100 Craftway, P.O. Box 128
Littlestown, Pennsylvania 17340-0128
Phone: 800-331-4185
CAUTION
1. The electrical power must be disconnected from the fixture and pole before installing, servicing, or
relamping the fixture.
2. These directions must be read carefully and adhered to. Failure to do so may result in injury, damage to
the fixture, and voiding the warranty.
This fixture is intended for installation in accordance with the National Electrical Code and local code
specifications. Failure to adhere to these codes and instructions may result in serious injury and/or damage
to the ballast and void the warranty. These instructions do not purport to cover all details or variations in
equipment, nor to provide for every possible contingency related to installation, operation, maintenance,
or mounting situation. Should specific problems occur that are not addressed by these instructions, contact
your Sales Representative or distributor for assistance. Retain these instructions for future reference.
32001243, revision E
INSTALLATION INSTRUCTIONS:
OB361 AND TB361 BOLLARDS
Fax: 717-359-9672
OB361
TB361
page 1 of 4
Advertisement
Summary of Contents for Hadco OB361
- Page 1 INSTALLATION INSTRUCTIONS: OB361 AND TB361 BOLLARDS 100 Craftway, P.O. Box 128 Littlestown, Pennsylvania 17340-0128 Phone: 800-331-4185 Fax: 717-359-9672 OB361 TB361 CAUTION 1. The electrical power must be disconnected from the fixture and pole before installing, servicing, or relamping the fixture.
- Page 2 DISCLAIMER While we believe these instructions to be accurate at the time of publication, HADCO reserves the right to make changes to this fixture and/or components. The contractor should follow local and National Electrical Codes where required. For any further information please contact HADCO customer service.
- Page 3 #8-32 FLAT-HEAD SCREWS (2) ROOF HEXAGONAL LENS (w/gasket) CAGE LAMP (by others) LOUVER ASSEMBLY (optional - see "Note:" on pg.2 to install) BALLAST ASSEMBLY BOLLARD POST 5/16-18 FLAT-HEAD SCREWS (4) POST MOUNTING PLATE WASHERS (8) 1/2" HEX NUTS (8) 1/2" X 15-1/2" ANCHOR RODS GROUND LINE 2"...
- Page 4 REPLACEMENT COMPONENTS OB361-ROOF(*) ROOF FOR OB361 TB361-ROOF(*) ROOF FOR TB361 OBTB361-CAGE(*) CAGE ASSEMBLY (does not include panels) OBTB361-LOUVERS(*) OPTIC LOUVERS (includes cast spacer) OBTB361-LENS-REFR HEXAGONAL TYPE 5 REFRACTIVE LENS (includes gasket) OBTB361-LENS-CLR HEXAGONAL CLEAR LENS (includes gasket) OBTB361-LENS-OPAL HEXAGONAL OPAL LENS (includes gasket)
