-out meet the dimension and ventilation requirement. Threat the sawn ends of wooden or synthetic worktops with sealing varnish if necessary, to prevent moisture causing the worktop to swell. Lay the hob upside down on the worktop. Fit the connecting cable to the appliance in compliance with requirements (see page 32 and 33). -
Page 38: Technical Details
INSTALLATION Technical details This appliance complies with all relevant CE directives. Hob type GIT63B GIT73B GIT95B GIT95XC Induction Connection 230 V - 50 Hz 230 V - 50 Hz 230 V - 50 Hz Max. capacity cooking zones Front left 3,7 kW (Ø... -
Page 39: Environmental Aspects
ENVIRONMENTAL ASPECTS Disposal of packaging and appliance In the manufacturing of this appliance durable materials were used. Make sure to dispose of this equipment responsibly at the end of its lifecycle. Ask the authorities for more information regarding this. The appliance packaging is recyclable. The following may have been used: •... - Page 40 GB 40...
- Page 41 GB 41...
- Page 42 GB 42...
- Page 44 GIT_G+ en (12-15)
