- Page 3 Dear customer, Congratulations on your purchase of a Bazooka MAW high- performance subwoofer. At Bazooka we are fanatics about accurate music reproduction. Your selection of our products for your sound system indicates that quality sound is also important to you too. At SAS,...
-
Page 4: Calculating Enclosure Volume
CALCULATING ENCLOSURE VOLUME It is difficult to give exact box dimensions that are universal for all cars and trucks. It is for this reason that you must be able to calculate the space in which you have available in order to achieve the proper air volume required. - Page 5 PRODUCT SPECIFICATIONS (8” SUBWOOFERS) MAW8004 Free Air Resonance. Total Q of driver @ FS including all resistance. Q of driver @ FS including non electrical resistance only. Q of driver @ FS including electrical resistance only. The driver's compliance expressed as an equivalent volume of air (Cubic Ft.).
- Page 6 PRODUCT SPECIFICATIONS (10” SUBWOOFERS) MAW1004 Free Air Resonance. Total Q of driver @ FS including all resistance. Q of driver @ FS including non electrical resistance only. Q of driver @ FS including electrical resistance only. The driver's compliance expressed as an equivalent volume of air (Cubic Ft.).
- Page 7 MAW8004 RECOMMENDED ENCLOSURES Please Note: Our suggested box volumes are given as internal air requirements Sealed Enclosure Box Volume * 0.34 Cu Ft. * Box is given as internal air volume including driver Displacement. MAW8004 Amplitude Response (dB/Hz) MAW8004 Amplitude Response (dB/Hz) -6 -6 5 Hz 5 Hz...
- Page 8 MAW8008 RECOMMENDED ENCLOSURES Please Note: Our suggested box volumes are given as internal air requirements Sealed Enclosure Box Volume * 0.34 Cu Ft. * Box is given as internal air volume including driver Displacement. MAW8008 Amplitude Response (dB/Hz) MAW8008 Amplitude Response (dB/Hz) -6 -6 5 Hz 5 Hz...
- Page 9 MAW1004 RECOMMENDED ENCLOSURES Please Note: Our suggested box volumes are given as internal air requirements Sealed Enclosure Box Volume * 0.66 Cu Ft. * Box is given as internal air volume including driver Displacement. MAW1004 Amplitude Response (dB/Hz) MAW1004 Amplitude Response (dB/Hz) -6 -6 5 Hz 5 Hz...
- Page 10 MAW1008 RECOMMENDED ENCLOSURES Please Note: Our suggested box volumes are given as internal air requirements Sealed Enclosure Box Volume * 0.50 Cu Ft. * Box is given as internal air volume including driver Displacement. MAW1008 Amplitude Response (dB/Hz) MAW1008 Amplitude Response (dB/Hz) -6 -6 5 Hz 5 Hz...
- Page 11 The innovative design of the MAW component Woofers allows you to liquid cool the voice coil motor assembly for maximum power handling capability. With the addition of the CHIL PLUG and the CHIL KIT from your local dealer, or directly from SAS, you can easily add liquid cooling to your MAW Series Component Woofer.
- Page 12 www.extremeconcepts.com MAW Manual Rev 2.10.02...
