Chemtrac HydroAct 4 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HydroAct 4 User Manual
Chemtrac, Inc
Firmware Version: 1.19
November 15, 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HydroAct 4 and is the answer not in the manual?

Questions and answers

Related Manuals for Chemtrac HydroAct 4

Summary of Contents for Chemtrac HydroAct 4

  • Page 1 HydroAct 4 User Manual Chemtrac, Inc Firmware Version: 1.19 November 15, 2017...
  • Page 2 Copyright © 2017 Chemtrac, Inc All rights reserved. No part of this publication may be reproduced, distributed, or transmitted in any form or by any means, including photocopying, recording, or other electronic or mechanical methods, without the prior written permission of the publisher, except in the case of brief quotations embodied in critical reviews and certain other noncommercial uses permitted by copyright law.

  • Page 3: Table Of Contents

    Contents Introduction ............5 Safety Precautions 1.1.1 Warnings used in this manual .
  • Page 4 2.4.2 Main Menu ............18 2.4.3 Home Screens .

  • Page 5: Introduction

    This manual contains basic information to be noted during installation, operation and maintenance. It is therefore essential that this manual be read by the contractor before installing and commissioning the HydroAct 4, as well as by the relevant operating personnel/owner of the unit. It must remain available for reference at all times.

  • Page 6: Qualification And Training Of Personnel

    Chapter 1. Introduction Refers to an imminent danger or a potential hazardous situation. Non-compliance can lead to death or extremely serious injury. Refers to a potential hazardous situation. Non-compliance can lead to injury or property damage. Draws attention to supplementary information to make the work easier and ensure trouble- free operation.

  • Page 7: Safe Operation

    1.1 Safety Precautions 1.1.4 Safe Operation The safety instructions contained in this manual must be observed. The owner is responsible for ensuring compliance with local safety regulations.

  • Page 9: Analyzer

    Analyzer Overview ......11 Safety Precautions Technical Data Installation Operation...

  • Page 11: Overview

    2. Overview The HydroAct 4 is a compact electronic communication and control system. It is designed for use with many different measuring sensors. Any use other than the one described here compromises the safety of persons and the entire measuring system and is, therefore, not permitted. The manufacturer is not liable for damage caused by improper or non-designated use.

  • Page 12: Safety Precautions Installation, Maintenance And Inspection

    • The HydroAct 4 must always be isolated before starting any work. • Please be aware that the HydroAct 4 may be controlling chemical dosing and as such shutting down the HydroAct 4 without due regard to the systems it is controlling can lead to chemical release.

  • Page 13: Installation

    2.3 Installation Enclosure Material ABS flame retardant Seals EPDM HydroAct 4 Dimensions 1. 103mm 2. 309mm 3. 230mm Installation As with all instrumentation the installation and commissioning of this instrument is crucial to its safe and effective operation. This instrument must only be used for its purpose as outlined in this manual.

  • Page 14: Unpacking

    2.3.3 Mounting The HydroAct 4 enclosure is very versatile and can be wall mounted, panel mounted or mounted on a handrail or pole . The HydroAct 4 electronics should be mounted so that: • it is away from sources of heat or direct sunlight, •...
  • Page 15 HydroAct 4 Panel Mounting A - HydroAct 4 front section, B - Four M5 bolts, C - HydroAct 4 rear section, D - Rubber gasket, E - Panel, F - Support bracket, G - Four M5 washers, H - Four M5 nuts.
  • Page 16 Handrail Mounting The analyzer enclosure can be handrail mounted using the optional handrail mount kit. By turning the brackets through 90° the analyzer can also be pole mounted. HydroAct 4 Handrail Mount- A HydroAct 4 B Large bracket C Four M5 8mm bolts...

  • Page 17: Electrical Connections

    2.3 Installation 2.3.4 Electrical Connections 1. Auxiliary power from secondary PSU 2. 12V input from main PSU 3. Communication card slots 4. Sensor and output card slots 5. Digital input configuration jumpers 6. Relay and digital input connectors 7. AC Power to main PSU 8.

