- Page 1 © 2010 by Huchez Treuils S.A.S. Manual wall winch Manual winch MANISTOR 100 and 200 ® Instruction manual _________________________ 173-192.10-3...
-
Page 2: Table Of Contents
PRODUCT DEVELOPED AND MANUFACTURED ACCORDING TO NF EN 13157 STANDARD REGISTERED DESIGN To ensure the constant improvement of its products, HUCHEZ reserves the right to change the equipment as described below and, in this case, to supply products which differ from the illustrations in this instruction manual. -
Page 3: Presentation Of The Machines
© 2010 by Huchez Treuils S.A.S. 2 – Presentation of the machines MANISTOR® winches are manual lifting machines manufactured according to the standards and regulations in force. 2.1. Construction Aluminium chassis Polymer composite drum Double rope fastener ... - Page 4 © 2010 by Huchez Treuils S.A.S. 2.3. Technical features of the different models Rope Minimum Weight lift per Number (bare Capacity Handle turn of Max. Model winch, Ø mm capacity load kg layers without handle rope) kg Manistor® 100 Manistor® 200 The rope diameter indicated above corresponds to the load on the last layer.
-
Page 5: Handling - Storage
© 2010 by Huchez Treuils S.A.S. - Lifting a load: turn to the right - Lowering a load: turn to the left After use, it is not obligatory to remove the handle; however this is highly recommended if the winch is in a public place or a public path. - Page 6 © 2010 by Huchez Treuils S.A.S. 4.3 Installing the rope On the Manistor® 100: Remove the handle 1, remove the screws 2a and 2b, as well as the protection washer 3. Release the screws 4a and 4b. Pass the rope through the drum via the opening 5, the rope will come out through the opening 6.
- Page 7 © 2010 by Huchez Treuils S.A.S. Release the screws 16a and 16b. Pass the rope through the opening 17 of the housing. Pass the rope through the drum via the opening 18, the rope will come out through the opening 19. Place the rope in the groove 20 ensuring that it does not go beyond the surface 21.
- Page 8 © 2010 by Huchez Treuils S.A.S. Rope output angle 4.4 In the event of a system blockage If the winch blocks as a result of misuse and all lifting and lowering operations are impossible, it is important not to force the machine. This could cause damage and even cause the load to fall.
-
Page 9: Servicing And Maintenance
© 2010 by Huchez Treuils S.A.S. 5 – Servicing and maintenance The delivered winches are ready to be used (after installing the rope if not supplied by the manufacturer). A maintenance check is required at least once a year: The following require regular greasing: - on Manistor®... - Page 10 © 2010 by Huchez Treuils S.A.S. - on Manistor® 200: gears with an EP.2 grade grease for open gears Surfaces to be greased on Manistor 200. (In addition to the gears). Regularly and before every use: check the condition of the rope, hook and safety latch.
-
Page 11: Contraindications For Use
© 2010 by Huchez Treuils S.A.S. 6 – Contraindications for use Before using the equipment, check for potential causes of overloading such as: adhesion to the ground, suction, jamming, etc. All forbidden and incorrect uses or operations are presented below: It is forbidden to: ... -
Page 12: Taking Out Of Use
© 2010 by Huchez Treuils S.A.S. In accordance with regulations, the user must keep an inspection booklet recording all the inspections and operations carried out on the machine (Rule FEM 9755). In France, since 1 April 2005, the owner of a lifting machine must: 1. -
Page 13: Example Of The Declaration Of Conformity
© 2010 by Huchez Treuils S.A.S. 10 – Example of the Declaration of Conformity Original instruction manual All rights reserved... -
Page 14: Spare Parts
© 2010 by Huchez Treuils S.A.S. 11 – Spare parts MANISTOR® 100 Description 21889 Brake screw 21890 Drum 21894 Ratchet 21895 Handle 21901 Ratchet spring 21905 Brake nut 21907 Stainless-steel washer 21908 Housing 13698 Nut M6 13045 External retaining ring Ø20x1.2... - Page 15 © 2010 by Huchez Treuils S.A.S. MANISTOR® 200 Description 21889 Brake screw 21890 Drum 21891 Bearing 21892 12-tooth sprocket wheel 21893 37-tooth wheel 21894 Ratchet 21895 Handle 21901 Ratchet spring 21903 Self-lubricating ring 20x26x16 21907 Stainless-steel washer 21909 Housing 21910...