  • Page 18: Operation User Interface

    Example Main Menu The Menu screen is a standard display in your HydroAct 4 and is a tile based display of all the different parts or “devices” that make up your analyzer. By using the Up, Down, Left, Right and Select button it is possible to navigate to any part of the analyzer by highlighting the icon and selecting it.

  • Page 19: Home Screens

    2.4 Operation menus accessible by highlighting the menu item and either pressing the Select button or the Right button. 2.4.3 Home Screens Home screens are used to display information from more than one source on a single display. They are accessed by pressing “Home” from any screen displaying the soft-key and then by pressing the Left or Right button to scroll through the available Home Screens.

  • Page 20: Analyzer Options

    Chapter 2. Overview HydroAct 4 Button Layout The analyzer is preconfigured with a default user called “user1” who has full access to the analyzer, with the default password of: 1, 1, 1, 1, 1, 1 From the button layout above.
  • Page 21 ID would typically refer to a specific analyzer. Language The user interface of the HydroAct 4 can be set to any supported language. Use the drop down list to select the language of choice.
  • Page 22 2.4.5.3 Home Screens The HydroAct 4 has the capability to have multiple home screens which give the user options as to how the display provides information (see section 2.4.3). To set up a new home screen, edit or delete an existing home screen, select:...
  • Page 23 2.4 Operation Select the home screen type from the drop down list. Generic home screens allow up to 4 devices to be displayed in a variety of formats. Other home screen types are application-dependent and are described below, if applicable. For this example, select “Generic” and press “Create”. Editing an existing Generic home screen or creating a new Generic home screen will display the above form.
  • Page 24 Chapter 2. Overview Layout 3 Layout 4 Layout 5 Layout 6 Each window can display information about a device or a data log graph. To select what is displayed in each window of a particular layout, move the selection to highlight the window and press the select button.
  • Page 25 Security access levels Access to many of the analyzer functions is secured using password protection. To allow flexible security profiles the HydroAct 4 is split into six access areas: System Controls access to analyzer-specific settings and communication options. Sensor Controls access to sensor devices.
  • Page 26 Chapter 2. Overview To add a user, highlight “<+ Add User>” and press the select button. Enter the desired user name and access rights. To set the password, press “Password” and follow the on screen prompts. To delete a user, highlight the user name and press “Delete” .
  • Page 27 2.4 Operation The HydroAct 4 makes use of several internal read-only file systems as well as the micro SD card. Information regarding the file system usage can be viewed by selecting: Options Information File Systems All entries other than “/mnt” are internal read-only file systems and the information may be useful for technical support inquiries.
  • Page 28 Chapter 2. Overview The “re-alarm” feature can be enabled and the timeout set. If the analyzer is in alarm and that alarm is acknowledged (see below), then the analyzer will return to the alarm state after the timeout has expired if the error condition has not been rectified. The exact reason for the active alarm is shown by selecting: Options Alarm...

  • Page 29: Logs

    2.4 Operation Configuration Files Restore Clone Analyzer Settings (Name, Alarm, Users, etc) Communications Card Settings Data Logs Setup Home Screens Device Codes Device Settings Modbus Maps 2.4.6 Logs Selecting the log tile from the main menu will display a secondary logs menu. These available options are;...
  • Page 30 Chapter 2. Overview Use the arrow keys to scroll up, down, left and right. Press “Clear” to delete the current status log messages and truncate the status log. Press “Download” to save the status log to SD card. 2.4.6.3 Data Logs 2.4.6.3.1 Creating a Data Log To create a new data log, select “Create Data Log”.
  • Page 31 2.4 Operation 2.4.6.3.2 Viewing a Data Log Each data log configured will be displayed as a tile in the Logs menu. Select the data log of interest to view the data. The overview allows the renaming of the log and changing of the log interval. The “Delete” button will remove the log completely and prevent any further data logs being collected.

  • Page 33: Options

    Options Sensors ......35 PC6 Particle Counter Outputs ......55 Analog Outputs Relay Output...

  • Page 35: Sensors

    The constant head flow control weir ensures stable, reproducible flow and accurate particle counts. The PC6 Particle Counter connects over a RS485 connection to the HydroAct 4 which allows the user to see the individual size ranges and particle counts in multiple size ranges. The HydroAct 4 controller provides an indication of the sensor’s cleanliness and allows the user to know...

  • Page 36: Theory Of Operation

    Chapter 3. Sensors The PC6 Particle Counter is equipped with a class 3R laser and should not be tampered with in any way. In order to provide maximum user safety the PC6 Particle Counter particle counter was designed with the following issues in mind. •...
  • Page 37 3.1 PC6 Particle Counter The amount of light blocked from the detector is the sum of the light absorbed by the particle and the light scattered or reflected by the particle. The size, composition, color, refractive index, light scattering coefficient, etc of each particle will determine how much light is scattered and how much is absorbed.

  • Page 38: Installation

    Chapter 3. Sensors 3.1.2.2 Technical Data 3.1.2.2.1 Sensor Laser Type Solid-state Laser Diode (780nm) Flow Cell Dimensions 750 x 750 m Cell Material Nituff coated aluminum, (PEEK plastic, Optional) Viewing Windows Sapphire Detection Range 2 - 750 m Size Channels Up to 6, user selectable size ranges. Sizing Range 2..127 m Flow Rate 75 ml/min Laser Diode Life greater than 75000 hours at 55 °C...
  • Page 39 3.1 PC6 Particle Counter 3.1.3.3 Mounting The total space needed to mount the PC6 Particle Counter sensor is an area 533mm (21 in.) wide and 1016mm (40 in.) tall. The PC6 Particle Counter should be permanently mounted to a flat, vertical surface, such as a wall or support column, in an upright position using the 4 mounting holes located on the enclosure.
  • Page 40 Chapter 3. Sensors Important Note on Weir Installation 1. Make sure the clear horizontal pipe at the top of Weir is higher than the top of the PC6 Particle Counter by 254mm to 305mm (10 - 12 in.). This ensures flow will start reliably through the sensor. If the Weir is mounted too low, the flow may not re-start reliably through the sensor if flow was ever lost for any reason.
  • Page 41 “Slot #1” position as shown in this diagram. Otherwise, if additional plugin cards are installed in slots 2 to 4 it will be necessary to power up the HydroAct 4 and check the sensor...
  • Page 42 Chapter 3. Sensors name and/or connections diagram under the sensor menu to determine the correct slot position for the sensor input card. There will be numbers appearing at the end of the sensor name like PC 1.1 or PC 1.2. A designation of 1.2 indicates the sensor input card is located in slot #2, whereas a designation of 1.3 indicates slot #3.

  • Page 43: Commissioning

    With water flowing through the sensor, a check should be performed to make sure the PC6 Particle Counter sensor does not have a cell condition alarm reporting on the HydroAct 4. If there is an alarm, try cleaning the sensor as detailed in section 3.1.6.1. Contact your supplier for assistance if the cell condition alarm does not clear after cleaning.

  • Page 44: Operation

    Chapter 3. Sensors 3.1.4.3 Setting proper flow rate Since all particle count data must be based on a sample volume, flow control is crucial for accurate and repeatable performance. The simplest and most effective way to achieve constant flow is to utilize a flow control weir.
  • Page 45 3.1 PC6 Particle Counter Laser Condition Percentage readout reflecting changes in laser operating current. This value is pro- vided for diagnostic information only. Laser current will change as a function of laser temperature and age. The laser percentage will increase over the lifetime of the laser and also when ambient air or water temperature increases.
  • Page 46 It is recommended to leave the flow rate at 75 ml/min unless changes to this setting have been previously discussed with Chemtrac. Units Options are “Raw”, “per ml” or “per 100 ml”. If “Raw” is selected, the particle count data will represent all particles that passed through the sensor during the sample period.
  • Page 47 Termination Enabled Use the checkbox to enable the use of a termination resistor. Byte Swap To support different microprocessors that store data in different formats, the HydroAct 4 can alter the data it sends and receives to match the format expected by the sensor. The byte swap option allows the order of bytes in the 16-bit registers to be reversed.
  • Page 48 Chapter 3. Sensors PPB Averaging Cycles Incorporates a rolling average of the number of cycles selected. Range is from 0 (off) to 15. PPB Correlation Factor Multiplier that allows adjustment of the volumetric concentration calculation to better match an independent measurement. Range is from 0.001 to 9.99. 3.1.5.6 Maintenance Setup The PC6 Particle Counter comes equipped with proactive maintenance alerts.
  • Page 49 Alarms are the means by which values obtained from sensors cause visible, audible or physical actions to occur. Alarms are not to be confused with relays. An alarm in a HydroAct 4 unit will create a visible bar across the top of the screen and sound a buzzer. One flow alarm per sensor and two data alarms per parameter are available.
  • Page 50 Chapter 3. Sensors Enabled Selecting this option turns the alarm/threshold on or off. Set The Value is used to trigger the alarm or threshold . The Delay is the amount of time the value has to exceed the set value before the alarm/threshold is triggered. Reset The Value is used to clear the alarm or threshold.

  • Page 51: Maintenance

    Threshold 2 active The second parameter threshold is active and triggered. 3.1.5.14 Connections As the HydroAct 4 is a modular system the exact wiring details will be specific to each order. Electrical connections required can be viewed by selecting: Options Connections In the image above, the left side shows the position of the connector.
  • Page 52 Chapter 3. Sensors using the cleaning brush. The sapphire window and the external flow cell design make brush cleaning a safe and effective method for removing tough contaminants. Several methods may be used to clear a blocked flow cell. One of the most effective tools is a small can of compressed air.

  • Page 53: Troubleshooting

    3.1 PC6 Particle Counter tubing. It is reasonable to expect some liquid spillage when disconnecting tubing so be certain that no sensitive electronics or live circuits are exposed. 3.1.7 Troubleshooting 3.1.7.1 Cell Condition Low Possible cause Possible solution Flow cell dirty. Clean sensor flow cell.

  • Page 55: Outputs

    For example to a SCADA for data acquisition or to a pump for dosing control. The two types of output used by HydroAct 4 are the analog output and relay In order to utilize the full capability of the instrument it is necessary to link the signal/value and an output device, such as an alarm, threshold or control options for the relays or analog outputs.

  • Page 56: Commissioning

    For example a 4-20mA output at the analyzer could end up being 3.95mA to 19.9mA at the end of the cable. The HydroAct 4 has the capability to drive more or less current to account for this resistance so that the analog output is exactly that required at the end of the cable.
  • Page 57 4.1 Analog Outputs 4.1.4.1 Setup The setup of the analog output is split into three sections. Later sections can be accessed separately from the menu or by selecting “Next” from any of the previous pages. To access the analog output setup: Options Setup...
  • Page 58 Chapter 4. Outputs Type Choose the type of analog output from the drop down box. See technical data for a list of supported output types. See section 4.1.2. Manual Value Enter the manual value of the output as a percentage. For example if 4..20mA output type is selected a manual value of 50% will force the current output to 12mA.
  • Page 59 4.1 Analog Outputs Type Choose the type of analog output from the drop down box. See the technical data in section 4.1.2 for a list of supported outputs. Minimum Enter the parameter value that translates to a minimum output of e.g. 4mA if “type” is set to 4..20mA.
  • Page 60 I/O card in use This flag is set when two devices are attempting to use the same I/O card. I/O card configuration failed This flag is set if the I/O plugin card fails to respond correctly. Contact Chemtrac for advice. 4.1.4.7...

  • Page 61: Relay Output

    4.2 Relay Output The image above is for an output with the types selected as 0..20mA or 4..20mA. The connections will reflect the configuration of the device and differ between current and voltage outputs. Relay Output 4.2.1 General Information Relay outputs, typically mechanical reed relays are installed at time of manufacture. A relay is a mechanical or electronic device mounted on the electronics within the instrument that can switch.
  • Page 62 Chapter 4. Outputs Name Device name to identify control in menus. Text can be up to 25 characters long. Display Options are “Show” or “Hide” the device tile on the menu screen. Enabled Options are “Yes” or “No”. This option must be enabled for the option to function. Mode Options Options are “Manual”...
  • Page 63 4.2 Relay Output Polarity Options are “Normally Open” and “Normally Closed”. 4.2.3.3 Options for Control Output Mode 4.2.3.3.1 Map Output This configuration screen is accessed by pressing “Next” from the Output Setup configuration screen or navigating via the Options Menu. Options Setup Map Output...
  • Page 64 Chapter 4. Outputs In all cases the polarity and output mode of the relay will need to be configured. Pulse width modulation outputs a repeated pulse with a fixed width. The control signal is output by increasing the proportion of time the relay is active in any pulse as the value increases. Pulse frequency modulation outputs pulses of a fixed activated width, but increases the frequency of the pulses in respect of the control output value.
  • Page 65 4.2 Relay Output Sensor Select the appropriate sensor from the drop down list. Parameter Choose the appropriate parameter from the drop down list. If the selected sensor has only one parameter this option may not be available. The “Next” button is a shortcut to the following configuration screen. 4.2.3.4.2 Configuration Setup This configuration screen is accessed by pressing “Next”...
  • Page 66 Chapter 4. Outputs Device Choose from a list of available devices. The “Next” button is a shortcut to the following configuration screen. 4.2.3.5.2 Configuration This configuration screen is accessed by pressing “Next” from the Map Output configuration screen or navigating via the Options Menu. Options Setup Configuration...
  • Page 67 4.2 Relay Output Device Choose from a list of available devices. The “Next” button is a shortcut to the following configuration screen. 4.2.3.6.2 Configuration This configuration screen is accessed by pressing “Next” from the Map Output screen or navigating via the Options Menu.
  • Page 68 Chapter 4. Outputs Sensor Choose the appropriate sensor from the drop down list. Parameter Choose the appropriate parameter from the drop down list. The “Next” button is a shortcut to the following configuration screen. 4.2.3.7.2 Configuration This configuration screen is accessed by pressing “Next” from the Map Output screen or navigating via the Options Menu.
  • Page 69 4.2 Relay Output Flags that are active are shown in black text on a white background, those that are not active are grayed out. Selecting the flag will cause the relay to activate if that parameter flag becomes active. 4.2.3.8 Options for System Status 4.2.3.8.1 Map Output...
  • Page 70 Chapter 4. Outputs System Status Options are “Normal”, “Alarm Active” or “Alarm Acknowledged” 4.2.3.9 Status Flags The status flags show the state of a device. These flags can either be active or not. To see the state of these status flags, select: Options Device Flags Status Flags...
  • Page 71 4.2 Relay Output Options are Polarity Options are “Normally Open” or “Normally Closed” Active Options are “No” or “Yes” 4.2.3.12 Connections Options Connections This screen identifies the terminals to use for electrical connections for this relay. The left hand pane identifies the terminal block and the right hand pane the connectors on the terminal block.

  • Page 73: Documentation

    Documentation Warranty ......75 Returns ......77 Contact Details...

  • Page 75: Warranty

    5. Warranty Chemtrac, Inc warrants its product to be free of defects in material and workmanship for a period of one year from date of shipment to the original customer unless specifically agreed elsewhere. Upon receipt of written notice from the customer, Chemtrac shall issue a returns form for the defective product and, upon its receipt, shall repair or replace (at the discretion of Chemtrac) the defective equipment or components.

  • Page 77: Returns

    If the analyzer has to be repaired, please return it cleaned to your local service organization or Chemtrac, Inc at the address below. To return your equipment for repair: • Contact Chemtrac support, open a service ticket and request a returns form. • Complete the returns form, including the contaminant declaration.
